Micom EDM MM50 Installation Instructions Manual

Magnetic linear sliding door operator auto & assist version
Hide thumbs

Advertisement

Quick Links

Download this manual
MODEL: EDM MM50 & MM80
MAGNETIC LINEAR SLIDING DOOR OPERATOR
MAGNETIC LINEAR
SLIDING DOOR OPERATOR
INSTALLATION INSTRUCTIONS
_________________________________
MODEL:
EDM MM50 & MM80
Auto & Assist Version
(Japanese Type)
ORIGINAL INSTRUCTIONS
MICOM Autodoor | Osaka – Japan
DATE: 2011
No. MM0004
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the EDM MM50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Micom EDM MM50

Summary of Contents for Micom EDM MM50

  • Page 1 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR MAGNETIC LINEAR SLIDING DOOR OPERATOR INSTALLATION INSTRUCTIONS _________________________________ MODEL: EDM MM50 & MM80 Auto & Assist Version (Japanese Type) ORIGINAL INSTRUCTIONS MICOM Autodoor | Osaka – Japan DATE: 2011 No. MM0004...
  • Page 2 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR WARNING: Avoidance of Injury, Electric shock and Fire  Installation and adjustment must be performed by approved personnel only.  Repair and/or alteration to the control box and motor are prohibited.
  • Page 3 Door frame may alter after original installation due to the condition of the building. Further adjustment may be needed later after installation. IF YOU HAVE ANY PROBLEMS – PLEASE SWITCH OFF THE PRODUCT AND CONTACT A MICOM REPRESENTATIVE IMMEDIATLEY OR E-MAIL: info@micomautodoor.com...
  • Page 4 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 1. Operator Description (MM50 & MM80 from Japan) AUTO Type ASSIST Type Push & Go Function Push & Go Function Vi-Part Synchronisation Open Speed Adjuster Open Speed Adjuster Partial Open Adjuster...
  • Page 5 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 1.2 Control Box MM50 & MM80 (Auto & Assist Type) Description Motor Connection – Already Connected E-Lock Connection (option) Harness Connector – Signal Input / Output Data LED - Power On – Green LED will Flash 5sec. Then Green LED ON Activation Signal / Safety Signal Input –...
  • Page 6 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 2. Installation 2.1 Cutting Rail Cut to size for required installation. Control and Linear Motor must be protected from metal particles. 2.2 Applicable Door Note: Door position and alignment to Applicable Door Width +/- 100mm (50mm Each Side) of Magnet Length.
  • Page 7 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 2.3 Hanger Assemblies Position of hangers – Hangers should not be closer than shown. If the pitch is too close, the door will not move Fix with M8 Bolts supplied.
  • Page 8 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 2.4 Installation of Operator Using appropriate fixing, attach operator to horizontal surface. X3 Plastic Protection Plates – Do not remove - To protect Linear Motor and Magnet during installation - Retain to future maintenance 2.4 Installation of Door...
  • Page 9 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR Step3. Hanging Door – Use Door mounted without tightening hangers Step4. Tightening hangers with M8 nut. X3 Plastic Protection Plates Secure door leaf with M8 Nut Once bolts are tightened, door and hangers will be aligned.
  • Page 10 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 2.5 Plastic Protection Plates It is important to have x3 plastic protection plates in place when installation is being carried out. These plates protect the Linear Magnetic Motor and the Moving Magnet from being in contacting with each other and causing damage. As well as maintaining the correct 2mm distance between the Linear motor and moving magnet before the hanger assemblies are tightened.
  • Page 11 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 2.7 Moving Magnet – Set up & Correct Positioning See Linear Motor – There you will find white markings. These indicate the overlap allowance between the Linear Motor and Moving Magnet.
  • Page 12 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 2.8 Wiring 2.8.1 Power Input & Mains Switch 1. Power Switch On/Off Plug In. 2. AC100V 3. AC100V 4. EARTH 2.8.2 Harness Wiring Activation Input (SS) Threshold Safety Input (SB)
  • Page 13 With an E-Lock fitted, the door will lock after it is fully closed. CAUTION: If the door does not stop at the closed end position and re-opens automatically. The operator is not installed correctly. Please contact your MICOM Representative or email: info@micomautodoor.com...
  • Page 14 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 3.3 Activation & Functions Not only can the operator be activated by all customary sensors and activation devices, but also by hand activation. Please see supporting Wiring Diagrams for accessory options.
  • Page 15 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 4. Operation Adjustment 4.1 OPEN SPEED – ADJUSTER 1. Open / Close Speed is adjustable by the speed adjuster. Turning Right = Faster (F). Adjustable range is 200~500mm/s. Factory Setting Speed: Open Speed at 400mm/s / Close Speed at 300mm/s.
  • Page 16 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 4.4 AUTO Type - Open / Close Breaking & Sensing Function (with Bi-Part) Plug No.1 Adjustment 2 pin / White Plug No.2 Adjustment 3 pin / Black Plug No.3 – Close Pressure 2 pin / Black 4.4.1 Close Pressure Adjustment...
  • Page 17 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 4.5 ASSIST Type - Open / Close Breaking & Sensing Function Plug No.1 Adjustment 2 pin / White Plug No.2 Adjustment 3 pin / Black Plug No.3 – Close Pressure 2 pin / Black 4.5.1 Close Pressure Adjustment...

