- Page 1 DUAL STEPPED CV/GATE RECORDER BUILDING GUIDE...
-
Page 2: Table Of Contents
Table of Contents 01. Components List + Tools 02. Panel Sides 03. Important Note 04. Step by Step Assembly 04_1. Diodes 04_2. Flat Resistors 04_3. Capacitors 04_4. Quartz 04_5. 78L05 04_6. Standing Resistors 04_7. Jack Connectors 04_8. IC Sockets 04_9. Power Supply Header 04_10. -
Page 3: Components List + Tools
01. Components List + Tools Switches Resistors LEDs X4 — Pack 3/5 S1 → S4 6,8 kΩ Green LED Switches Nuts X14 — Pack 1/5 X2 — Pack 2/5 x12 on V2 kit L1, L2 X4 — Pack 4/5 On switches 100 kΩ... -
Page 4: Panel Sides
02. Panel Sides SHAKMAT MODULAR BISHOP’S MISCELLANY V1.1 Front Rear The front of the PCB is the one with the switches, jack connectors and potentiometers on it. The top of the board is the connectors side, the bottom is the switches side. Almost all the components goes to the front of the PCB. -
Page 5: Important Note
03. Important Note If you feel you're going to build this kit without looking at the steps, just remember this : don't solder the switches without placing them into the front panel first. If you don't want the final PCB & front panel assembly becoming a real pain, do this, seriously. -
Page 6: 04_2. Flat Resistors
04_2. Flat Resistors Here's a picture of the PCB with placement of the flat resistors by value. There’s no polarity to observe with resistors, so you can solder them no matter the way. Once soldered, you’ve to cut the excess of the resistor legs with a pair of cutting p!iers. -
Page 7: 04_4. Quartz
04_4. Quartz The quartz has to lay flat and fits the shape on the PCB silkscreen. Pack 2/5 16 MHz 04_5. 78L05 Bend the middle leg of the 78L05, then place the component on the PCB, like shown on the silkscreen. Pack 2/5 78L05 04_6. -
Page 8: 04_7. Jack Connectors
Jack 04_8. IC Sockets Now, let’s flip the PCB and solder the three IC’s sockets. Be attentive SHAKMAT MODULAR to their orientation. The notch on BISHOP’S MISCELLANY V1.1 the silkscreen (marked in red on the picture) as to match the notch on the socket. -
Page 9: 04_9. Power Supply Header
04_9. Power Supply Header Solder only one leg of the header, verify that it’s flush with the PCB & then solder the 9 other legs. Pack 3/5 Header 04_10. Potentiometers Let's go back to the front side. First you'll have to remove a little bit of metal on the potentiometer as shown in the picture. - Page 10 04_11. Switches First, finger tighten the switches on the panel with their nuts. Then assemble the panel with the PCB while the switches are mounted. Finally solder the legs. 04_12. LEDs Remove the front panel, put the LEDs into place in the PCB. Be very careful to get them the right way around.
- Page 11 SHAKMAT MODULAR BISHOP’S MISCELLANY V1.1 04_13. ICs Plug the IC’s in thieir sockets, make sure their orientations matches the socket orientation. 04_14. Testing Now let's have a visual test : is everything correctly soldered ? Are the diodes orientation right ? Are the IC’s orientation OK ? Is there any...
- Page 12 If ever you get some troubles or questions, send us an email at support@shakmatmodular.com. To download the Bishop’s Miscellany Operation Manual, go to our website (address below) and navigate to the support section. There are two different firmware available for the Bishop’s Miscellany. V1.0 to v1.2 all operate the same way but the 2.0 firmware introduces some new functionnalities &...
