- Page 1 HET-Flying wing Wingspan: 1820 mm Length: 670 mm Weight: 700 -1200 grams. Motor: HET 15-10 15- 13 , 4w, 5W Brushless Motor www.highendrc.com...
- Page 2 ITEMS NEEDED FOR COMPLETION: 4 CHANNEL COMPUTER RADIO SYSTEM SERVOS: 2 for regular operation (2-Elevons) 1x Electronic Speed Controls 1x 30 mm spinner 2x 6” Servo Extensions 1 Brushless Motors: HET 4W, 5W, 15-10 or 15-13 1 Propeller 1x Li-Po Battery Battery Connectors and Gilt Connectors CA and Epoxy Glues Sanding Block and normal tools...
- Page 3 Glue first one side of the wing joiner with 5 minute Check the alignment of the wings. Lay the wing epoxy. With the bottom side up , Then glue the wings together. With 5 or 30 minute epoxy. Lay the wing on a cardboard tube or broomstick Sand th edges , and if necessary, trim the front and With the bottom side up to let the epoxuy cure.
- Page 4 Servo bay hatch and triangle stock hard wood. Glue in the triangle wood stock with 5 minute epoxy. Make sure that the servo hatch is flush with the wing surface. Mark the crew holes with a thin pencil and Aft he holes have been drilled put some thin CA glue in the Drill appr.
- Page 5 Pull an extension servo wire through the Solder the servo wires to the extension cable pre-drilled hole. Please use metal gear and isolate the wires with shrinktube. servo’s. Don’t forget to set the servo horn in If you use extension cords with male and its middle position with your transmitter female ends you don’t have to do soldering.
- Page 6 Mark your motor mounting pattern on the Now install your motor and speed controller nose and cut the holes with a dremel tool Check the alignment of the motor axle Check it with the spinner installed correct if neccesary with washers between the motor and fuselage.
- Page 7 MOTORS and ESCs THAT CAN BE USED MOTOR power LIPO Proppellor 4W 2 cells 40 amps 200 Watts 1500 Mah 25c 3S1P 8 x6 folding prop. 5W 2cells 40 amps 200 watts 1800Mah 25C 2200 25C 10 x6 folding prop. 15-10 3 cells 30 amps 200 watts...
- Page 8 You will find the flying wing to have very good stability as well as maneuverability. Loops and rolls are easily obtained with adequate entry speeds. Remember to land level so there won’t be damage to the plane. The flying wing will also thermal and soar very well with the motor off.
