- Page 1 All manuals and user guides at all-guides.com VersiVision FVT1000/FVR1000 Series Fiber Optic Video Modems Technical Manual Also covers FVR1000M modules Copyright Aug 2005 VERSITRON, Inc. 83 Albe Drive / Suite C Newark, DE 19702 www.versitron.com...
- Page 2 1. You call VERSITRON at (302) 894-0699 or (800) 537-2296 and obtain a Return Maintenance Authorization (RMA) Number. Please reference your RMA number on the outside of the shipping box.
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com TABLE OF CONTENTS SECTION 1: GENERAL DESCRIPTION INTRODUCTION…………………………………………………………………..4 DESCRIPTION OF EQUIPMENT…………………………………………………4 Functional Characteristics…………………………………………4 Physical Characteristics..............5 SPECIFICATIONS………………………………………………………………5-6 SECTION 2: INSTALLATION INSTRUCTIONS INSTALLATION PROCEDURE………………………………………………….7 SECTION 3: TROUBLESHOOTING TROUBLESHOOTING…………………………………………………………8 LISTS AND ILLUSTRATIONS FIGURE 1: FVT1003 and FVR1003……………………………………………5 FIGURE 2: PSACV1 Power Supply……………………………………………7 FIGURE 3: FVT100x Connection Layout……………….……………………9... -
Page 4: Introduction
ST and SC optical connectors are standard for the fiber optic interface. The FVT1000 and FVR1000 modems are completely compatible with the NTSC, PAL, or SECAM video standards. VERSITRON FVT1000 and FVR1000 Series Fiber Optic Video Modems utilize APC circuitry while maintaining stable optical power output. The fiber optic link established between the transmitter and receiver devices insures immunity from EMI, RFI, and ground loops. -
Page 5: Physical Characteristics
All manuals and user guides at all-guides.com Physical Characteristics The VersiVision FVT1000 transmitter and FVR1000 receiver modems are available as standalone devices for easy plug and play installation. In addition, the FVR1000 receiver modems can be ordered as circuit card modules (See Chart Above) for installation in the Model FVC14 rack-mount chassis. The 14-slot chassis fits in a standard 19”... - Page 6 All manuals and user guides at all-guides.com ENVIRONMENTAL MTBF >100,000 hours Operating Temp: -30˚C to +50˚C Storage Temp: -40˚C to +85˚C Relative Humidity: 0% to 95% (non condensing) Size: 19 x 16 x 3.2 cm 7.5 x 6.3 x 1.2 in. Shipping Weight: <4.4kg Construction:...
-
Page 7: Section 2: Installation Instructions
All manuals and user guides at all-guides.com SECTION 2 INSTALLATION INSTRUCTIONS INSTALLATION PROCEDURE The VersiVision FVT1000 Series transmitters and receivers are preset for immediate use. There are indicator LEDs on the units for monitoring the real-time status of video, and power. The following instructions describe the typical installation procedure and the function of the LED indicators located on each unit. -
Page 8: Troubleshooting
All manuals and user guides at all-guides.com SECTION 3 TROUBLESHOOTING OPTICAL FIBER The VersiVision FVT1000 and FVR1000 Series fiber optic video modems are available for applications using multimode or singlemode optical fibers. Please be certain that the correct size and type of fiber is being used for the particular mode transmitter/receiver combination. - Page 9 All manuals and user guides at all-guides.com FIGURE 3: VersiVision FVT100x/FVR100x Connection Layout...
