- Page 1 DG-WU2008 User Manual V1.0 2019-06-13 As our products undergo continuous development the specifications are subject to change without prior notice...
- Page 2 Please check with your local distributors for latest information. No part of this document can be copied or reproduced in any form without written consent from the company. Trademark DIGISOL TM is a trademark of Digisol Systems Ltd. All other trademarks are the property of the respective manufacturers.
-
Page 3: Table Of Contents
DG-WU2008 User Manual Table of Contents CHAPTER 1 INTRODUCTION ............................6 1.1 O .....................................6 VERVIEW 1.2 G ........................7 AMILIAR WITH YOUR NEW ONTROLLER 1.3 P ..................................7 ACKAGE ONTENT CHAPTER 2: HARDWARE INTRODUCTION ......................8 : ......................................8 ARDWARE CHAPTER 3: LOGIN WEB NETWORK MANAGEMENT ................... 9 CHAPTER 4: WEB GUI CONFIGURATION ....................... - Page 4 DG-WU2008 User Manual 4.5 AUTH INTERNET ACCESS ............................ 27 4.5.1 A .................................. 27 ONFIGURE 4.5.1..............................27 UTHENTICATION 4.5.1..............................29 ORTAL UTHENTICATION 4.5.1. IP A ................................. 31 UTHENTICATION 4.5.1. MAC A ..............................32 UTHENTICATION 4.5.1................................... 32 ADIUS ILLING 4.5.1.
- Page 5 DG-WU2008 User Manual 4.10.1 PPTP ..................................... 48 4.10.1. PPTP VPN S ................................ 48 ERVER 4.10.1. PPTP VPN A ............................49 CCESS TATUS 4.10.2 L2TP ..................................... 50 4.10.2. L2TP VPN S ................................ 50 ERVER 4.10.2. L2TP VPN A ............................51 CCESS TATUS 4.10.3 VTUNS ....................................
-
Page 6: Chapter 1 Introduction
DG-WU2008 User Manual Chapter 1 Introduction 1.1 Overview DG-WU2008 is a CAPWAP based WLAN Controller with main functions as Router, AC Controller, Management, VLAN Management functions. When worked as a router, it can access into 512 end users, to do advertisement and captive portal authentication. -
Page 7: Get Familiar With Your New Controller
This controller has individual IP address on each LAN port. For first time installation, connect PC to LAN1 port of controller. Default username/ password is admin/ admin. 1.3 Package Content DG-WU2008 WLAN Controller Power Cable Rack Mount Kit... -
Page 8: Chapter 2: Hardware Introduction
DG-WU2008 User Manual Chapter 2: Hardware Introduction Hardware: WAN1: WAN Port in Default mode. WAN2/LAN5; WAN3/LAN4; WAN4/LAN3, LAN2: LAN Ports in default mode, but can set up as WAN ports in gateway operation mode based on requirement. LAN1: LAN Port as default CONSOLE;... -
Page 9: Chapter 3: Login Web Network Management
DG-WU2008 User Manual Chapter 3: Login Web Network Management The default IP address of device is 172.16.0.1. Connect the PC to controller & PC will obtain the IP address directly from AC controller DHCP server. Input AC Controller’s IP address http://172.16.0.1:2011 into browser. It will display the below page. -
Page 10: Chapter 4: Web Gui Configuration
DG-WU2008 User Manual Chapter 4: WEB GUI Configuration After logged into AC controller, following home page will be displayed: 4.1 System Status 4.1.a Device Info Display general information of Controller. Network Interface Status: It displays the active interface port connectivity status, Link Speed, IP address, Mac Address, Receive/ Send speed. -
Page 11: B Interface Status
DG-WU2008 User Manual 4.1.b Interface Status Displays controller LAN/ WAN interface detail (Upstream/ Downstream bandwidth(KB), IP Address, Status, total Upstream/ downstream speed(KB/S), Flow(MB) If you click Operation icon, it will display the respective interface detail as shown below: Line Detection... -
Page 12: Lan Ip Flow
DG-WU2008 User Manual 4.1.c LAN IP Flow You can view the connected User sessions under this option. Click on desired User IP address to view the session logs: 4.1.d Application Flow Display the user running applications flow chart. -
Page 13: Network Configure
DG-WU2008 User Manual 4.2 Network Configure 4.2.a Interface Configure Under this tab you can configure WAN settings, DHCP Server configuration on each LAN port (172.x.x.x), Configurable WAN/ LAN port as per requirement & sub-interface for VLAN configuration. This tab options are described as below:- 4.2.a.1 WAN Configure... -
Page 14: Lan/ Dhcp
DG-WU2008 User Manual 4.2.a.2 LAN/ DHCP You can configure DHCP Server for respective LAN port under this tab. Every LAN port have different IP network. By default DHCP Server is enabled only on LAN1 interface. Similarly, you can enable/ disable DHCP Server for other LAN interface if required. -
