  • Page 1 September 2003 Z600...

  • Page 2: Purpose Of This Document

    The Sony Ericsson Z600 White Paper is designed to give the reader a deeper technical understand- ing of how the Z600 is designed, and of how it interacts with other media. This document will make it easier to integrate the Z600 with the IT and communications solutions of a company or organi- zation.

  • Page 3: Table Of Contents

    Polyphonic ring signals ...20 Bluetooth™ wireless technology ...20 Using Bluetooth wireless technology in the Z600 ...21 Synchronize calendar and phone book ...21 SyncML, an open standard for remote synchronization in the Z600 ...22 Local synchronization ...24 WAP services ...25 Bearer type characteristics ...27 Gateway characteristics ...27...
  • Page 4 Enhanced message service ...58 Multimedia message service ...60 Bluetooth technical data ...62 Performance and technical characteristics ...62 Tone and percussion maps in the Z600 ...63 Percussion map ...66 WAP browser technical data ...67 WAP Operator technical data ...69 GPRS technical data ...73 Built-in GSM data modem technical data ...76...

  • Page 5: Product Overview

    Product overview Z600 is a dynamic and easy to use high-end mobile phone. It offers complete imaging and messaging capabilities that allow family and friends to capture, share and preserve those special moments. Designed for fun-loving people, the Z600 features a distinctive clam shell body cloaked in vibrant, youthful colours.

  • Page 6: Key Functions And Features

    (CIF) resolution (352x 288 pixels) and 24 bit colour depth. The lens is recessed into the front cover of the Z600. The viewfinder will fill up the whole screen, irrespective of the resolution at which the picture is taken. A dedicated hardware button provides fast access to the camera application.

  • Page 7: Exchangeable Front And Back Covers

    The keys to efficiency The lay out of the keys is one of the many new and improved elements in the Z600, helping the user to find functions and features in the phone quickly and easily. Conveniently and ergonomically grouped together on the front, the two soft keys, a navigation key, the back key and the “C”...

  • Page 8: More Features

    The main menu gives an overview of all functions and features in the phone. Actions in the Z600 are always carried out in the most efficient way, and there is always a visible sta- tus bar at the top of the display. The status bar extends the usage of non voice features by dis- playing icons and indicators of ongoing actions.

  • Page 9: Technologies In Detail

    Multimedia in Z600 Graphics Graphics (tables, charts, diagrams and layouts) have a major impact on the way we work. The Z600 supports JPEG (max 640x480), GIF (max 160x120), WBMP (max 320x320) and animated GIFs. With ply select a picture, add a message and send just like an SMS message or build a slide show with several images and your favourite sound clips.

  • Page 10: Mms (Multimedia Messaging Service)

    Z600 also allows downloading of sounds and melodies. MMS (Multimedia Messaging Service) One of the key features in the Z600 is the Multime- dia Messaging Service (MMS), this is expected to become the preferred messaging method of mobile terminal users, since there are virtually no limits to the content of an MMS transmission.

  • Page 11: Mms Objects

    PIM communication with MMS With MMS in the Z600, it is easy to send and receive business cards, calendar entries and notes. Business card (vCard) With MMS in the Z600, the user can send a busi- ness card.

  • Page 12: Benefits

    WAP is used as bearer of an MMS mes- sage between the MMS-C and the MMS client (application). The WAP Gateway is used for delivery and retrieval of messages. Z600 White Paper September 2003...

  • Page 13: Message Conversion

    EMS gives the user the ability to send and receive melodies. These can be pre-defined sounds, downloaded from the Internet, received in SMS messages or composed by the user on the phone keypad or a PC. Z600 White Paper September 2003...

  • Page 14: Messaging Using Ems

    EMS. Voice and e-mail notifications Notifying mobile phone users that they have new voice or fax mail messages waiting - including icons or melodies with EMS. Z600 White Paper September 2003...
  • Page 15 These may develop further in the future to support access via PC over the Internet, from the phone using WAP and even with an SMS request interface. Z600 White Paper September 2003...

