Razor W25143499003 Installation Instructions

Tools Required:
A. 5 mm Allen wrench
B. 10 mm wrench
WARNING
Do not use non-Razor products with your Razor electric
product. This item has been built to certain Razor design
specifications. Certain aftermarket parts may not be
compatible and will void your warranty.
As with all consumer electronics, use of compatible
batteries and chargers is strongly recommended. Failure
to do so may pose a fire hazard.
CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect charger
before removing or installing the batteries. Failure to follow these steps in the correct order may cause
irreparable damage.
Step 1
Using a 5 mm Allen wrench, loosen the four (4) hex
bolts that attach the seat to the frame (Figure 1a)
and remove seat. Remove the two (2) hex bolts on
the Drift Bar cover (Figure 1b) and remove.
Figure 1a
Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00 AM - 5:00 PM PST.
( )
Not included
Figure 1b
BATTERY INSTALLATION INSTRUCTIONS
Examine the battery, charger and their connectors for
excessive wear or damage each time you charge the
battery. If damage or excessive wear is detected, do not
use the charger or the product until you have replaced
the worn or damaged part.
Battery connectors may contain lead and lead
compounds. Wash your hands after handling.
Step 2
Using a 5 mm Allen wrench and a 10 mm wrench,
loosen the two (2) hex bolts on the side of the
battery cover (Figure 2a) and the two (2) locknuts,
located underneath the unit (Figure 2b).
Figure 2a
1
CRAZY CART
W25143499003
Figure 2b
