Guardian
POSSIBLE DAMAGE OR INJURY. Be alert of hi/lo adjustment of overbed table
when raising bed.
ASSEMBLY INSTRUCTIONS (FIGURE 1)
1. Using the hex bolts and washers, attach the base to the post. Tighten the bolts
securely.
2. Insert the tilt control bar into the post by loosening post screw. Tighten post
screw, once tilt control bar has been inserted into post.
3. Attach the outer tube to the top board using the screws.
4. Slide the outer tube onto the tilt control bar. If it is too tight, release the
rotating knob on the tilt control bar.
5. Tighten the rotating knob to set the top board.
6. Insert the casters into the base until they lock into place.
Tilt Control Bar
Rotating Knob
Post Screw
Figure 1
Tilt Automatic Overbed Table
®
User Instructions
Model IC-6418
Screws
Base
Hex Bolts
Top Board
Outer Tube
Casters