  • Page 16: Java

    Applications are easily downloaded directly to the Z600 using the browser, or may be installed from a connected PC. Applications such as the currency converter can obtain the latest exchange rates from the Mobile Internet and then make up-to-date calculations.

  • Page 17: General Information

    The Sony Erics- son portal for downloading of free games for the Z600 is accessible with only one key press in the games menu. The openness of the downloadable games solution is dedicated to provide an enhanced gaming experience.
  • Page 18 Game file sizes Each game has its own directory in the file system. A game directory in the Z600 can contain up to 16 different files but together they may not exceed an aggregate of 480 000 bytes.The maximum size of files for downloading depends on the size of the WAP gateway.

  • Page 19: Game Controls

    Exit the game. MIDI - Musical Instrument Digital Interface The Z600 contains an advanced MIDI composer that allows the user to compose melodies and ring signals in polyphonic sound. A MIDI signal or file does not contain any music. It contains binary data...

  • Page 20: Polyphonic Ring Signals

    300 Hz to 3400 Hz, which is good enough for speaking, but quite poor for music. The Z600 can handle up to 15000 Hz, equivalent to an FM stereo radio, which means excellent sound quality.

  • Page 21: Using Bluetooth Wireless Technology In The Z600

    The information is kept updated by syn- chronizing with the information at the office or at home. Hierarchical phone book with contacts The Z600 features a hierarchical phone book. For every contact, details such as name, home, work and mobile numbers, pager number, e-mail Z600...

  • Page 22: Syncml, An Open Standard For Remote Synchronization In The Z600

    The hierarchical phone book in the Z600 is compatible with most groupware and agenda programs, such as Microsoft Outlook, enabling smooth local syn- chronization of contact information between the SyncML, an open standard for remote synchronization in the Z600 SyncML –...

  • Page 23: Benefits Of A Common Synchronization Protocol

    With SyncML, application developers will be able to develop an application that can connect to a more diverse set of devices and network data. Z600 White Paper September 2003...

  • Page 24: Local Synchronization

    This is vital if, for example, each member in a work group has his/ her own Z600, and needs to synchronize with a PC. It makes it easy, for example, to download a com- mon company phone directory to the phone book in each company mobile phone.

  • Page 25: Wap Services

    • Support is handled by Sony Ericsson. XTNDConnect PC All users of the Z600 can easily upgrade to the full version of the synchronization software. A number of features and supported applications will then be added, including XTNDConnect Phone Viewer.
  • Page 26 WAP Gate- way, allowing HTML-based services to be viewed on the WAP browser of the Z600. An XHTML page can be viewed in both the WAP browser and in any standard Web (HTML) browser.

  • Page 27: Bearer Type Characteristics

    WAP services on the Internet, simply by switching WAP profile. Bearer type characteristics The Z600 accesses WAP services over IP. IP can be provided either over GSM Data, HSCSD or GPRS, depending on network services. Typical differences which distinguish the bearer types are listed below.

  • Page 28: Security Using The Wap

    WAP gateway is necessary. An icon in the display of the Z600 indicates when a secure connection is in use. The Z600 is based on the WAP 2.0 (WML 1.3) specification suite, in which security functionality is specified by a technology called Wireless Transport Layer Security (WTLS).

  • Page 29: Push Services

    WAP settings To simplify the configuration of WAP settings in the Z600, all settings can be sent to the phone as an SMS message. This makes it easy for an operator, a service provider or a company to distribute set- tings for Internet/intranet, and WAP, without the user having to configure the phone manually.

  • Page 30: Chtml Support

    Several data con- nections can be saved in the Z600. To make it eas- ier for the user, data connections can be provided by the operator via OTA provisioning.

  • Page 31: General Packet Radio Services

    53,600 bps. The GSM system limits the ability to use all eight time slots, so the Z600 uses up to four time slots for receiving data, and one slot for transmitting. This means the speed for receiving data is up to 85,600 bps and up to 21,400 bps for sending data.

