Sonos, Inc. Sonos and all other Sonos product names and slogans are trademarks or registered trademarks of Sonos, Inc. Sonos Reg. U.S. Pat. & Tm. Off.
If you’re using a computer, get the app at www.sonos.com/support/downloads. For the latest system requirements and compatible audio formats, go to http://faq.sonos.com/specs. Note: Sonos recommends using the Sonos app on a mobile device instead of a computer for setup. Already have Sonos? You can easily add new speakers anytime (up to 32).
• Keep both ends of the Playbar at least 1' (30cm) from a wall or other obstruction. Wall mounted Use the Playbar wall mount kit. You can buy it on www.sonos.com. Follow the instructions in the kit. See Wall mounting for instructions.
IMPORTANT: Remove the protective caps from each end of the optical audio cable before inserting. Playbar’s Digital Audio IN (optical) Attach the power adapter to the Playbar and apply power. Push the power cord firmly into the Playbar until it is flush with the surface.
Page 6
The speaker status light on the right side flashes. Play/Pause Status light Volume up Volume down Explore Playbar IR sensor light Play/Pause Status light Volume up IR sensor light Volume down Note: The grill cloth is not removable. Tampering with the cloth may damage your Playbar.
IR (InfraRed) Sensors / Signal Lights The IR sensor receives signals sent by a remote control. When the Playbar receives a volume or mute command, the IR light displays momentarily. You can adjust this setting so the light never displays. See IR signal light.
Use the app to change sound settings or modify the way your home theater speaker works with your TV. Refer to the Sonos App for Mobile Devices product guide to get more information about using the Sonos app. Note: You can also use the Sonos app for Mac or PC.
Sonos Playbar TV Autoplay Turn on TV Autoplay (default) so audio plays directly through the home theater speaker when you turn on your If music is playing when you turn on the TV, the music stops and the home theater speaker switches to TV audio.
IR repeater When the Playbar is placed in front of your TV on a tabletop, it may block the IR sensor on your TV. The IR repeater setting allows the Playbar to repeat the signal to your TV. This setting is On by default.
• Adjust EQ Play music Playbar can stream music even when the TV is off. If TV Autoplay is On, the music stops and switches to TV audio whenever you turn on the TV. • Radio by TuneIn. Select from more than 100,000 free internet radio stations, podcasts, and shows.
Make sure both have the same orientation (horizontal or vertical). Add a Sub You can pair a Sub with any Sonos speaker or amplified component. On a mobile device: > Settings > Room Settings.
Turn On or Off. Adjustment (phase) On a computer: Select Manage > Settings (PC) or Sonos > Preferences (Mac). Select Room Settings. Choose the room with the Sub from the Room Settings drop down list. It appears as Room (+Sub).
• If you’re not using it, select Don’t use Sub. It appears in Rooms as Sub (unused) until paired with a speaker. Surround speakers Turn two Sonos speakers (same model) into separate right and left channels for your home theater. If you create a room group or stereo pair instead, you won’t have surround sound. Note:...
From the Basic tab, click Remove Surrounds. Wall mounting You can mount Playbar to a wall above or below a wall-mounted TV. Use the Playbar wall mount kit. You can buy it on www.sonos.com. Follow the instructions in the kit.
Page 16
Product Guide Note: There are 2 spare screws (and anchors) included in the kit. Use these to provide additional reinforcement if you’d like. Tape the template to the wall above or below your TV. Use a level. 2"(50mm) For best audio performance, orient the connector panel AWAY from the TV.
Sonos Playbar Wall mounting information Wall Material Pre Drill Use Wall Anchors Use Screws Wood Stud 1/8" (3mm) bit Drywall (no stud) 3/16" (4.5mm) bit Hard wallboard or double 3/16" (4.5mm) bit board Plaster 1/4" (6.5mm) bit Concrete or Brick 1/8"...
• Did you allow Sonos to check for updates? The Sonos Playbar requires software version 4.0 or later. • Is the power cord properly seated? Be sure to push the power cord firmly into the Playbar until it is flush...
Page 19
Sonos Playbar • If either of these is not the problem, a network issue may be preventing the Playbar from connecting to Sonos. Try moving the Sonos products closer together. Eliminating annoying messages on your TV when using a cable, satellite, or set...
Page 20
• If you are using My Harmony website: • Type Sonos as the manufacturer and Playbar as the model name. If the Sonos Playbar is not in their database, you will be asked to confirm your entry or make another choice.
Using the volume control buttons on your television, turn the TV volume all the way down. Do not use the Mute button. From this point forward use only the volume buttons on your Sonos app to adjust the Playbar’s volume. Your home network Your Sonos speakers and the mobile device with the Sonos app need to be on the same Wi-Fi network.
• Do not place the unit in a small confined space (e.g., closet or cabinet, under a bed or sofa) where ventilation is restricted. Both ends of the Playbar should be at least 1 ft. (30cm) from a wall or other obstruction.
• A lint brush can be used to smooth out visible lines in the fabric. Do not clean fabric with a lint roller. • Clean non-fabric portions of the Playbar only with a dry, soft cloth. Household cleaners or solvents may damage the finish on your Sonos products.
TV with a single cable and plays all sources, including satellite boxes and game consoles. 3.1 Home Theater Pair Playbar with Sub, and with the push of a button you can add spine- curling bass to your cinematic experience—wirelessly. 5.1 Home Theater Add speakers, such as two Play:5s, to your Playbar and Sub for a true surround sound experience.
Page 25
Playbar, AC power cord, optical audio cable, quickstart guide and legal booklet. Multiple Orientations Mount Playbar on the wall either above or below your TV, or lay flat on your TV table. Control Control Playbar volume and mute using your existing TV, cable or universal remote.
We’d love to hear from you! We’ll read your feedback carefully and use it to help us improve our product guides. Write to us at: docfeedback@sonos.com If you’re having a problem with your Sonos system, please contact Customer Care so they can help. Email them at http://www.sonos.com/emailsupport.
