- Page 1 Operating, Maintenance, Servicing and Installation Guide watch AlluGuard online at: www.thegaragedoorchannel.co.uk...
-
Page 2: Table Of Contents
Rotherham Road, Parkgate, Rotherham S62 6FP t: 01709 529 723 f: 01709 524 577 e: info@alluguard.co.uk w: www.alluguard.co.uk AlluGuard reserve the right to alter specifications to design and manufacture without notification. All specifications are correct at time of publication, errors and omissions excepted. August 2019... -
Page 3: Welcome
We understand that the purchasing of your AlluGuard management systems are industry 77 or AlluGuard 55 roller garage door is a significant acknowledged! Our products are investment for you and your property, this has led us... -
Page 4: Looking After Your Garage Door
Additional information garage door for electrically operated products Tips on maintenance for your new AlluGuard 77 and AlluGuard 55 Garage Door. Your door should run smoothly and easily as the motor is not designed to Your garage door is low maintenance: over-come problems of a badly running or damaged door. -
Page 5: Operating Instructions
Operating Instructions Electrically Operated Products Whenever possible the garage door should be operated when it is in view, making sure it is not obstructed. Ensure when the curtain is running, that you and any other person stands clear of the curtain and keeps hands etc. away from the moving parts. -
Page 6: Safety
Safety The safety edge also works as a weather seal, designed to be pressed against the ground. The bottom slat transmitter\cable has an IP rating Safety edge of IP54 and is protected against dust and water splashing. The Safety Edge is fitted to the bottom of the door and is activated when the door starts to Safety Devices close. -
Page 7: Troubleshooting
Troubleshooting Electrically Operated Products Fault Possible Cause Solution Transmitter not working Batteries flat Change batteries* Aerial position Check position of aerial on unit to ensure it is straight** Distance from door Operate the handset within sight of the door Door closes but immediately Safety edge activated Sweep the floor to ensure it is clear of obstructions and check... -
Page 8: Door Service & Safety Check
Door Service & Safety Check Door Number: style, security, innovation... Installation Date: Installation Address: AlluGuard Approved Installer: Postcode: Visual Checks Check exterior of curtain for debris/salt/dirt signs of rubbing or scuffing - clean as required. PASS FAIL Advisory notes: Check operation on all handsets and wall station buttons/ change batteries after 18 months or second service. -
Page 9: Service & Maintenance Record
Service & Maintenance Record Date Work Carried Out Work Performed By Print Signed Company Name... -
Page 10: Installation Manual
Installation Manual Important: Please read these instructions carefully prior to commencing the installation of the door. The AlluGuard door has been designed to provide DANGER years of trouble free use. The door will perform Disconnect electric power to the control unit before efficiently only if it is installed and operated correctly. - Page 12 Should the lintel the installation. protrude backwards or forwards from the brick piers this will require special instructions, please consult Tools Required: your AlluGuard Approved Installer. • 2 Stepladders • 7.0 drill bit 3. Fitting Notes •...
- Page 13 The headroom is the clear vertical height required between the top of the guide rails and any obstruction above the shutter as shown in Fig 1 and Fig 2. This space is required to house the door roll headroom of 205mm / 300mm is required. (AG55 requires 205mm & AG77 requires 300mm).
- Page 14 The motor and control unit can be mounted on either the L/H side or R/H side. (Please specify at time of order). All AlluGuard doors are fitted with a safety brake as standard excluding AG55 Doors shown in Fig 10.
- Page 15 The safety brake and back plate are fitted to the end plate as standard (Fig 10). Remove the 10mm nuts and washers from the bottom two fixings on the safety brake. Remove the safety brake and fit it to the end of the shaft with a 20mm M6 bolt and washer (Fig 10a).
- Page 16 5.5 Fitting Behind Aperture Lift the frame assembly into position and align centrally with the aperture. Ensure the guide rails are vertical (in both directions) and are parallel to each other, at the same height and the correct distance apart. NOTE: Some width adjustment is available on the sliding shaft end of the axle.