  • Page 32: Interruption Of Gprs Data Account

    GPRS. Interruption of GPRS data account When the user is browsing with a Z600 the GPRS connection will be automatically disconnected when an incoming call is received. This is the default behaviour. However, it is possible for opera-...

  • Page 33: At Commands Support

    AT commands support This section outlines the AT commands supported by the Z600. The information here can be of use for advanced users, to indicate the possibilities they have to: • develop new communications software • add the Z600 to an application’s list of compati- ble modems •...

  • Page 34: Sony Ericsson Developer Support

    Infrared transceiver Infrared communication creates a data link between two communications devices through an infrared beam of light. On the Z600, this link is used to connect with desktop computers, PDAs, Sony Ericsson handheld computers, laptop PCs, other phones and other hardware supporting the stand- ard.

  • Page 35: Connection Via Cable

    Z600 White Paper Connection via cable The infrared connection is not always the best solution when connecting to a PC/PDA. Indeed, it is not always even possible. The DRS-11 cable and the USB cable DCU-11 provides the same connec- tivity between the phone and another unit.

  • Page 36: Facts And Figures

    Call functions Call counter Call barring* Call divert* Call hold* Call list (last dialled, answered and missed calls) Yes, only limited by memory Yes, built-in Yes, (25) Yes, outgoing and total (not incoming) Yes, 30 entries Z600 White Paper September 2003...
  • Page 37 Yes, supporting IMAP4, POP3, SMTP. Yes, with 30 pre-defined pictures, 15 pre- defined animations and 4 melodies. Yes. At the purchase of the Z600 phone, there is up to 2.0 Mb of memory space for own objects such as pictures, sounds and themes.
  • Page 38 T9 Text Input, multitap alphabetic (GSM standard) Yes, Music DJ Yes, dynamic memory allocation: 2.0 Mb Yes, built-in (max. data rate 108,800 bit/ Yes, five-way Yes, up to 10 – depending on size. 510 numbers in phone + SIM Z600 White Paper September 2003...
  • Page 39 Limited by the memory Yes, storage capacity only limited by the memory Yes, storage capacity only limited by the memory Yes, via EMS, MMS, infrared and Blue- tooth wireless technology Long “C” 3V and 5V Z600 White Paper September 2003...
  • Page 40 Enhanced, Full and Half Rate. AMR sup- ported where available. Yes, via RS232 cable, USB, infrared and Bluetooth wireless technology Yes, 4 Yes, limited only by memory Yes, via MMS, infrared and Bluetooth wireless technology Z600 White Paper September 2003...

  • Page 41: Network-Dependent Features

    WAP browser WTLS for added WAP security* Network-dependent features SMS and EMS messaging The Z600 is capable of sending and receiving SMS and EMS messages, and linked messages. • With the Short Message Service, a user can send text messages containing up to 160 characters to and from GSM mobile stations •...

  • Page 42: Fixed Dialling And Restricted Calls

    All necessary setup and programming is distributed to users over the air, directly to their phones. In the Z600, a separate menu is available for functions residing on the SIM card. These can include submenus for controlling...

  • Page 43: Sim At Services Supported By The Z600

    SIM AT services supported by the Z600 Service CALL CONTROL CELL BROADCAST DOWN- LOAD DISPLAY TEXT GET INKEY GET INPUT Mode Text of up to 240 characters (120 ucs2 coded). bit 1: 0 = normal priority 1 = high priority...
  • Page 44 '01' = File Change Notification '02' = SIM Initialization and File Change Notifi- cation '03' = SIM Initialization '04' = SIM Reset bit 1: 0 = packing not required 1 = SMS packing by the ME required Z600 White Paper Support September 2003...
  • Page 45 '04' = User activity '05' = Idle screen available '06' = Card reader status '07' = Language selection '08' = Browser termination '09' = Data available 'OA' = Channel status Z600 White Paper Support Applica- Yes, 1 row of text is...

