Eyevis esp WQXGA Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

espSERIES-WQXGA
EYEVIS PROJECTOR LINE
(Version 1)
User´s Manual
Version 0.9 (August 2013)
Technical changes reserved.
Preliminary

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the esp WQXGA Series and is the answer not in the manual?

Questions and answers

Related Manuals for Eyevis esp WQXGA Series

Summary of Contents for Eyevis esp WQXGA Series

  • Page 1 Preliminary espSERIES-WQXGA EYEVIS PROJECTOR LINE (Version 1) User´s Manual Version 0.9 (August 2013) Technical changes reserved.
  • Page 2 The content of this manual is furnished for information use only, is subject to change without notice, and should not be construed as a commitment by eyevis GmbH. eyevis GmbH resumes no responsibility or liability for any errors or inaccuracies that may appear in this documentation.

  • Page 3: Table Of Contents

    ESP-LWQX-1000 TABLE OF CONTENT SICHERHEIT / SAFETY TRANSPORT, STORAGE, UNPACKING UNPACKING DELIVERY CONTENTS PACKAGING PRODUCT OVERVIEW PROJECTOR ASSEMBLY / INSTALLATION AUTHORIZED INSTALLATION OPTIONS UNAUTHORIZED INSTALLATION OPTIONS CABLING THE PROJECTORS ADRESSING THE PROJECTORS ROTATION SWITCHES NETWORK ADJUSTING THE FOCUS CONFIGURATION GENERAL INFORMATION ON THE CONFIGURATION PROGRAMS ADJUSTING THE COLOURS WITH EC-LCONTROL ESTABLISHING COMMUNICATION VIA EYEDEVICE CLEANING AND CARE...
  • Page 4 ESP-LWQX-1000 DURATION AND VALIDITY OF WARRANTY PROOF OF PURCHASE WARRANTY SERVICE OR EXCHANGE DURING WARRANTY PERIOD WARRANTY EXCLUSIONS REACTION TIME ADVISED PROCEDURE FOR RAISING A CLAIM LEGAL AND OTHER CLAIMS LIMITATIONS OF LIABILITY CORRECT DISPOSAL APPENDIX APPENDIX: TECHNICAL SPECIFICATION...
  • Page 5 ESP-LWQX-1000 REVISION HISTORY PAGE / VERSION DATE DESCRIPTION SECTION 2013-08 Specification first issued. (Preliminary)

  • Page 6: Sicherheit / Safety

    ESP-LWQX-1000 SICHERHEIT / SAFETY ZU DIESER ANLEITUNG Lesen und beachten Sie diese Anleitung. In ihr stehen wichtige Informationen zum Produkt. Beachten Sie insbesondere alle Sicherheits- und Warnhinweise. Bewahren Sie diese Anleitung sorgfältig auf! VERWENDETE WARNHINWEISE ACHTUNG Kennzeichnet eine Gefahr, die zur Beschädigung oder Zerstörung des Produkts führen kann.
  • Page 7 ESP-LWQX-1000 SICHERHEITSHINWEISE In diesem Kapitel finden Sie allgemeine Hinweise für einen sicheren Umgang mit dem Produkt. ► Lesen Sie diese Sicherheitshinweise sorgfältig und befolgen Sie alle darin beschriebenen Anweisungen. Vor konkreten Gefahren werden Sie zusätzlich in den nachfolgenden Kapiteln durch farbige Warnhinweise immer dann gewarnt, wenn die Gefahr unmittelbar besteht.
  • Page 8 Zum Auspacken und zum Bewegen der Geräte sollten Sie mindestens zu zweit sein. Stellen Sie sicher, dass die Geräte stets aufrecht transportiert werden. ► Verwenden Sie ausschließlich eyevis Untergestelle zum Aufbau der Geräte. Verwenden Sie an Orten mit starken Vibrationen ein entsprechendes vibrations-absorbierendes Untergestell von eyevis. ►...
  • Page 9 Schäden, die in Folge mangelnder Beachtung der Anweisungen dieser Bedienungsanleitung entstanden sind. ► eyevis ist nicht haftbar für Schäden die in Folge des Gebrauchs seiner Produkte im Zusammenschluss mit anderen Produkten, Geräten und Software entstehen.
  • Page 10 ESP-LWQX-1000 ABOUT THIS MANUAL Read and pay attention to this manual. It contains important information on the product. In particular, note all of the safety instructions and warnings. Keep this manual in a safe place! WARNINGS USED NOTICE Indicates a hazard that could lead to damage or destruction of the product. The general warning symbol indicates a hazard that could lead to injuries or death.
  • Page 11 Observe all the local system installation and operation regulations which our systems are subject to. POWER ► Only use the power cable supplied by eyevis. ► The power cable must be correctly and securely connected to earthed power outlets. ►...
  • Page 12 When unpacking or carrying the devices, at least two people are needed. Make sure the devices are carried upright. ► When installing the devices, use the designated frame supplied by eyevis. Use a special vibration absorbing frame from eyevis when using the devices in locations subject to vibration.
  • Page 13 Specifications“ section on page Seite <?>. DISCLAIMER ► eyevis is not liable for any damage caused by natural disaster (such as earthquake, thunder etc.), fires, acts by third parties, accidents, owner's intentional misuse and fault or uses in other improper conditions.

