Summary of Contents for Apposite Linktropy 5500
- Page 2 Los Angeles, CA 91316 USA 1.310.477.9955 info@apposite-tech.com www.apposite-tech.com Copyright ©2005-2017 Apposite Technologies LLC. All rights reserved. Apposite, Linktropy, and Netropy are registered trademarks of Apposite Technologies LLC. The Apposite logo and “WAN Emulation Made Easy” are trademarks of Apposite Technologies LLC. Part No. DOC-HG-L5510-L13...
-
Page 3: Table Of Contents
9 Apposite Support ............................12 Appendix A: Specifications ..........................13 Appendix B: Regulatory ............................ 14 Federal Communications Commission Notice ..................14 Canadian Notice / Avis Canadien ......................14 CE Certification ............................14 Appendix C: Apposite End User License Agreement ..................15... -
Page 4: Overview
VERVIEW This Linktropy 5510 Hardware Guide describes the physical hardware of the Linktropy 5510 WAN Emulator. The companion User’s Guide describes the installation, configuration, and operation of the Linktropy WAN emulation functionality. A separate Quick Start Guide provides a walk-through for first time configuration. -
Page 5: Included Items
NCLUDED TEMS The Linktropy 5510 shipping carton contains the following items: Linktropy 5510 hardware unit Rack mount brackets (2) and screws (6) Linktropy Quick Start Guide AC power cord (U.S.) RJ45 to DB-9 serial cable 2 Included Items... -
Page 6: Front And Rear Panels
RONT AND ANELS 3.1 Front Panel Standard RJ45 Interface Version Optional SFP Interface Version The front panel of the Linktropy 5510 contains: Power LED: Lit green when the unit is powered on. Unlit when power is off. CONSOLE: Console interface using RS-232 with an RJ45 connector. See Section 8 for a pin-out of the console interface. -
Page 7: Rear Panel
3.2 Rear Panel The rear panel of the Linktropy 5510 contains: Power input: Standard IEC C14 socket for power input. U.S. and Canadian customers should use the supplied power cord to connect the Linktropy 5510 to a power outlet. International customers may need to substitute a local power cord with a standard IEC C13 plug. -
Page 8: Capacity Limitations
The listed values are based on actual data throughput, not link bandwidth settings. Users who need to emulate latencies close to these limits are advised to contact Apposite to discuss their specific requirements. Frame Size... -
Page 9: Rack Mounting
OUNTING The Linktropy 5510 includes a pair of brackets for mounting the device into a standard 19” rack. Attach the brackets to both sides of the unit using three of the supplied screws with each bracket as shown in the diagram below. 5 Rack Mounting... -
Page 10: Rj45 Interfaces
RJ45 I NTERFACES The standard version of the Linktropy 5510 includes two RJ45 10/100/1000baseT ports for emulation, labeled LAN A and LAN B, and a separate RJ45 10/100/1000baseT port for management. The ports are set by default to auto-negotiate the proper speed and duplex settings, and flow control is turned off. -
Page 11: Sfp Interfaces (Optional)
SFP I NTERFACES OPTIONAL The Linktropy 5510 is optionally available with Gigabit Ethernet small form-factor pluggable (SFP) interfaces, also known as mini-GBIC, for the LAN A and LAN B interfaces. SFP interfaces are modular and support both fiber-optic and copper-based cabling depending on the installed transceiver. -
Page 12: Console Interface
ONSOLE NTERFACE Console access to the Linktropy 5510 is through the RJ45 interface on the front panel labeled “CONSOLE.” An RJ45 to DB-9 cable is included with the unit to connect the device to a standard PC serial port. The pin-out for the RJ45 interface is shown below: Definition Definition CTS/RTS... -
Page 13: Apposite Support
For units with an unlimited term license (purchased prior to August 2017), one year of maintenance is included with purchase, after which a yearly maintenance renewal is required for ongoing support. License and maintenance renewals are available from Apposite or your Linktropy reseller. -
Page 14: Appendix A: Specifications
A: S PPENDIX PECIFICATIONS Capacity Max. Emulation Rate 1 Gbps full duplex Max. Packet Rate 2,976,200 packets per second (full line rate all packet sizes) Interfaces Network 2 x 10/100/1000baseT Copper Gigabit Ethernet or 2 x SFP Gigabit Ethernet Management 1 x 10/100/1000baseT Copper Gigabit Ethernet Console 1 x RS-232... -
Page 15: Appendix B: Regulatory
B: R PPENDIX EGULATORY Federal Communications Commission Notice This equipment has been tested and verified to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 16: Appendix C: Apposite End User License Agreement
Apposite maintenance services, or (b) for any Product that is not a Legacy Product, the License Period, unless such Product has a perpetual license, in which case the Warranty Period shall be five (5) years from the date of purchase of the Product from Apposite unless extended by purchase of maintenance services. - Page 17 Agreement. Apposite and its suppliers’ entire liability and your sole and exclusive remedy shall be, at Apposite’s sole discretion, to: (i) repair the Software or Hardware; (ii) provide replacement Hardware or Software;...
- Page 18 You may terminate it at any time by destroying all copies of the Software and Documentation in your possession. The licenses granted by Apposite herein will terminate immediately if you fail to comply with any term or condition of this Agreement. You agree on termination of the licenses to cease all use of the Software and Documentation.
- Page 19 Apposite ® Technologies LLC 17835 Ventura Blvd., Suite 211 Los Angeles, CA 91316 USA 1.310.477.9955 info@apposite-tech.com www.apposite-tech.com...