  • Page 46: User Interaction With Sim At

    If the SIM AT Menu Item is selected by pressing ‘Select’ all the items sent in the Set Up Menu command will be available for selection, in the same way as the Select Item command. Z600 White Paper September 2003...

  • Page 47: Security And M-Commerce Technical Data

    Access to the WIM Terminology and abbreviations 3GPP 3rd Generation Partnership Project. Support in the Z600 for m-commerce If separate card, no If separate card, no If separate card, no If separate card, no R99 with exceptions (missing AT commands, for example “Launch browser”...
  • Page 48 Accesses and displays Internet content in a mobile phone, using small file sizes and the bandwidth of the wireless-handheld network. MIDP Mobile Information Device Profile. A J2ME profile connected to the CLDC configuration and aimed at mobile phones. Man-Machine Interface. Z600 White Paper September 2003...
  • Page 49 The card can be a small plug-in type or credit card- sized, but both types have the same functions. The Z600 uses the small plug-in card. Short Message Service. Allows messages of up to 160 characters to be sent and received via the net- work operator's message centre to a mobile phone.

  • Page 50: Related Information

    World Wide WAP (WWW). In contrast to HTML, WML is designed to fit small handheld devices. Related information Documents • The Z600 User’s Guide • Sony Ericsson Z600 FAQ • AT Command Reference Manual • WAP June2000 (WAP 2.0) Specification Software •...

  • Page 51: Technical Specifications

    • T9 is a registered trademark of Tegic Technical specifications The consumer pack includes: • Mobile Phone Z600 • Battery • Travel Charger • CD containing Windows SW package for the phone; Extended Systems XTNDConnect Server syn-...

  • Page 52: General Technical Data

    Status display Main display 2nd display Antenna Z600 Tri-band. GSM phase 2 recommendations. GSM 900 (3GPP TS 51.010- 1), GSM 1800 (3GPP TS 51.010-1) and GSM 1900 (NATWG 03), e-GSM supported Enhanced, Full and Half Rate. AMR supported where available for high...

  • Page 53: Ambient Temperatures

    Keypad lock: from standby, Lock keys in More list. It is also possible to select Auto key lock in the Settings menu. Use of several keys simultaneously (e.g. for games) is possible. Max: +50×C, Min -10×C Max: +85×C, Min -40×C Max: +45×C, Min +4×C Z600 White Paper September 2003...

  • Page 54: Current Consumption, Talk And Standby Times

    182 bits 78 bits Message displayed on screen The messages are queued in order to be read in the same order they were received. CBMI and CBMID Z600 White Paper Enhanced full rate ACELP 12.2 Kbp/s 20 ms 244 bits...
  • Page 55 Ability to display in a understandable way a message with a DCS “language unspecified” whatever language is set in the SIM card Ability to extract a phone number or short number of a CB message to re-use it Support of multi-page CB-messages Z600 White Paper September 2003...

  • Page 56: Short Message Service

    “SIM archive” or “Sent items” folders know the remaining capacity storage Support in the Z600 It is possible to pre-record the SMS Service Centre Number. It is possible to insert a picture or an icon into the text message.
  • Page 57 Possibility to write an e-mail address as a recipient address SMS storage Nokia Picture Messaging Support in the Z600 Yes (only to the sender, not to all or part of the message recipients) Yes, using Phone Book groups or by adding more...

  • Page 58: Enhanced Message Service

    Sounds I-melody Melodies WBMP Picture sizes Support in the Z600 Enhanced Messaging Service (EMS) according to the standard 3GPP TS 23.040 v4.3.0, with the addition of the ODI feature from 3GPP TS 23.040 v5.0.0. 100 messages It is possible to...
  • Page 59 Feature Pictures Animations TP-PID field value given by the handset before sending an EMS message Support in the Z600 It is possible to... • edit and create pictures by using the phone keypad. • send and receive pictures via EMS. If the pictures are not protected by copyright.

