- Page 1 DESIGN & INSTALLATION GUIDE...
-
Page 2: Table Of Contents
1. PURPOSE OF DOCUMENT 1.1. GENERAL This document is intended for designers and installers to ensure that the UNITRAY Safe Tray System is specified and installed correctly. 1.2. SUPPORTING INFORMATION This document must be read in conjunction with the following documents: •... -
Page 3: Unitray Safe Tray System Scope Of Use
6 x 100 mm high elevating posts OF USE (to suit the location of the drainage waste The UNITRAY Safe Tray System is intended for and associated plumbing). Alternatively, the use in all buildings where: UNITRAY Safe Tray System may be placed •... -
Page 4: Handling & Storage
2.5. HANDLING & STORAGE When unpacking, ensure all parts have been supplied. The UNITRAY Safe Tray System comes with the following parts: Adaptors - select the tapered adaptors for standard 15mm and 20mm NZ copper relief drain diameters. NB the adaptors pre-attached to Tundish cap must only be used for smaller diameter pipe such as KemPress™... -
Page 5: Specification
UNITRAY is inverted. ALLOWABLE ELEVATING POST LOCATION PATTERNS The UNITRAY safe tray system is designed and engineer-certified to safely support the load of a full HWC when put together in accordance with the below elevating post locations. MEDIUM TO LARGE UNITRAY TRAY... -
Page 6: Assembling The T-Connector
4.1.2 ASSEMBLING THE T -CONNECTOR Screw the T-Connector securely onto the threaded UNITRAY Safe Tray outlet using thread tape on all male components to ensure a water-tight connection. Ensure that the T-Connector is orientated correctly for the drain location. There are three options for attaching the T-Connector. -
Page 7: Locating The Unitray Safe Tray System & Connecting With The Hwc
Connect the lower outlet of the T-Connector to a drain in accordance with Building Code plumbing requirements. Place the HWC centrally on the UNITRAY Safe Tray System to ensure even weight distribution and spacing between HWC and safe tray wall. - Page 8 UNITRAY Safe Tray System Design & Installation Guide V2 NZ October 2017 www.unitray.co.nz INSTALLATION OPTIONS Visual representation of UNITRAY Safe Tray System installation options. Standard indoor UNITRAY installation Indoor UNITRAY installation using optional elevating post kit Outdoor UNITRAY installation as inverted elevating platform using optional elevating post kit info@unitray.co.nz...
