Glasdon GLENWOOD 170 POST Installation And Maintenance Instructions

Glenwood

Installation and Maintenance Instructions

IMPORTANT NOTE: ENSURE THAT ALL RELEVANT PERSONNEL READ THESE INSTRUCTIONS PRIOR TO USE

Please also refer to the 'Manual Handling Operations Regulations 1992' during the handling of the

product and materials used for installation. Glasdon recommends that a full Health and Safety analysis is

GLENWOOD 170 POST -

EXTENDED BASE MODEL (Concrete-in)

KIT CONTENTS:

ITEM 1 - Glenwood 170 Post

GLENWOOD 170 POST C/W

GLENWOOD SOCKET

KIT CONTENTS:

ITEM 1 - Glenwood 170 Post

ITEM 2 - Key Hole Plug

ITEM 3 - Socket Key

ITEM 4 - Glenwood Socket

- Excavation equipment

- Tape Measure

- Concrete Mix (we suggest using a quick setting

concrete i.e. QC10 for all installations)

- Safety Equipment (hard hat, mask, goggles,

reflective clothing, etc)

OPTIONAL BLANKING PLATE:

See page 5 for

Instructions

™

carried out prior to installation.

x 1

Page 1

170 Post

DIAGRAM NOT TO SCALE

Table of Contents

Do you have a question about the GLENWOOD 170 POST and is the answer not in the manual?

Page 1 IMPORTANT NOTE: ENSURE THAT ALL RELEVANT PERSONNEL READ THESE INSTRUCTIONS PRIOR TO USE Please also refer to the ‘Manual Handling Operations Regulations 1992’ during the handling of the product and materials used for installation. Glasdon recommends that a full Health and Safety analysis is carried out prior to installation.
Page 2 And turn anti-clockwise until removed. GLENWOOD SOCKET INSTALLATION INSTRUCTIONS See our website for a video guide - www.glasdon.com Remove the key hole plug by following step Push the key inwards and lift the post to 1 & 2 of ‘Security Hole Plug’ instructions.
Page 3 Use a spirit level to ensure the top of the Fill the hole with concrete. Ensure concrete is socket is level and flush with the ground. Add/ flush with the top of the socket. remove gravel as required to level. Smooth the surface and allow concrete to dry for at least 24 hours.
Page 4 GLASDON cannot be held responsible for claims arising from incorrect installation, unauthorised modifications or misuse of the product. Stock No. C000/0525 - DWG No. 11B-055-17 Issue 1 - April 2019 © Copyright April 2019 Glasdon UK Ltd reserve the right to alter specifications without prior notice. Page 4...