  • Page 60: Multimedia Message Service

    Actions that the user can perform after mes- sage notification: Support in the Z600 MMS is bound to a WAP profile. A WAP profile is bound to a Data Account. A Data Account contains either CSD parameters or GPRS parameters.

  • Page 61: Instant Messaging/ Chat

    MMS User Agent will report problems to user in case of: Instant messaging/ Chat Feature Support of instant messaging Chat application Support in the Z600 • reply to the sender of the message • reply to the sender and to Cc people •...

  • Page 62: Bluetooth Technical Data

    Performance and technical characteristics Dimension Frequency range Channel spacing Support in the Z600 This product is manufactured to meet Bluetooth Specification 1.0b and is designed to work with V1 devices. Dial-up Networking Profile File Transfer Profile Generic Access Profile...

  • Page 63: Tone And Percussion Maps In The Z600

    Receiver RX Bit error rate Tone and percussion maps in the Z600 The Z600 has a tone bank of 128 (0-127) sampled instruments. The instruments are complemented by 47 percussion sounds, see table number two. Echo effects are possible. Tone map...
  • Page 64 Pad 1 (new age) Pad 2 (warm) Pad 3 (polysynth) Pad 4 (choir) Pad 5 (bowed) Pad 6 (metallic) Pad 7 (halo) Pad 8 (sweep) Fx1 (rain) Fx2 (soundtrack) Fx3 (crystal) Fx4 (atmosphere) Fx5 (brightness) Fx6 (goblins) Z600 White Paper September 2003...
  • Page 65 Banjo Shamisen Koto Kalimba Bag pipe Fiddle Shanai Tinkle Bell Agogo Steel Drums Woodblock Taiko Drum Melodic Tom Synth Drum Reverse Cymbal Guitar Fret Noise Breath Noise Seashore Bird Tweet Telephone Ring Helicopter Applause Gunshot Z600 White Paper September 2003...

  • Page 66: Percussion Map

    Low Conga High Timbale Low Timbale High Agogo Low Agogo Cabasa Maracas Short Whistle Long Whistle Short Guiro Long Guiro Clavas Hi Wood Block Low Wood Block Mute Cuica Open Cuica Mute Triangle Open Triangle Z600 White Paper September 2003...

  • Page 67: Wap Browser Technical Data

    Reload page Tables User Agent Profiles WAP/WML WAP Support in the Z600 WAP browser Yes, HSCSD, ISDN and analog Yes, up to 25 named bookmarks for easy access to frequently visited pages Yes, can be sent and received as link using SMS and vBookmark for-...
  • Page 68 WAP browser WAP profiles WTLS (security) Support in the Z600 WAP browser *) When creating WML applications, it is recommended that you always save the page contents as UTF8, and that this is clearly indi- cated in the pages before publishing. This ensures that the contents of the application can be viewed, regardless of character sets used in gateways and the phone.

  • Page 69: Wap Operator Technical Data

    Security mechanism OTA provisioning (if empty) Interface (if empty) Re-provisioning (Set 1 filled) Interface (Set 1 filled) Carrier reset/provisioning Support in the Z600 for WAP 2.0 baseline XHTML, mobile profile Name Startpage IP settings: CSD phone no., CSD Data rate, CSD dial type...
  • Page 70 SI/content retrieval postponing SI menu structure accessability SL reception warning SIA reception warning Support in the Z600 for WAP Not used for provisioning. The SWIM is only used for WAP security, both WTLS connections and digital signatures. Both client and trusted certificates can be used for WTLS connections and digital signatures.
  • Page 71 Downloaded object solution UAP indication for downloading Support in the Z600 for WAP Depending on the size of the push messages. Around 20 push messages with a size of 500 bytes can be stored. Yes. WAP services/options/common/Push access/Off No.
  • Page 72 Number of display lines for a WAP connection Pop-up menus Radio buttons Check boxes Buttons Support in the Z600 for WAP Yes. Store, delete, forward, use, manage. audio/iMelody, other/eMelody, vMel. Image/WBMP, GIF, JPEG. Image/WBMP, GIF, JPEG. Yes, 4-6 pre-loaded and 5-7 at Sony Ericsson Mobile Internet.

