3D Glasses User's Guide
System Requirements
3D Glasses are designed to be emitter free and work with 3D enabled DLP®
projectors and televisions. Turn on the 3D mode on the display in DLP®-Link
mode when using 3D content. Do note, some displays will automatically switch to 3D
mode when 3D content is played.
3D Glasses
Operation Guide
1. To turn on 3D Glasses
Press the power button and the LED will flash one time indicating the goggles are
ready to use 3D mode.
2. Verify that 3D content is being sent to the projector and signal is compatible
with projector specifications
3. Turn on 3D mode in projector on-screen menu. 3D mode is located in
Display settings section.
4. Turn on 3D glasses and verify image appears in 3D and there is no eye-strain.
5. If the image does not appear in 3D repeat previous steps (1) – (4)
6. If the projected image still does not appear to be 3D change the 3D sync invert
setting. The 3D invert setting is located in the Display section of the projector
menu.
7. For additional set-up information refer to the projector user's manual.
8. To turn off 3D Glasses
Press the power button and hold until the LED switches off
TM
Optical receiver
Power button
Battery indicator LED
Advertisement
Table of Contents
Related Manuals for Optoma ZD101
Summary of Contents for Optoma ZD101
-
Page 1: System Requirements
All manuals and user guides at all-guides.com 3D Glasses User’s Guide System Requirements 3D Glasses are designed to be emitter free and work with 3D enabled DLP® projectors and televisions. Turn on the 3D mode on the display in DLP®-Link mode when using 3D content. - Page 2 All manuals and user guides at all-guides.com Battery Indicator The 3D Glasses include two coin type CR2032 standard manganese lithium batteries. If battery life is close to the end, the battery indicator LED will flash 4 times consecutively every 1 minute. This behavior will repeat until the battery life is ended. When you turn on 3D Glasses under low battery level the LED will be dimly lit for 5 seconds.
- Page 3 All manuals and user guides at all-guides.com Step 2 Battery Removal Gently pull back the metal clips to release the batteries.. Step 3 Insert new batteries Anode (+) of battery Battery insertion direction Battery insertion direction...
- Page 4 All manuals and user guides at all-guides.com Nosepiece Change 3D Glasses come with three interchangeable nosepieces to provide a comfortable fit. You should pull out the current nosepiece and insert the one that fits you best. Pull out the nosepiece as shown and change to another nosepiece Items in the Box...
- Page 5 All manuals and user guides at all-guides.com Take regular breaks when using 3D glasses and if you experience discomfort at any time, discontinue use. We suggest a minimum break of 5 minutes for every hour of use. Do Not: Use 3D glasses for any other purpose than outlined in this manual. Use 3D glasses for extended periods of time.