Page 15: Physical Port Definition
DG-WU2008 User Manual 4.2.a.3 Physical Port Definition LAN1 & WAN1 are default ports. Rest all are configurable into LAN/ WAN port as per the requirement. You can set desired LAN & WAN port combination under this tab. 4.2.a.4 Subinterface Configure You can use this option to create different VLAN for connected AP or Wi-Fi Users. -
Page 16: B Route Rule
DG-WU2008 User Manual 4.2.b Route Rule 4.2.b.1 Multi-line Deversion Rules You can use this option if multiple WAN is terminating on controller. You can set session shunt, source IP shunt and source IP +destination IP for some specific network traffic depending on desired WAN connection to minimize the internet utilization. -
Page 17: Static Route
DG-WU2008 User Manual 4.2.b.2 Static Route 4.2.b.2.1 Static Routing You can manually add static route to this device to define the path selection of traffic from one interface to another. 4.2.b.2.2 Routing Information Displays the routing rule enabled on the controller under this tab. -
Page 18: C Ddns
DG-WU2008 User Manual 4.2.c DDNS Dynamic DNS (DDNS) is an Internet service that allows controller with varying public IP addresses to be located using Internet domain names . To use DDNS, you must setup an account with a DDNS provider such as DynDNS.org,etc. When you set up an account with a DDNS service, the host &... -
Page 19: D Nat/ Port Forwarding
DG-WU2008 User Manual 4.2.d NAT/ Port forwarding By default, the firewall of a controller blocks all connection attempts by devices on the Internet to devices in your local network. This is called inbound traffic. If you want devices on the Internet to connect to devices on your local network (for example, you have an IP Camera or an FTP server that you want to be accessible via the Internet), you will have to open the desired ports on controller. -
Page 20: Dmz Host
DG-WU2008 User Manual 4.2.d.2 DMZ Host If you use a DMZ to forward all inbound traffic to a device in you local network, that device loses all the protection of the device's firewall & It is totally exposed to the Internet. -
Page 21: Dst Nat
DG-WU2008 User Manual 4.2.d.4 Dst NAT You can add a Destination NAT rule under this tab. 4.3 Flow Control Policy 4.3.1 Smart Flow Control Under this tab you can set/ define bandwidth for respective WAN interface. -
Page 22: Bandwidth Control
DG-WU2008 User Manual 4.3.2 Bandwidth Control You can define/ limit the bandwidth for specific Address Pool or User under this option. Set the Upstream/ Downstream limit in KB/S. 4.3.3 Free Flow Control You can define IP pool under this tab for Free Flow control. -
Page 23: Ac Management
DG-WU2008 User Manual 4.4 AC Management The wireless controller can discover peer wireless AP regardless of whether these devices are connected to each other, located in the same Layer 2 broadcast domain, or attached to different IP subnet. When the controller discovers and validates AP, the controller takes over the management of the AP. - Page 24 DG-WU2008 User Manual All Device: Show the complete list of wireless AP connected to this controller Online Device: Show the list of wireless AP which are online Offline Device: Show the list of wireless AP which are offline Device Model Filter: Select the desired model from filter list to display same model AP Search Conditions: Search the wireless AP by IP address, MAC address, Device Name, Device Model &...
-
Page 25: Ap Configure Template
DG-WU2008 User Manual 4.4.2 AP Configure Template Click ‘Add’ to create a template on controller. It will list the connected model in drop down menu. Just select the desired model & confirm the settings. Once you confirm the settings, it will list the template. Click on Config to configure the Wireless settings for respective AP model. -
Page 26: Ap Upgrade
DG-WU2008 User Manual Select the AP from the list & click on ‘Apply Configuration Template’ to push the configuration. After applying the template, you can view the updated AP configuration under AP List. 4.4.3 AP Upgrade You can view the current firmware version of connected AP’s & latest if any under this option. -
Page 27: Auth Internet Access
DG-WU2008 User Manual 4.5 Auth Internet Access 4.5.1 Auth Configure You can configure four type of Authentication Method for specific LAN interface/ Sub-interface if any on this controller for Internet access. 1. PPPoE Authentication 3. IP Authentication 2. Portal Authentication 4. - Page 28 DG-WU2008 User Manual You can configure advanced setting for PPPoE Auth under this option as shown below:- Now create a User account for PPPoE Auth Method under User Management>>Auth User tab. The users connected through LAN1 interface will not be able to access the internet until and...
