New
Features
Added
A feature rich mains controller allowing
switch users to control up to two
electrical appliances with wired or
wireless switches.
ENERGISE includes SimplyWorks
technology, allowing interference free
activation of appliances at up to 10 metres.
Six selectable modes enable the user
to choose how, and for how long, the
appliance(s) will be turned on.
Simplyworks
INSTRUCTIONS
Product Description
Four modes give independent switch and
appliance activation: two further modes
provide co-operative control of both
appliances.
®
wireless
ENERGISE will accept any wired switch or
the SimplyWorks
75, SEND; or any combination of these.
ENERGISE
®
SWITCH 125, SWITCH
®
Advertisement
Table of Contents
Related Manuals for Pretorian Simplyworks ENERGISE
Summary of Contents for Pretorian Simplyworks ENERGISE
- Page 1 ® Simplyworks INSTRUCTIONS ENERGISE Features Added Product Description A feature rich mains controller allowing Four modes give independent switch and switch users to control up to two appliance activation: two further modes electrical appliances with wired or provide co-operative control of both wireless switches.
- Page 2 ENERGISE IMPORTANT SAFETY INSTRUCTIONS. FAILURE TO COMPLY COULD RESULT IN PERSONAL INJURY. • Read and pay heed to these instructions and retain for future reference. • Do not use this unit near water. • Unit is intended for indoor use only. •...
-
Page 3: Control Modes
Features • Six selectable control modes. Four modes provide independent switch operation; two further modes provide co-operative switch operation. • Independent switch operation in Direct, Latched, Timed Minutes and Timed Seconds modes. • Co-operative switch operation in Co-Op and On/Off modes. •... -
Page 5: Output Status
Pairing with Wireless Switches Place SWITCH 125 or SWITCH 75 close to ENERGISE and briefly press Pair 1 button [5] on ENERGISE. Pair LED 1 [7] will flash slowly. Immediately press the Pair button on the wireless switch. Pair 1 LED will continue to flash slowly until pairing is complete when the LED will light steadily for 5 seconds. -
Page 6: Safe Operation
Selecting Control Modes To view the settings for channel 1, press the Note that if either channel is set to Co- 1/Mode button [3] briefly and the LEDs will Operative or On/Off modes, the other channel light up to indicate the current mode and will automatically be changed to the same period settings. -
Page 7: Maintenance
Clean using a dry cloth, never immerse in water or spray water or other liquids on to the unit. Never carry ENERGISE by its power cable. ENERGISE has no user serviceable parts. If repair is necessary the unit should be returned to Pretorian Technologies Ltd or an authorised distributor. Technical Specification Input/Output Power: USA: No fuse in plug. -
Page 8: Troubleshooting
Unit 37 Corringham Road Industrial Estate Gainsborough Lincolnshire DN21 1QB UK Tel +44 (0) 1427 678990 Fax +44 (0) 1427 678992 SimplyWorks ® is a registered trademark of Pretorian Technologies Ltd S040007:2 www.pretorianuk.com Refers to firmware version 44.3 and later...