  • Page 73: Gprs Technical Data

    GPRS technical data Dimension Support in the Z600 Compatible GPRS and ETSI R97 SMG 31 bis SMG specifications Data rates Multislot class 8 supported (4+1) CS-1, CS-2, CS-3, CS-4 9,050 bps, 13,400 bps, 15,600 bps, 21,400 bps supported (network- dependent)
  • Page 74 Dimension Support in the Z600 Support of the QoS modi- Yes, when initiated by the network fication procedure (not by the handset) Interfaces to external IrDA, RS-232, AT commands. IrDA, devices supported by the Datarate=SIR & MIR RS232, auto- handset and available for...
  • Page 75 Dimension Support in the Z600 AT commands supported • • • • AT+CGDCONT - DEFINE • PDP CONTEXT AT+CGQREQ - Quality of • Service Profile (REQUESTED) AT+CGQMIN - Quality of Service Profile (Minimum Acceptable) AT+CGATT - PACKET DOMAIN SERVICE ATTACH...

  • Page 76: Built-In Gsm Data Modem Technical Data

    GSM Data communication, no compres- sion with V.42bis compression up to four times higher transmission rates depending on the data type Support in the Z600 e-mail client Yes (outgoing, images only) Yes, HSCSD, ISDN and analog US ASCII (All variants)
  • Page 77 Feature OTA Support Supported protocols Support in the Z600 e-mail client ISO8859-2 All variants ISO8859-5 All variants ISO8859-10 All variants KOI8-R All variants WIN1251 All variants WIN1252 (All variants UTF7 (All variants) UTF8 All variants GB2312 BIG5 GB18030 POP3, IMAP4, SMTP...

  • Page 78: Ussd Technical Data

    Images – downloading to phone Feature File type EMS icons WBMP GIF, WBMP, Support in the Z600 GSM Phase 1/ 2 (Cross-phase compatibility). GPRS behavior according to class B MMI-mode supported. No application mode support (not needed for any application).
  • Page 79 WAP: Can not show animations in the WAP Browser. You can download maximum 3kb. The animation will be shown in the Image Browser if it’s saved in the phone. GIF: Animations used as background images or user greetings displays first frame only. Phon Cable IrDA e-to- phon Z600 White Paper Yes, 1) September 2003...

  • Page 80: September

    No. Set stati- Detect) cally CTS (Clear To Send) Support for Sync ML in the Z600 The handset is fully SyncML compliant (it passed both Syn- cML Conformance and Inter operability testing [SyncFest]) Contacts: vCard 2.1, Calendar: vCalendar 1.0, Tasks: vTodo 1.0.
  • Page 81 Statically connected with DTR Ready) DTR (Data Termi- Statically connected with DSR nal Ready) GND (Signal Ground) RI (Ring Indica- No. Set stati- tion) cally RTS (Request To Send) Rx (Received Data) Tx (Transmitted Data) Z600 White Paper September 2003...
  • Page 82 News & commercials Online Services OTA configuration Overview of AT command functions Performance and technical characteristics Push inbox Push services Related information Restricted Calls Z600 White Paper ... 73 ... 27 ... 52 ... 78 ... 78 ... 15 ... 53 ...
  • Page 83 ...14 User-to-user ...78 USSD technical data ...15 Vehicle positioning ...18 Vibrator ...11 Video ...63 WAP browser technical data ...69 WAP Operator technical data ...28 WAP, security ...52 Weight XTNDConnect PC ...34 ...47 ...50 Z600 White Paper ... 25 September 2003...
