- Page 1 MyFlyDream AATDriver V5.06 www.MyFlyDream.com...
- Page 2 1. Hardware and features MFD AATDriver V5 is an enhance unit for MFD AAT(AutoAntennaTracker) system. The main function of AATDriver V5 is to demodulate the tracking data from Video or Audio signal, and control the tracker to point to the target.
-
Page 3: Operating Instructions
Current consume <80ma (without external devices) 2. Wiring Simply connect AATDriver to you tracker. Power it with a 5.5mm DC barrel plug (centre +). And connect your monitor to the VIDEO output RCA connector. 3. Operating Instructions 1). Accessing the OSD menu: To enter OSD menu: Hold the TEST button, then press HOME button. - Page 4 And you can keep tracking even when the tracker is moving. To connect a GPS to the AATDriver V5, you have to use the side port of the AATDriver: www.MyFlyDream.com supplies GPS for DuoTracking use. You can just plug the local GPS to the side port, the AATDriver will recognize the GPS.
-
Page 5: Firmware Update
DriverA_PIN#2 --------- DriverB_PIN#6 DriverA_PIN#6 --------- DriverB_PIN#2 This picture describes what the plane icon means (It's ID is 1): 4. Firmware update... - Page 6 1. AATDriver V5 comes with a update cable. If you don't have it, you need to solder it according the above photo. Plug the 6pin plug to the AATDriver mainbaord. 2. Plug the jumper cap to 5V position. 3. Hold the button and plug in 12V power.
- Page 7 4. Run the update tool. Select the correct COM port. Click Next.. next..select the frimware file (for example, MFD_AATDriver_V5.04.hex) and apply the update. (Just like MyFlyDream AutoPilot)
