Summary of Contents for BMW K1200

  • Page 1 Owner’s Manual, ComSystem K1200 LT BMW of North America, LLC Woodcliff Lake, New Jersey 07677-7731...
  • Page 2: Welcome To Bmw

    Welcome to BMW The BMW ComSystem has been developed to provide riders of BMW K 1200 LT models the most advanced sound and communications management system. The ComSystem acts as the foundation, allowing owners to utilize privately purchased portable modular electronic devices suited for the local market such as cell phones, two- way radios and portable music storage devices.
  • Page 3: Safety Notes

    Safety Notes The following symbols are used in this operating manual for safety notes: Danger indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury Caution indicates a potentially hazardous situation or unsafe practice that may cause property damage or may invalidate your vehicle warranty.
  • Page 4 Check the volume control position of your ComSystem prior to use. If in doubt about the correct setting, turn the volume control counter-clockwise to a minimal level prior to turning on ignition to avoid excessively loud volume when the motorcycle ignition is turned on. Set your ComSystem to a volume level which allows you at all times to hear traffic noises and the signals of other road-users (especially police and emergency services).
  • Page 5 Never dial the telephone while riding, unless you have a voice- controlled dialing phone service and the driving situation permits. Note: Only press the transmit button when you really want to transmit via two- way radio. All conversations and telephone calls that are conducted with the transmit button pressed can be received and overheard by third parties when the two-way radio is switched on.
  • Page 6 Overview The audio management of the K 1200 LT consists of inputs and outputs from numerous standard and optional devices. To gain the most benefit from the system, it is necessary to understand what functions are available. As with all audio systems, these devices operate on different levels, which determine what priority each level has over the other.
  • Page 7 Controls BMW ComSystem Control Surface: 1. Auxiliary Audio Input 2. Fairing Speaker / Headset Switch 3. Intercom Volume 4. FRS Radio Input 5. Intercom VOX Sensitivity 6. Cell Phone Input 7. FRS or CB Transmit Select Switch Motorcycle Connections / Controls 8.
  • Page 8: Rider / Passenger Intercom

    Rider / Passenger Intercom Operation The ComSystem intercom is a voice activated system that allows seamless communication between rider and passenger. The ComSystem is operational when the motorcycle ignition switch is turned “on”. The system will not function (nor can you hear music through the helmet headsets) with the ignition “off”...
  • Page 9 • The intercom will mute the music from all audio sources when VOX is engaged, and return the music 3.5 seconds after the last VOX input is received. The 3.5 second delay spans the natural gaps that occur from voice inflections and minor turns of the head (away from microphone) that occur while riding.
  • Page 10: Auxiliary Audio Input

    Auxiliary Audio Input The ComSystem provides a port to connect auxiliary audio players (such as MP3 devices) to the audio channel (Level 1). Requirements • Connect the accessory audio device using a connection cable BMW PN 99 99 0 000 204 (short) or 99 99 0 000 205 (long), which has a 3.5 mm stereo plug at both ends.
  • Page 11 Cellular Telephone The ComSystem provides an input for cellular phone communication. Given the increased emphasis / local legislation requiring the use of cellular phone headsets while driving a car, as well as the proliferation of phone models and calling plans available, BMW is providing a simple connection to the ComSystem via the cellular phone headset 2.5 mm jack found on most phones.
  • Page 12 oddments compartment. A longer cable is available PN 99 99 0 000 203 to allow placement of the phone in the optional tank utility pouch 71 60 2 342 670. • Turn the phone “on”, place the phone in the tray and close the lid. •...
  • Page 13 Operation of (FRS) Family Channel Radio Requirement • A FRS radio such as the Kenwood FreeTalk™ (BMW PN 99 99 0 000 041) and corresponding adapter cable (BMW PN 99 99 0 000 199) are required. Several different adapter cables have been developed for the most popular FRS radios (see page 23).
  • Page 14 • Incoming FRS radio transmissions will activate the intercom system, mute the music (Level 1), and will be heard by rider and passenger. Rider and passenger can discuss what is being heard from the FRS or CB radio without that conversation be transmitted. If CB is also being monitored, incoming transmissions will mix with the FRS radio broadcasts, muting the music as well.
  • Page 15 particularly true of CB, which is AM band (FRS is FM). Therefore, expect less range in mountain areas, greater range in plains areas. Note: For maximum enjoyment of the system, it is imperative that the helmet headset microphone placement be correct, as advised in the headset installation instructions.
  • Page 16 Operation of (CB) Citizen Band Radio Requirement • A CB radio such as the Midland™ 75-830 CB radio kit (BMW PN 99 99 0 000 196) available from your BMW retailer. • We recommend that the CB radio kit be installed by your BMW retailer.
  • Page 17 desired channel. You can select memory functions to remember specific channels. • With intercom volume set at your normal level, adjust the volume of the CB radio to be received at a comfortable level. Use the CB radio volume control to do this (you need to receive a real transmission to do this) before the ride begins.
  • Page 18 Note: If you receive a cell phone call while riding with the FRS or CB radio in use, the cell phone will mute all Level 1 & 2 communications. How- ever, if (out of habit) you press the PTT button while talking on the phone (something you should not do), that portion of your phone conversation could be transmitted over the FRS or CB radio.
  • Page 19 Accessory Audio Warning Device or GPS BMW has provided a special connection plug in the wiring harness of the ComSystem for connection of an Accessory Audio Warning Device (AAWD) and GPS. Requirements • A GPS system with audio output signal and / or AAWD with audio output signal.
  • Page 20 volume control to do this (you need to receive a real transmission to do this) before the ride begins. • AAWD or GPS volume level must be set high enough to trigger the audio circuit. Very low volume levels may produce a “choppy” audio response.
  • Page 21: Communication Options