  • Page 18: Troubleshooting

    MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 5. Trouble Shooting Problem Possible Solution Check wiring or power source. Wire to controller is Does not power on. LED does not light. disconnected? E-Lock Error. Wire to E-Lock is disconnected?
  • Page 19 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR MM50 & MM80 – Harness Wiring & Connections A. ACTIVATION SIGNAL INPUT RED = ACTIVATION (SS) GREEN = COM WHITE – 100VDC (Japan Only) BLACK – 100VDC (Japan Only) B. THRESHOLD SAFETY SIGNAL INPUT RED –...
  • Page 20 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR Basic Wiring – Single & Bi-Part - Activation & Safety Vi-Parting Synchronization (Bi-Part) Page 20...
  • Page 21 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR Vi-Parting Synchronization (Bi-Part) or Individual Operation by Switch Notes: When door is synchronized using Vi-Parting connection, it is possible to include a switch to change operation for Single Door use. SWITCH ON = Synchronization | SWITCH OFF = Individual Interlock Notes: Door 1 will not open if door 2 is open.
  • Page 22 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR Closed End Output Signal – Digital Counter (Option) Wiring: Yellow – Closed End Signal Blue – Com (Closed End Signal) Load Capacity: 0.3A AC125V / 1A / DC24V Security Wiring (Option) – Access Control Notes: Door will open and close when access is authorized from card reader, keypad or other security system.
  • Page 23 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR Security Wiring (Option) – Timer Notes: Door will open and close by activation only during pre-set time. Security Wiring (Option) – Timer Access Notes: Entering room is restricted with timer device. Exit from room is allowed.
  • Page 24 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 6.2 Applicable Door Size Rail Length (mm) Entrance Width (mm) MM50 & MM80 1666 / 1925 / Single - Left / Standard Size Option 2232 / 2512 / 833 / 962.5 / 1116 / 1256 / 1355...
  • Page 25 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 8. Health & Safety It is recommended that the following installation guide lines be followed in compliance with safety standards. 8.1 Safety During the Open Cycle Provision should be made to deter person from occupying the area through which the door travels during the open cycle.
  • Page 26 MODEL: EDM MM50 & MM80 MAGNETIC LINEAR SLIDING DOOR OPERATOR 8.4 Installation Check List It is recommended that the following is carried out by the authorised technician and that the following information is provided during installation commissioning and at each annual safety inspection. We therefore provide the basis for such checks to be carried out in compliance with safety standards.

This manual is also suitable for:

Edm mm80