- Page 17 7.3 Locking Ring There is a locking ring positioned on the shaft for each locking strap; the number of locking rings will vary according to curtain width and AG55 - 2 rings & AG77- 1 ring per strap. Position the outermost ring/s to the shaft approx. 150mm in from each end and equally space the other/s as shown in Fig 19.
- Page 18 The support straps supplied should be positioned centrally or equidistant. Doors up to 3m wide will have one strap and doors over 3m wide have two straps. 8. Connect the Electrics 8.1 Preparing the AlluGuard Roller Garage Doors for Remote Control for Installation •...
- Page 19 9.2 Connecting the Receiver to the Mains Power Supply 9.2.1 Fully unfold the receiver aerial so that it is pointing downwards. 9.2.2 Screw the bulb supplied into the receiver. (Before connecting to mains power supply) 9.2.3 Replace and screw in the receiver cover. 9.2.4 Refit the integrated light cover.
- Page 20 Ellard Motor Limit Set-up 9.4 Limit Switch Adjustment (see Fig 22) The limits are set at the factory to 8 revolutions of the shaft, A 4mm ‘Allen Key’ limit adjuster is used to adjust them further. Allow the motor to run downwards without the curtain attached to enable the shaft to determine bottom limit position, without curtain attached to shaft.
- Page 21 & Programming the Safety Edge Transmitter Start with the roller door at its top limit, if positioning the top magnet (AG55 Doors with 12RPM Motor) you should measure down 50mm from the bottom of the safety edge transmitter and turn on dipswitch 4 within the safety edge transmitter.
- Page 22 7. 1 x Courtesy Light Bulb 8. 1 x XSE Safety Edge Transmitter 9. 1 x XSE Safety Edge Transmitter Installation Guide 10. 1 x Bag of XSE Safety Edge Transmitter Screws (x4) 11. 1 x Guide Magnets (2 x Magnets with AG55 12RPM Motors)
-
Page 23: Installation Instructions
EMR (Exterior Release Kit) Installation Instructions... - Page 24 System Diagnostics The Rollixo Remote Control System provides a full fault finding diagnostic programme, this is all dependant on there being power to the unit.
-
Page 25: Declaration Of Incorporation
A technical file of documentation has been compiled in accordance with Annex VII (Part 7 of Schedule 2), part B. AlluGuard undertakes to transmit, in response to a reasoned request by the national authorities, relevant information on this partly completed machinery. Transmission shall be via electronic or paper copies, and shall be without prejudice to the intellectual property rights of the manufacturer of the partly completed machinery. -
Page 26: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY - CUSTOMER COPY THE SUPPLY OF MACHINERY (SAFETY) REGULATIONS 1992 Model: Serial Number: Size (W x H): Installed By: The above power operated door (door, operator, safety devices, etc.), has been assembled, installed, connected and tested in accordance with the manufacturer’s instructions, at the following site address and is in conformity with the provisions of the Machinery Directive (89/392/EEC as amended by 91/368/EEC and 93/336/EEC), the Low Voltage Directive (73/23/EEC) and EMC Directive (89/336/EEC). - Page 27 EC DECLARATION OF CONFORMITY - INSTALLER COPY THE SUPPLY OF MACHINERY (SAFETY) REGULATIONS 1992 Model: Serial Number: Size (W x H): Installed By: The above power operated door (door, operator, safety devices, etc.), has been assembled, installed, connected and tested in accordance with the manufacturer’s instructions, at the following site address and is in conformity with the provisions of the Machinery Directive (89/392/EEC as amended by 91/368/EEC and 93/336/EEC), the Low Voltage Directive (73/23/EEC) and EMC Directive (89/336/EEC).
-
Page 28: Style, Security, Innovation
Rotherham Road, Parkgate, Rotherham S62 6FP t: 01709 529 723 f: 01709 524 577 e: info@alluguard.co.uk w: www.alluguard.co.uk AlluGuard reserve the right to alter specifications to design and manufacture without notification. All specifications are correct at time of publication, errors and omissions excepted. April 2018...
