Assembly & Installation Instructions
CAUTION: Read instructions carefully and turn electricity off at main
circuit breaker panel before beginning installation.
P830-18ICAT & P830-13ICAT
WARNING: Thermal insulation may be installed in direct contact with fixture, but DO NOT install insulation in excess of
eight inches above fixture.
RISK OF FIRE: Recessed portions of recessed housing, other than at points of support, shall be spaced at least 1/2" from
combustible material. Thermal insulation shall not be installed within 3" of recessed housing or junction box, and shall not
be installed above the fixture, as to entrap heat and prevent the free circulation of air.
CAUTION: To complete the installation, choose only a UL Listed Progress Trim from the Label inside the Housing. The use
of any Trim Not Listed in this Fixture is a Violation of N.E.C. Article 110-3 (B) and Voids All Warranties.
NOTE:
This fixture comes with replaceable ballast. Should the ballast fail contact a qualified electrician to replace it.
If further assistance is required, contact Warranty Services at: (864) 678-1670.
A.- For Wooden Joists: Use the Centering Arrow (4), Located on the Plaster Frame, to position the Fixture, extend the
Hanger Bars (6) and hammer the 4 Nail Tabs (7) into Joists (8). Drive additional nails through holes in Hanger Bars for
additional support if required. Bars may be bent to fit tight mounting conditions. (See Fig. 1)
B.- On Suspended Ceilings: Place the Fixture on the ceiling grid with the "T" Bars (9) running through the Hanger Bar
Notches (10). Fold the Hanger Bar ends closed to engage the integral Tabs (11). Secure with pliers if necessary.
C.- Locate Housing: along Hanger Bar to desired position and using pliers, squeeze the 4 Locking Tabs (12) on the Plaster
Frame (13) tightly over the Bars to prevent further Housing movement. Bar Hangers (6) may be installed in alternate Slots
(21) if Mounting Conditions require.
D.- Carefully Remove: Junction Box Cover Assembly (14).
E.- Run Supply Wires: through UL Listed Connectors (not supplied) in one of the five pry outs (15) on the Junction Box (16)
or Type NM cable (ROMEX), through an Opening above the Wire Retaining Plate (17). Connect Wires (19) as shown in Fig.
2 and 3. Connect Fixture Wires to Supply Wires as shown in Wiring Diagram. Carefully replace Junction Box Cover
Assembly (14).
F.- Select a Trim: from the Label inside the Housing. Use Only Lamp Types approved for the Trim chosen.
DO NOT EXCEED MAXIMU M LISTED WATTAGE
(Ceiling Opening is to be 4-3/8" Di a .)
This Instruction Sheet is also intended to be used as a Paint Shield.
Upon completion of installation, crumple this sheet up and insert it up into the Housing to protect the Socket and Labels
from being spray painted.
PAGE 1 of 4