    Communication Options BMW has developed a wide range of communications options to assist riders with their communications needs. Please review the following items to learn more about BMW communications. BMW Helmet Headsets BMW helmet headsets are fitted with high-performance helmet speakers with independent floating ground connections, providing outstanding fidelity / sound reproduction.
  • Page 22 1983 - 2001 Kawasaki audio 1986 - 1989 Suzuki audio 1988 - 2000 Honda GL1500 w/J & M passenger control panel BMW FreeTalk™ Headset Harness BMW has produced a special harness that connects the BMW helmet headset directly to the Kenwood FreeTalk™ FRS radio. This enables LT riders or riders of other models to communicate when they are not riding a motorcycle equipped with a ComSystem.
  • Page 23 BMW ComSystem Parts Listing Main Kits 99 99 0 000 186 ComSystem - Kit Complete (includes main control unit and complete wiring harness) 99 99 0 000 187 ComSystem - Kit Complete for Retrofit of BC1 & 99 00 0 001 788 Power Accessory Relay Harness (needed for either kit above) Replacement Parts...
  • Page 24 99 99 0 000 199 ComSystem - Kenwood FreeTalk™ FRS Adapter Harness 99 99 0 000 200 ComSystem - Motorola Talk-About™ FRS Adapter Harness 99 99 0 000 201 ComSystem - Motorola Talk-About™ (T-Series) FRS Adapter Harness 99 99 0 000 202 ComSystem - Cell Phone Adapter Harness - standard length 7”...
  • Page 25: Technical Data

    Technical Data Current Draw Operating Voltage Audio Input Maximum level in Frequency Response Aux. Audio Input Maximum level in Frequency Response Intercom Input Maximum level in Frequency Response System / ignition off System on / standby (no audio, no transmission, external music switch off) Maximum (with CB transmission)
  • Page 26 Input from FRS Radio Input from CB Radio Input from Cell Telephone Input from GPS / Audio Warning Device Output Audio Output to FRS Radio Output to CB Radio Output to Cell Telephone GPS B+ Power Supply Frequency Impedence Sensitivity Maximum 1 kHz 1 kHz 1 kHz...
  • Page 27 Part # 99 99 0 000 190 Replacement Wiring Harness 1 - Main Part # 99 99 0 000 191 Replacement Wiring Harness 2 - Rear...
  • Page 28 Part # 99 99 0 000 192 Replacement Wiring Harness 3 - Front Part # 99 99 0 000 199 Kenwood FreeTalk Adapter Harness...
  • Page 29 Part # 99 99 0 000 200 Motorola Talk-About Adapter Harness Part # 99 99 0 000 201 Motorola Talk-About (T Series) Adapter Harness...
  • Page 30 Part # 99 99 0 000 196 ComSystem CB Wire Diagram...
  • Page 31 © 2001 BMW of North America, LLC Logo and trademark are registered Printed in U.S.A. 06/01 PN 99 99 0 000 210...
