Enwork Zori Assembly Instructions Manual
Media cart
Hide thumbs
Also See for Zori:
- Installation manual (5 pages) ,
- Installation instructions manual (23 pages) ,
- Installation manual (7 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Enwork Zori
Summary of Contents for Enwork Zori
- Page 1 Zori Media Cart Assembly Instructions Zori Media Cart Installation Guide rev A...
- Page 2 INSTALLATION GUIDE 1) Parts and Fasteners Included 1/4-20 x 2in. Flat Head Screw #10 x 1-1/4 Button Head Screw...
-
Page 3: Tools And Supplies Required
INSTALLATION GUIDE 2) Tools and Supplies Required Phillips Head Screw Driver... -
Page 4: Assembly Overview
INSTALLATION GUIDE 3) Assembly Overview Fig #1 Frame Assembly Fig #2 Credenza Assembly Fig. #3 Base Frame Assembly Fig. #4 Power Unit (specific unit may vary) - Page 5 INSTALLATION GUIDE Media Table Assembly 4) Assembly: • Lay the Credenza Assembly(Fig.#1) top face down on a non-marring surface. Fig.#4 • Place the Base Frame Assembly(Fig.#3) on the bottom panel, spaced evenly from all sides . • Attach the base frame to the bottom panel using the included (16) #10 x 1-1/4 Button Head Screws.
- Page 6 INSTALLATION GUIDE Media Table Assembly 4) Assembly: • Place the Frame Assembly(Fig.#1)on top of the Credenza Assembly/Base Frame Assembly(Fig.#5). • Align the frame holes with the predrilled holes on the Credenza. Fig.#4 • Start to thread the (8) 1/4-20 x 2in. Flat Head Screw but do not tighten until all the screws are loosely placed.
- Page 7 12900 Christopher Drive Lowell, MI 49331 800.815.7251 www.enwork.com Specifications subject to change without notice.