-
Page 29: B Portal Authentication
DG-WU2008 User Manual Once user get connected through PPPoE dialer will be listed under Access Status tab in PPPoE Auth option on controller. You can disconnect the PPPoE client from web GUI itself by clicking the icon highlighted below:-. 4.5.1.b Portal Authentication... - Page 30 DG-WU2008 User Manual Click on Portal Auth tab to configure further settings. You can customize the Web Login page by uploading the images as desired under “Customize Auth Page”. Create a User account for Portal Auth Method under User Management>>Auth User tab.
-
Page 31: Ip Authentication
DG-WU2008 User Manual Enter the username/ password created for Web authentication on controller to go online. 4.5.1.c IP Authentication You can allow/ limit certain IP address to desired LAN interface of controller using this method. You need to create User Account with desired IP address under User Management>>Auth... -
Page 32: Mac Authentication
DG-WU2008 User Manual 4.5.1.d MAC Authentication You can allow/ limit certain MAC address to desired LAN interface of controller using this method. You need to create User Account with desired IP address under User Management>>Auth User tab. NOTE: You can set the schedule for defined Users to allow internet access for limited time period under all 4 authentication methods. -
Page 33: F Notify Page
DG-WU2008 User Manual 4.5.1.f Notify Page You can define a notification page under this tab. 4.5.2 User Management 4.5.2.a Auth User You can create the desired User Account for PPPoE Dial UP/ IP Address Auth/ MAC Address Auth/ Web Auth & VPN Dial UP under this tab. -
Page 34: B Auth User Status
DG-WU2008 User Manual It will display the created users list as shown below:- 4.5.2.b Auth User Status It displays the user Online/ Offline status along with uptime. It will display the user session & details once you click on desired user from the list. -
Page 35: C Department / Level Definition
DG-WU2008 User Manual User Flow & Link Track You can view the connected User Sessions & speed in graphical format. User Auth Log: It will display the authenticated user status. 4.5.2.c Department/ Level Definition You can define multiple departments under this tab to isolate the users if any. -
Page 36: Behavior Control
DG-WU2008 User Manual You can define different Levels under this tab for users if any. 4.6 Behavior Control 4.6.1 Application firewall You can create firewall rule/ policy for Specific Address/ User/ Level or Department under this tab. You can create object for Time/ Destination IP/Destination Port/ Application under “Object Management”. -
Page 37: Url Redirect
DG-WU2008 User Manual 4.6.2 URL Redirect You can redirect any url to defined site on controller. 4.6.3 Domain Redirect You can redirect any domain to defined fixed IP on controller. -
Page 38: Message Push Configure
DG-WU2008 User Manual 4.6.4 Message Push Configure You can configure message push settings under this tab. -
Page 39: Object Management
DG-WU2008 User Manual 4.7 Object Management 4.7.1 Basic Object You can create basic object of Time, Source IP, Port & Destination IP under this tab. 4.7.1.a Time Object By default one object already exist on controller for any time. If you want to define a rule/ policy for specific time slot, you can create a Time object as Shown below:- 4.7.1.b Source IP Object... -
Page 40: C Port Object
DG-WU2008 User Manual 4.7.1.c Port Object There are some predefined Port Object already created on Controller by default. You can create an object for any customized port if required, under this tab. 4.7.1.d Destination IP Object You can create an object for any online destination address if required, under this tab. -
Page 41: Application Object
DG-WU2008 User Manual 4.7.2 Application Object You can create application based object under this tab. 4.7.2.1 Built-in Application Object 4.7.2.1.a Built-in App Object Upgrade By default there are certain built-in application objects in controller. You can Upgrade the built-in object library under this tab. -
Page 42: Custom Application Object
DG-WU2008 User Manual 4.7.2.2 Custom Application Object 4.7.2.2.a Customize App Object You can create new object under Custom which is not listed in built-in app object. 4.7.2.2.b Define App by Domain You can create new object based on Domain under this tab. -
Page 43: C Define App By Objective Ip + Port
DG-WU2008 User Manual 4.7.2.2.c Define App by Objective IP + Port You can define Local User IP Pool for respective customized object under this tab. 4.8 Safety Protection 4.8.1 IP-MAC Binding You can bind IP address for respective MAC Address under this tab. -
Page 44: Connection Quantity Limit
DG-WU2008 User Manual 4.8.2 Connection Quantity Limit You can define the concurrent TCP/ UDP connection for respective Address, User, Level or on department basis. 4.8.3 LAN Abnormal Detection You can enable DHCP Detection, Loop Detection or PPPoE detection feature under this tab. -
