Bluetooth Operation - Boost -STUPDJ-MKII Instruction Manual

15. LED ON/OFF (TURN ON/OFF LED)
16. GUITAR INPUT
17. POWER INPUT
18. MIC INPUT
Wireless Microphone
1. Open battery cover and insert a battery according to the + and – markings inside the compartment.
2. Turn on the microphone. If the power indicator doesn't flash nor lights up steadily check if the
battery is charged and if it has been inserted with the correct polarity.
3. Adjust the volume of the wireless microphone when you sing.
4. If the power indicator flashes when you switch on the wireless microphone, the battery is low and
needs to be replaced as soon as possible.
Notes:
1. The effective range of the wireless microphone is 15m. Do not use over that range.
2. Do not use two microphones working on the same frequency or crosstalk and interference will occur.
3. If you use more wireless microphones at the same time, they must be set to different frequencies
and should be kept away at least at 50m.
4. Don't put the device too close to a DVD/CD/VCD player as they have strong frequencies and might
affect the microphone.
Built-in recording function
Please note that the REC function is only accessible via the remote control! There is no REC button on
the unit itself.
1. In Aux mode: Plug in a USB stick and press the record key to go to record function. The screen shows 00:01
to indicate that recording has started. If you connect the USB stick for the first time to the speaker, the
system will create a folder and the speaker will save and play the recorded file automatically in this folder.
2. In USB play mode: Press the record key to go into recording mode. The current sound output will stop and
go to mute status. The screen shows "Recording". The recording will start when the screen displays 00:01.
You can use a microphone to record. If you connect the USB stick for the first time to the speaker, the
system will create a folder named VOICE.
USB/SD Operation
Keep the speaker away from high temperatures, strong magnetic fields and any equipment that could
generate interference. If the speaker stops working, switch it off and on again, or unplug USB/SD/MMC
card and re-plug it. The speaker should be back to normal status.
Supported music formats: MP3, WMA
1. USB port: plug and play
2. SD/MMC slot: plug and play
3. Mode key: press to cycle through external AUX sound source/USB/SD card/FM/BLUETOOTH
4.Play/pause: Press to play, press to pause, press again to resume play.
5. Previous/Next: During play press once to go back to the beginning of the track or to the next track.
6. Repeat: During play press once to repeat the current song, press twice to repeat all songs.

BLUETOOTH OPERATION

1. Turn on the unit and press the MODE button on unit or on the remote control to select the Bluetooth
function. The display shows "BLUE".
2. In Bluetooth mode, "BLUE" will be flashing on the display, the system automatically enters search mode.
3. Activate the Bluetooth feature on the external device to be paired.
©Copyright LOTRONIC 2017 BOOST-STUPDJ-MKII 4
