testo 865, 868, 871, 872 - Thermal Imager
Short instructions
In order to be able to establish a connection via Bluetooth, you need a
tablet or smartphone with the Testo "Thermography" App installed on it.
These short instructions describe the basic operating steps. Please refer
to the instruction manual to find out how to handle the product safely
and for detailed information.
All manuals and user guides at all-guides.com
Short
instructions
Pocket
Guide
Thermography
Instruction
manual
Videos
Advertisement
Related Manuals for TESTO 865
Summary of Contents for TESTO 865
- Page 1 Videos In order to be able to establish a connection via Bluetooth, you need a tablet or smartphone with the Testo “Thermography” App installed on it. These short instructions describe the basic operating steps. Please refer to the instruction manual to find out how to handle the product safely...
- Page 2 6 Infrared camera lens; Takes infrared images; protects the lens protective cap 7 Digital camera Takes real images (except testo 865) 8 Laser Marking the measuring point (only testo 872) Trigger Saves the displayed image 10 Battery compartment Contains the rechargeable battery...
- Page 3 The infrared image is saved automatically. testo 868, 871 and 872: irrespective of the selected image type, an infrared image is always saved with the attached real image. If a higher resolution is required: In the menu, select the...
- Page 4 All manuals and user guides at all-guides.com Displaying and deleting images - Select image gallery function. To do this, see Getting to know the menu. - Display image: Move joystick (4) left/right/up/down to select the image, then press (4). - Press (5) to delete the image.
- Page 5 - Move joystick (4) up/down to toggle between the colour palettes. Selecting image type (infrared image, real image) (testo 868, 871 and 872) - Select image type function. To do this, see Getting to know the menu.
- Page 6 All manuals and user guides at all-guides.com - Move joystick (4) up/down to select auto, manual ScaleAssist and then press (4). Automatic scaling is activated. is displayed bottom right. Manual scaling - Move joystick (4) left/right until min. temperature (lower limit value) is highlighted.
- Page 7 All manuals and user guides at all-guides.com 0970 8721 en 01...
