Description
Table Of Contents......................................................1
Revision List........................................................2
Important Safety Notice.....................................3
1.Monitor Specification...............................................4
2. LCD Monitor Description........................................5
3. Operation Instruction...................................................6
3.1. General Instructions.........................................6
3.2. Control Button...................................................6
3.3. OSD Menu...........................................................8
4. Input/Output Specification.......................................11
4.1. Input Signal Connector.........................................11
4.2. Power Supply Requirements...............................12
4.3. Factory Preset Display Modes...............................13
4.4. Panel Specification..........................................14
5. Block Diagram.....................................................20
5.1. Software Flow Chart........................................20
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
R FOR TH
UNIT WHEN S
TABLE OF CONTENTS
Page
Description
5.2. Electrical Block Diagram...........................22
6. Schematic.....................................................25
6.1. Main Board...................................................25
6.2. Power Board.............................................29
6.3. Key Board...............................................34
7. PCB Layout....................................................35
7.1. Main Board.................................................35
7.2. Power Board..........................................38
7.3. Key Board...................................................43
8. Maintainability................................................44
8.1. Equipments and Tools Requirement..............44
8.2. Trouble Shooting.......................................45
9. White-Balance, Luminance adjustment............53
10. Monitor Exploded View...............................55
11. BOM List................................................57
SAFETY NOTICE
1
LANIX LX700B&LX900B
Horizontal Frequency
31-75 KHz
Page
Advertisement
Table of Contents
Related Manuals for Lanix LX700B
Summary of Contents for Lanix LX700B
-
Page 1: Table Of Contents
17"& 19” LCD Color Monitor LANIX LX700B&LX900B Service Service Service Horizontal Frequency 31-75 KHz TABLE OF CONTENTS Description Page Description Page 5.2. Electrical Block Diagram………………..22 Table Of Contents..……......…..1 Revision List.…........……..2 6. Schematic……………........25 6.1. Main Board………..........25 Important Safety Notice.……....……..3 1.Monitor Specification......………..4 6.2. -
Page 2: Revision List
17"& 19” LCD Color Monitor LANIX LX700B&LX900B Revision List Revision Customer Version Release Date TPV Model Name History Model LX700B T7RHM5NPWW2LNN Aug 5, 2008 Initial release LX900B T98SM5NPX22LAN... -
Page 3: Important Safety Notice
LANIX LX700B&LX900B Important Safety Notice Proper service and repair is important to the safe, reliable operation of all LANIX Company Equipment. The service procedures recommended by LANIX and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. -
Page 4: Monitor Specification
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 1. Monitor Specifications 1) Lanix Monitor LX700B Widescreen Liquid Crystal Monitor of 17" Visible Area of Screen 17" (433mm) Model LX700B 0.255mm Dot Pitch Max Resolution: 1440 x 900 @75Hz Contrast Ratio (typical):600:1 Plug &... -
Page 5: Lcd Monitor Description
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 2. LCD Monitor Description The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage. -
Page 6: Operation Instruction
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor (See Figure). By changing these settings, the picture can be adjusted to your personal preferences. - Page 7 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B 1. Souce (LX2200B) 2. Auto Config 3. Eco Mode/- 4. + 5. Menu/Enter 6. Power Button & Indicator...
-
Page 8: Osd Menu
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 3.3 OSD Menu OSD Settings Press the MENU-button ( ) to activate the OSD window. Press to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate sub-menu. Once the desired function is highlighted, press MENU-button to activate Press to change the settings of the selected function. - Page 9 17"& 19” LCD Color Monitor LANIX LX700B&LX900B Function Control Illustration Luminance Adjust Range Description Brightness 0-100 Backlight Adjustment Contrast 0-100 Contrast from Digital-register. Standard Standard Mode Eco mode Text Text Mode Internet Internet Mode Game Game Mode Movie Movie Mode...
- Page 10 17"& 19” LCD Color Monitor LANIX LX700B&LX900B Demo on or off Disable or Enable Demo Picture Boost Frame Size 0-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast 0-100 Adjust Frame Contrast 0-100 Adjust Frame Hue Saturation 0-100 Adjust Frame Saturation H.
