Summary of Contents for SharpX QUATTRO HS
- Page 1 Instructi o ns SharpX QUATTRO / HS Machine No.: Keep for future use! Issue date: SharpX QUATTRO SharpX QUATTRO HS Manufacturer: ® SHARPX AB Box 287. S 59123 Motala SWEDEN Phone / Fax: +46 (0) 141 57929 Email: info@sharpx.se www.sharpx.se...
-
Page 2: Table Of Contents
………………………………………………..6 1.5….Overview..…………………………………..7 1.6….Technical data and dimensions…………..8 2……Getting started……………………………...9 2.1….Unpacking and checking of package Content………………………………………..9 2.2….Installation…………………………………..9 2.3….Electrical connection………………………...9 2.4….Wet sharpening (type QUATTRO HS)….. 9 3……Cleaning……………………………………...9 4……Operation…………………………………...10 4.1….Safety guidelines…………………………...10 4.2….Tips for sharpening and polishing………...11 4.2.1..Sharpening………………………………….12 4.2.2..Polishing…………………………………….13 5……Maintenance / replacement of wear &... -
Page 3: General
This symbol stands for a requirement This machine is solely intended for sharpening or result of an action. of clean knives. Any other use of the SharpX could constitute a hazard and is prohibited. Setup and instructions performed by your ―... -
Page 4: Description And Characteristics
High resilience and edge retention of the blade can only be obtained by a convex edge. No dirt accumulation of the work environment ― since dust is collected by magnets. The water cooling system for model SharpX ― QUATTRO prevents overheating of the blade. -
Page 5: Safety Guidelines
Safety guidelines 8. Wear appropriate clothing Safety guidelines according to EN 61029-1:2010 Do not wear loose fitting clothes or jewelry ― 1. Keep your work area in good order which may get caught by moving parts. Cluttered work areas may cause accidents. ―... - Page 6 15. Avoid accidental start-up 18. Attention Make sure that machine is switched off when Only use replacement parts recommended by ― ― connecting plug to power outlet. the manufacturer. 16. Pay attention The use of other inserts and accessories may ―...
-
Page 7: Overview
Handle for exchange of Electric motor grinding unit (120 W) Tooth belt/pulley (for increased speed) Excentric (turns, U < 6000 min creates vibration) Knife handle support Typ SharpX QUATTRO / HS 190 mm 150 mm 515 mm 550mm 250mm 570 mm... -
Page 8: Technical Data And Dimensions
Technical data and dimensions SharpX QUATTRO SharpX QUATTRO HS Power supply 230V 50 Hz AC 230V, 50 Hz AC Special voltage 110 V, 60 Hz, 120 W 110 V, 60 Hz, 120 W Rated power 120 W 120 W Current... -
Page 9: Getting Started
Remove and clean the grinding parts. Installation Remove the gable with use of the supplied Allen The SharpX may only be operated in a dry key and clean the grinding space. working area separated from food. Please make After cleaning inside the grinding house mount sure that: the gable back in place. -
Page 10: Operation
Safety guidelines Before using the SharpX, please follow the following safety guidelines: Concentrate on your work ― Do not talk to other persons ―... -
Page 11: Tips For Sharpening And Polishing
Choose newer knives when grinding with the diamond grinding wheel. The first time the knife is ground in SharpX, more grindings are required until the knife edge is in the correct shape. Knives, which have been grinded many times on other systems, usually have a knife edge that has different grinding angles as well as an edge that is not centered. -
Page 12: 4.2.1 Sharpening
Start the machine (as well as the water pump. Make sure that water spills on the grinding wheels. (SharpX QUATTRO HS) Press the knife blade into the slot with a pressure of about 1 kg. Start at the handle. Simultaneously pull the knife steadily towards you through the wheel, with a speed of about 2 sec. for a regular-length knife. -
Page 13: Polishing
The knife edge now has a centred, ultimate, convex form and the knife is ready to use. RE-GEGROUND / SHARPENING When the knife is grinded in SharpX, you do not need to grind the knife every time. Sharpening is enough to restore the sharpness. -
Page 14: Maintenance / Replacement Of Wear & Tear Parts
Maintenance / replacement of wear & tear parts Important information Maintenance / replacement of wear & tear parts. Page 15. When you notice that the result after grinding is not satisfactory it is time to change the diamond grinding wheel and diamond block. Contact your retailer to order replacement diamond wheel and diamond block. -
Page 15: Changing Of Grinding Wheels
7. Caution: it may jump out. Risk of injury. Hook arm 8. Remove interlocking grinding wheels without using force. 9. Repeat steps 4 and 5 for types SharpX QUATTRO / HS. 10. Slide new grinding wheels with rubber ring on the shaft. -
Page 16: Changing Of Polishing Elements
Changing of polishing elements 19 - 20. Open swivel-mounted cover. 21. Carefully pass through screwdriver between spring and polishing element. 22. Lift spring upward until completely released. 23. Remove polishing element. 24. Repeat steps 21 and 22 for each polishing element to be exchanged. -
Page 17: Spare Parts
Spare parts... -
Page 19: Electrical Circuit Diagrams
Electrical diagram... -
Page 20: Ec Declaration Of Conformity
Manufacturer: ® SHARPX AB Box 287. S 59123 Motala SWEDEN Phone / Fax: +46 (0) 141 57929 Email: info@sharpx.se www.sharpx.se EC declaration of conformity in accordance with EC Machinery Directive 2006/42/EC, attachment II A We hereby declare that, due to its design and type as well as the version placed on the market by us, the machine described below is conform with corresponding essential safety and health requirements of the relevant EC directives.