  • Page 14: Transport, Storage, Unpacking

    ESP-LWQX-1000 TRANSPORT, STORAGE, UNPACKING UNPACKING The projector is packaged in a cardboard box. To protect the projector during transportation, the projector is wrapped in foam. The packaging is secured with packing tape. To unpack the projector: Open the package. Remove the projector with the protection foam from the package. Remove the protection foam: STORAGE OF PACKAGING ►...

  • Page 15: Delivery Contents

    Dimensions and technical details may vary depending on the product version. PACKAGING PROJECTOR • 1x ESP-Projector (ready mounted) • 1x power cable (2 meter) • 1x RS232 serial cable (2 meter) • 1x RS232 RJ45 (1 meter) • 1x eyevis projector adjustment software on CD • 1x user manual...

  • Page 16: Product Overview

    ESP-LWQX-1000 PRODUCT OVERVIEW This section provides an overview of the entire product, the individual parts as well as the connection and adjustment elements. PROJECTOR Fig. 1: Front view of projector Optics Service cover for focus adjustment Turn-Switch for projector addressing DVI IN Serial number of projector Stand-by button...
  • Page 17 ESP-LWQX-1000 CONTROL MODULE LAN (RJ 45) RS 232 IN (9-pol D-SUB) RS 232 OUT (9-pol D-SUB) LEDs display status DIP-Switcher (Service) DVI-D Fig. 2: View of the connectors POWER SUPPLY Power Supply Protection Main switcher On / Off Fig. 3: Power supply...
  • Page 18 ESP-LWQX-1000 STATUS LED Power State The power state LED indicates whether power circuit on the board is “online”, that means whether the CPU is powered by 5V standby voltage. Signal State The signal state LED indicates the status of the video signal. If the video signal is connected and valid, the LED will glow.

  • Page 19: Assembly / Installation

    ESP-LWQX-1000 ASSEMBLY / INSTALLATION This section describes how to mount and install the projector. AUTHORIZED INSTALLATION OPTIONS Fig. 6: Authorized installation options...

  • Page 20: Unauthorized Installation Options

    ESP-LWQX-1000 UNAUTHORIZED INSTALLATION OPTIONS In the following position shows the cooling element of the projector down. In this position, a sufficient cooling performance can not be guaranteed. Fig. 7: Unauthorized installation options...

  • Page 21: Cabling The Projectors

    ESP-LWQX-1000 CABLING THE PROJECTORS The projectors are connected together via RS232 cables. To cable the projectors together: Use the RS232 data cable provided (9-pin D-sub 1:1 extension cable) and connect each RS232 OUT to RS232 IN. Proceed according to the following diagram: Fig.

  • Page 22: Adressing The Projectors

    ESP-LWQX-1000 To connect the projectors to the control PC: ► Connect the control PC to projector 1 either via a RS232 data cable or via a KAT.5 Ethernet cable (optional): RS232 Fig. 9: Connecting the projecotrs to the control PC via RS232 data cable Ethernet Fig.

  • Page 23: Rotation Switches

    ESP-LWQX-1000 ROTATION SWITCHES Setting projector address(ID) for serial connection via RS232 cable. Address Switch 1 Switch 2 Switch 3 (ID) Fig. 12: Rotation switches NETWORK Settings of projector for network connection. Command Description Default value COM_LAN_DHCP Turn on / off DHCP functionality for LAN COM_LAN_GW LAN gateway IP...

  • Page 24: Adjusting The Focus

    You can find appropriate test images on your eyevis software CD. To adjust the focus: Remove the four screws that secure the left part of the cover to the focus.

  • Page 25: Configuration

    Generating reports NOTE: The EC-Lcontrol program is specially developed for adjusting the colour of the eyevis LED projectors. For this reason, use this program for colour adjustments instead of the colour adjustment function in the eyeDevice software. PROGRAM INSTALLATION AND START The programs do not have to be installed.

