- Page 1 Shakmat Clock O’Pawn 6HP Eurorack Module Built & designed in E.U. www.shakmat.com...
- Page 2 Introduction The Clock O’Pawn is a useful clock sourcing device that performs as your system’s true chef d’orchestre. Its transport section lets you start, stop, and reset connected instruments which are synchronised to an intuitive internal clock source or dancing along with your analogue and MIDI equipment. If you get bored by a metronomous clock, turn up the swing function and the maestro will lead with a nice shuffled feel ! Clock input...
- Page 4 Setting the BPM CLK1 produces a 1/16th note clock signal, which is generated either by internal (BPM / Tap Tempo) or external clock sources (analogue clock / MIDI). The BPM potentiometer allows fast access to a broad range of BPMs. To tap the tempo, hold the CLK2/EXT button tap in 4 quarter notes on the Play button [G].
- Page 5 Swing Turning the Swing potentiometer adds shuffle to the clock signal. This allows to obtain a feel between binary and ternary, as performed by jazz musicians. When the potentiometer is turned fully clockwise, the module puts out a triplet clock. Second output Depending on its state, the CLK2 output produces an...
-
Page 6: Specifications
Trigger Inputs 6 HP 0 - 5V Depth Outputs 27 mm 0 - 5V Current Draw 10 mA @ 12V www.shakmat.com Product design & engineering : François Gaspard Product & brand design : Steve Hackx Firmware coding : Léonard Steyaert...
