Vonets VAR11N Quick Start Manual

VAR11N is the professional mini WiFi repeater, and together with mini WiFi router and
WiFi intelligent bridge that is elaborately developed by HouTian Network, the original
creation D/A temperature compensated auto frequency control technology (TAFC),
it solved the common failing of the traditional wifi router or wifi products that easily drop
the network, make sure the lasting stability to ensure that the WiFi signal is not dropped.
The following describes how to use it as WiFi router:
Step 1: The connection between VAR11N and Modem, there are two
l Method 1: The default connection method, see the following pictures:
ADSL
(Modem)
The power hole of
VAR11N, powered by
the power adapter of
ADSL modem
The above picture connection method is the factory default connection, if there is
different connection environment, user can set WAN, LAN port for connection manually,
the method of switching WAN, LAN port, please see the following user guidance:
l Method 2: The connection method of WAN, LAN port after switching.
http://www.vonets.com
Shenzhen HouTian Network Communication Technology Co., Ltd
Home Wireless Router Application
ways, see the following:
Tel: 0086-755-26642519 26645879
RJ45 ethernet port of
VAR11N, the default
is WAN port, used to
connect LAN port of
ADSL Modem.
The power head paralleled
with the power interface of
VAR11N, after connecting
with the power adapter with
ADSL modem, it can share
the power adapter.
RJ45 ethernet head, used as
LAN and connect the ethernet
port of computer to be
convenient for configuration