  • Page 26: Adjusting The Colours With Ec-Lcontrol

    Fig. 14: The EC-Lcontrol main window NOTE: The EC-LControl software can be used for both ESP eyevis projectors and for the eyevis Cubes series. Therefore, both the concepts of Projector and Cube are used. (In the software and in the text)
  • Page 27 ESP-LWQX-1000 ADJUSTING THE COLOURS Fig. 15: The EC-Lcontrol start window NOTE: The settings you change will be applied to all projectors that you previously selected (Serial ID start, Serial ID end) To display the current settings: ► Press the Get actual values button. The current projector settings are displayed in the status window. ª...
  • Page 28 ESP-LWQX-1000 To manually adjust the projectors: Select the colour you wish from the Colour temperature field. Information on the colour temperatures can be found in Tab. 3 on ª page 60. Adjust the brightness in the Brightness field. The brightness can be estimated from the values contained in the list ª...
  • Page 29 ESP-LWQX-1000 Text output in display field Notes 2010_07_21 13:09:46 Iteration steps for optimisation adjust whitepoint..iteration: 1 of 10 The error messages indicate iteration: 2 of 10 that the red LED cannot be [ERR] Projector_2 RED-OVERRUN set to an adequate iteration: 3 of 10 brightness setting to [ERR] Projector_2...
  • Page 30 ESP-LWQX-1000 FINE ADJUSTMENT FOR SELECTED PROJECTORS Fine differences in colour rendering and brightness between the projectors can be adjusted with the fine adjustment function. To open the fine adjustment function: Click on the Fine adjust... button. The Color fine adjust window opens. ª...
  • Page 31 ESP-LWQX-1000 Drag the whitepoint across the colour field: Use the arrow buttons in the colour space to shift the whitepoint in the direction you want. The effects on the x, y and L values are displayed simultaneously. ª Click on Adjust to transfer the settings to the selected projector. Enter the RGB values: Manually enter the values for red, green and blue.

  • Page 32: Establishing Communication Via Eyedevice

    ESP-LWQX-1000 ESTABLISHING COMMUNICATION VIA EYEDEVICE This section describes how to establish the communication with the projectors with the help of the eyeDevice software. A detailed description can be found in The eyeDevice Software section from eyeDeviceSetup.exe page 47 onwards. To start the eyeDevice software: Open the eyeDevice software (eyeDevice.exe).
  • Page 33 ESP-LWQX-1000 ENTERING THE WALL SIZE In the Wall size field, you can enter the number and layout of the projectors: In the first window, select the number of columns, which is 4 in the example above. In the second window, select the number of rows, which is 2 in the example above.
  • Page 34 ESP-LWQX-1000 READING THE CONFIGURATIONS Mark the projector you want in the wall view. You can select several projectors at once: Click and hold the left mouse button in a field and mark the relevant area. Click on Read current... ª The data of the selected projectors are displayed in the view window.

  • Page 35: Cleaning And Care

    Do not clean the lens when it is heated. ► Wipe the lens over regularly with a soft cloth to keep it clean. Small stains can be removed using a damp cloth and a small amount of eyevis special detergent. CLEANING THE HOUSING...

  • Page 36: Disassembly And Disposal

    This device was made almost exclusively from material that can be disposed of and recycled in an environmentally friendly manner. Once the device is removed from operation eyevis will take it back to promote the reuse or recycling of material resources, provided the device is returned in a condition that reflects use as intended.

  • Page 37: Malfunctions And Troubleshooting

    ESP-LWQX-1000 MALFUNCTIONS AND TROUBLESHOOTING Before calling your service partner, please check the following table for a possible cause to the trouble you are currently experiencing. NOTE: The devices may only be opened by specially trained and qualified personnel. TYPICAL PROBLEMS NO PICTURE ►...

  • Page 38: Possible Causes Of Malfunctions And Problems

    ESP-LWQX-1000 POSSIBLE CAUSES OF MALFUNCTIONS AND PROBLEMS CAUTION Smoke or peculiar smells If you continue to use the device when smoke or peculiar smells are coming from the cube housing, it may cause a fire or an electric shock. ► Immediately remove the power plug from the outlet.

  • Page 39: Warranty Terms And Conditions

    Return-to-Base-Warranty (Bring-In Warranty) Defective parts or products must be sent back carriage free to eyevis. In certain circumstances can the product sent back to the specialist supplier (place of purchase) or to eyevis service centre (land of purchase).

  • Page 40: Warranty Exclusions

    REACTION TIME The reaction time to claim a right given by this warranty starts with the customer’s announcement of the claim to the eyevis GmbH. It is calculated in accordance to the standard service hours of the eyevis GmbH (monday-friday...

  • Page 41: Advised Procedure For Raising A Claim

    There are no express or implied warranties, representations or conditions other than those stated in this warranty. Other legal or contractual claims, also towards the seller of the product, are excluded as far as the eyevis GmbH has provided service based on this warranty.

  • Page 42: Limitations Of Liability

    ESP-LWQX-1000 LIMITATIONS OF LIABILITY In cases of slight negligent breaches of duty the liability of the eyevis GmbH is limited to the direct, foreseeable and contract-typical average damage. The slightly negligent breach of minor contractual obligations excludes the liability. eyevis will not be liable for any loss, damage or alterations to (1) third party furniture, hardware or software;...

  • Page 43: Appendix

    ESP-LWQX-1000 APPENDIX APPENDIX: TECHNICAL SPECIFICATION ESP-LWQX-1000 Projector: Technology: Professional Single-Chip DLP® Projector Resolution: WQXGA (2560 × 1600) Brightness: Up to 800-1000 Lumen (depending on projector version and individual settings) Contrast: Up to 1800 : 1 (depending on projector version) Aspect Ratio: 16:10 (WQXGA) Colours: 30-bit RGB...