-
Page 11: Input/Output Specification
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 4. Input/Output Specification 4.1 Input Signal Connector Analog connectors Pin No. Description Pin No. Description Video-Red Video-Green Detect Cable Video-Blue N.C. N.C. DDC-Serial data Ground H-sync GND-R V-sync GND-G DDC-Serial clock GND-B VGA connector layout DVI connectors Pin No. -
Page 12: Power Supply Requirements
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 4.2 Power Supply Requirements A/C Line voltage range 100 V ~ 240 V 50 3Hz, 60 3Hz A/C Line frequency range Current 1.5A max at 100V; 0.8A max at 240 V Peak surge current <... -
Page 13: Factory Preset Display Modes
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 4.3 Factory Preset Display Modes LX700B Horizontal Vertical Stand Resolution Frequency(kHz) Frequency(Hz) Dos-mode 720 × 400 31.47kHz 70Hz 640x480 31.469 kHz 59.94 Hz 640x480 37.861 kHz 72.809 Hz 640x480 37.5 kHz 75 Hz 800x600 35.156 kHz... -
Page 14: Panel Specification
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 4.4 Panel Specification 4.4.1 General Features LX700B HannStar Display model HSD 170MGW1-B00 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panle, a driving cirruit and a back light system. - Page 15 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 4.4.2 Display Characteristics LX700B LX900B...
- Page 16 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 4.4.3 Electrical Characteristics (1) TFT-LCD LX700B LX900B...
- Page 17 17"& 19” LCD Color Monitor LANIX LX700B&LX900B (2) Backlight LX700B LX900B...
- Page 18 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 4.4.4 Optical Characteristics LX700B...
- Page 19 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B...
-
Page 20: Block Diagram
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 5. Block Diagram 5.1 Software Flow Chat... - Page 21 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 1) MCU initializes. 2) Is the EPROM blank? 3) Program the EPROM by default values. 4) Get the PWM value of brightness from EPROM. 5) Is the power key pressed? 6) Clear all global flags.
-
Page 22: Electrical Block Diagram
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 5.2 Electrical Block Diagram 5.2.1 Main Board Panel Interface (CN403) Scalar TSUM1PFR-LF Keypad Interface EEPROM (Include MCU, ADC, OSD) (CN401) M24C16 (U403) (U401) (U9) H sync V sync (U1) Flash Memory Crystal D-Sub Connector SST25VF010A-33-4C 14.31818MHZ... - Page 23 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 5.2.2 Inverter/Power Board LX700B AC input Bridge Rectifier Transformer Rectifier diodes EMI filter and Filter Start Circuit: R904, R932, R933 CN902 Feedback Circuit Control IC ON/OFF Output Transformer MOSFET Circuit ON/OFF Lamp Control...
- Page 24 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B AC input Bridge Rectifier Transformer Rectifier diodes EMI filter and Filter Start Circuit: R904, R905, R906 CN902 Feedback Circuit Control IC ON/OFF Output Transformer MOSFET Circuit ON/OFF Lamp Control Feedback Circuit Control IC （IC801）...
-
Page 25: Schematic
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 6. Schematic 6.1 Main Board 715G2904 1 H_Sy nc R101 0R05 1/10W 5% R102 100R 1/16W 5% DSUB_H V_Sy nc R103 100R 1/16W 5% FB102 DSUB_V R104 C101 VGA_B+ DSUB_B+ VCC3.3 R105 R106... - Page 26 17"& 19” LCD Color Monitor LANIX LX700B&LX900B AVDD VDDP VDDC VCC3.3 VDDP AVDD FB401 U401 VCC3.3 300OHM VCTRL VCTRL C403 C404 LVA3P 0.1uF/16V 0.1uF/16V DSUB_R+ RIN0P LVA3M DSUB_R- RIN0M PA[0..1] DSUB_G+ PA[0..1] GIN0P DSUB_G- GIN0M LVA2P DSUB_SOG SOGIN0 LVA2M DSUB_B+...
