FOR CLARITY PURPOSE, THE GLASS SHELVES WILL
BE SHOWN AS IF WE CAN SEE THROUGH THEM.
POUR DES RAISONS DE CLARTÉ, LES TABLETTES DE
VERRE SERONT MONTRÉES COMME SI L'ON VOYAIT
AU TRAVERS.
PARA EL OBJETIVO DE CLARIDAD, LAS TABLAS DE
VIDRIO SERÁN MOSTRADAS COMO SI SE VIERA A
TRAVÉS.
KEY
PART NAME / NOM DE LA PIÈCE / NOMBRE DE LA PIEZA
CLÉ
CVE
1
LEFT FRONT MOULDING / MOULURE AVANT GAUCHE / Moldura delantera izquierda
2
RIGHT FRONT MOULDING / MOULURE AVANT DROITE / Moldura delantera derecha
3
BACK PANEL / PANNEAU ARRIÈRE / Panel trasero
4
CROSS BAR / TRAVERSE / Travezaño
5
FRAME / TRAVERSE / Travezaño
6
SUPPORT (MIDDLE) / SUPPORT (CENTRE) / Soporte (central)
7
SUPPORT (BOTTOM) / SUPPORT INFÉRIEUR / Soporte inferior
8
GLASS SHELF (TOP) / TABLETTE SUPÉRIEURE DE VERRE / Tabla superiore de vidrio
9
GLASS SHELF / TABLETTE DE VERRE / Tabla de vidrio
QTY
PART NAME / NOM DE LA PIÈCE / NOMBRE DE LA PIEZA
QTÉ
CANT
2
METAL FITTING / RACCORD EN MÉTAL / Pieza de ajuste metalicá
2
SCREW BOLT / VIS BOULON / Tornillo perno
12
GLASS CUSHION / COUSSINET / Cojinete
10
SCREW / VIS / Tornillo
2
SCREW / VIS / Tornillo
5
ADJUSTABLE GLIDE / PATIN AJUSTABLE / Pata ajustable
6
SCREW / VIS / Tornillo
1
ALLEN KEY / CLÉ HEXAGONALE / Llave hexagonal
2
SCREW / VIS / Tornillo
4
SCREW / VIS / Tornillo
4
WIRE MANAGER STRAP / COURROIE POUR FILS / Correa para cable
BCE72
QTY
QTÉ
CANT
1
IMLFL0010-BP
1
IMLFR0010-BP
1
IBACS0135-PKPK
2
1
1
1
1
IGL0111-BN
2
IGL0112-BN
PART No
No PIÈCE
PARTE No
IHA0435
IHA0436
IHA0437
IFA0139
IFA0142
IHA0434
IFA0140
4.0mm
IHA0352
IFA0161
IFA0155
IHA0455
LABEL
PART No
REV.
No PIÈCE
PARTE No
0
0
0
0
IMC0170
IMC0241
0
IMC0242
0
0
IMC0243
0
0
HOW TO CLEAN :
Do not place this product near a heat source, such
as a radiator, or in direct sunlight.
Clean the product periodically with a soft cloth.
If finger prints, food and beverage stains, etc. are
difficult to remove, use a cloth moistened with a
mild non-abrasive detergent solution.
Do not use scouring powder, abrasive pad or solvent.

ENTRETIEN :

Ne placer pas ce meuble près d'une source de chaleur,
tel qu'un calorifère ou directement au soleil.
Utilisez toujours un chiffon humide pour nettoyer le meuble.
Pour enlever les traces plus difficiles, utilisez un chiffon
avec un savon non-abrasif.
Ne pas utiliser de poudre à récurer, de tampon abrasif
ni de solvant.
LIMPIEZA :
No coloque este producto cerca de un afuente de calor,
tales como un radiador ò directamente bajo la luz del sol.
Limpie el producto periódicamente con un paño suave.
Si las manchas de huellas digitales, comida, bedida, etc.
resultan dificiles de quitar, utilice un paño húmedecido
con una solución de detergente suave sin corrosivos.
No utilice detergente en polvo, ningun material abrasico
ò solvente.

TOOLS REQUIRED

(NOT INCLUDED)

OUTILS REQUIS

(NON INCLUS)
HERRAMIENTAS
NECESARIAS
(NO INCLUIDAS)