Page 45: Lan Attack Protection
DG-WU2008 User Manual 4.8.4 LAN Attack Protection You can set the packet threshold for respective LAN interface under this tab. 4.8.5 WAN Ping Forbid/ WAN Login You can forbid remote ping, remote management of controller & close telnet service under this tab. -
Page 46: Log Record
DG-WU2008 User Manual 4.9 Log Record 4.9.1 Log Parameters You can select below option to store the logs to internal memory but after reboot, it will clear the logs You can specify Log Server IP if any, under this tab. -
Page 47: Online User Log
DG-WU2008 User Manual 4.9.3 Online User Log Here you can view the number of online Users at specific time interval in graphical format 4.9.4 Interface Flow Log Here you can view the upstream/ downstream rate of respective Interface at specific time... -
Page 48: System Log
DG-WU2008 User Manual 4.9.5 System Log You can view the system logs under this tab. 4.10 VPN You can configure following VPN connectivity on this controller. 4.10.1 PPTP 4.10.1.a PPTP VPN Server Configure PPTP Connectivity as shown below:-... -
Page 49: Bpptp Vpn Access Status
DG-WU2008 User Manual Once PPTP Server is configured, create a User for VPN Dial-UP under “Auth User”. 4.10.1.b PPTP VPN Access Status You can view the PPTP connectivity status under this option. You can also disconnect the connected user using the GUI. -
Page 50: L2Tp
DG-WU2008 User Manual 4.10.2 L2TP 4.10.2.a L2TP VPN Server Configure L2TP Connectivity as shown below:- Once L2TP Server is configured, create a New User or you can use the same user account Configured for VPN Dial-UP under “Auth User”. -
Page 51: B L2Tp Vpn Access Status
DG-WU2008 User Manual 4.10.2.b L2TP VPN Access Status You can view the L2TP connectivity status under this option. You can also disconnect the connected user using the GUI. 4.10.3 VTUNS 4.10.3.1 VTUNS Configure You can configure Server-Client Tunnel using this option on controller. You would require controller at the remote site as well to form VTUNS. -
Page 52: B Tunnel Management
DG-WU2008 User Manual 4.10.3.1.b Tunnel Management You need to define a Tunnel Name, ID & remote local network along with netmask under this tab. On Remote Controller, you need to set it as VPN Dialing Client. Enter the other controller IP as... -
Page 53: Vtuns Status
DG-WU2008 User Manual 4.10.3.2 VTUNS Status You can view the VTUNS status under this tab. 4.11 BPN (This feature is for future use) 4.11.a BPN Server You can configure BPN Server under this tab. -
Page 54: Bbpn Access Status
DG-WU2008 User Manual 4.11.b BPN Access Status You can view the BPN Status under this option. 4.12 Device Maintenance 4.12.a Firmware Upgrade You can upgrade the firmware on controller using this option. -
Page 55: B Modify Password
DG-WU2008 User Manual 4.12.b Modify Password You can set the management password under this tab. 4.12.c Ping Detection Here you can check the ping to respective WAN interface under this tab. -
Page 56: D Configure File Maintenance
DG-WU2008 User Manual Here you can check the ping to multiple interfaces at a time. 4.12.d Configure File Maintenance Here you can import/ export controller configuration settings. You can reset the controller to default settings. -
Page 57: E Restart Device
DG-WU2008 User Manual You can backup the configuration to Email ID. 4.12.e Restart Device You can reboot the device or Power it OFF under this option. -
Page 58: F Timed Task
DG-WU2008 User Manual 4.12.f Timed Task You can define a timed task under this option. 4.12.g Time Synchronization You can define a Time Server under this option. -
Page 59: H Cloud Configure (For Future Use )
DG-WU2008 User Manual 4.12.h Cloud Configure (For Future Use) You can configure cloud settings under this option. You can also change the Management password by clicking this option. To logout the Web Interface, click the highlighted tab. -
Page 60: Chapter 5 Troubleshooting
DG-WU2008 User Manual CHAPTER 5 Troubleshooting This Chapter provides solutions to problems for the installation and operation of the Wireless Access Controller. You can refer to the following if you are having problems. 1 Why can’t I configure the controller even when the cable is plugged and the LED is lit? Do a Ping test to make sure that the Wireless Access Controller is responding. - Page 61 DG-WU2008 User Manual Ensure that your Ethernet Adapter is working, and that all network drivers are installed properly. Network adapter names will vary depending on your specific adapter. The installation steps listed below are applicable for all network adapters. Go to Start > Right click on “My Computer” > Properties .
-
Page 62: Ido If My Ethernet Connection Does Not Work Properly
If the connection still does not work properly, then you can reset it to default. This product comes with One Year warranty. For further details about warranty policy and Product Registration, please visit support section of www.digisol.com...