- Page 27 17"& 19” LCD Color Monitor LANIX LX700B&LX900B PANEL_VCC CN403 PA[0..1] PB[0..9] PA[0..1] PB[0..9] R434 C420 PA[4..9] PA[4..9] 330 OHM 1/4W 0.1uF/16V CMVCC 2006-11-7 Add pull up 4K7 to MVCC AO3401L CMVCC R433 C419 R435 10K 1/16W 5% 0.1uF/16V PANEL_VCC 4K7 1/16W 5%...
- Page 28 17"& 19” LCD Color Monitor LANIX LX700B&LX900B ESD_VCC 2 DSUB_5V CMVCC DSUB_5V 2 5, 6 CMVCC R458 VCC3.3 VCC3.3 D401 BAV99 CN404 VCC3.3 R437 R439 CMVCC1 SM340A D402 10K 1/16W 5% 10K 1/16W 5% CMVCC CMVCC1 VCC1.8 CMVCC BKLT-EN Q410...
-
Page 29: Power Board
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 6.2 Power Board LX700B 715G2852 2 D909 NC/31DQ10FC R918 L904 100 OHM 1/4W 2A(INVERTER) R919 100 OHM 1/4W +16V FB904 C912 R920 BEAD 0.001uF ZD902 100 OHM 1/4W R946 RLZ18B 150 OHM 2W... - Page 30 17"& 19” LCD Color Monitor LANIX LX700B&LX900B CN801 28:28:2400 Lk:260mH CONN T801 R801 0R05 1/8W C801 18pF/6KV L801 +16V NC / L R802 CN802 100R 1/8W C825 CONN 18pF/6KV R804 0R05 1/8W R805 NC/4K7 1/10W 5% R810 Q802 R808 Q801...
- Page 31 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B 715G2824 2 2 D909 NC/31DQ10FC R918 L904 100 OHM 1/4W 2A(INVERTER) R919 100 OHM 1/4W +16V FB904 C912 R920 BEAD 0.001uF ZD902 100 OHM 1/4W R946 RLZ18B 150 OHM 2W C917 FB902...
- Page 32 17"& 19” LCD Color Monitor LANIX LX700B&LX900B CN801 28:28:2400 Lk:260mH CONN T801 R801 0R05 1/8W C801 18pF/6KV L801 +16V NC / L R802 CN802 100R 1/8W C825 CONN 18pF/6KV R804 0R05 1/8W R805 NC/4K7 1/10W 5% R810 Q802 R808 Q801...
- Page 33 17"& 19” LCD Color Monitor LANIX LX700B&LX900B +5V1 +5V1 C604 R602 R603 C609 CN602 R609 IC601 NC CN601 LOUT- R604 SE/BTL LOUT- VOLUME C601 LOUT+ LIN- LOUT+ C606 ROUT+ R605 RIN- ROUT+ BY PASS ROUT- SHUTDOWN ROUT- +5V1 R611 C605...
-
Page 34: Key Board
17"& 19” LCD Color Monitor LX700B/LX900B 6.3 Key Board 715G2835 1... -
Page 35: Pcb Layout
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 7. PCB Layout 7.1 Main Board 715G2904 1... - Page 36 17"& 19” LCD Color Monitor LANIX LX700B&LX900B...
- Page 37 17"& 19” LCD Color Monitor LANIX LX700B&LX900B...
-
Page 38: Power Board
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 7.2 Power Board LX700B 715G2852 2... - Page 39 17"& 19” LCD Color Monitor LANIX LX700B&LX900B...
- Page 40 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B 715G2824 2 2...
- Page 41 17"& 19” LCD Color Monitor LANIX LX700B&LX900B...
- Page 42 17"& 19” LCD Color Monitor LANIX LX700B&LX900B...
-
Page 43: Key Board
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 7.3 Key Board 715G2835 1... -
Page 44: Maintainability
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 8. Maintainability 8.1 Equipments and Tools Requirement Voltmeter. Oscilloscope. Pattern Generator. DDC Tool with an IBM Compatible Computer. Alignment Tool. LCD Color Analyzer. Service Manual. User Manual. -
Page 45: Trouble Shooting
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 8.2 Trouble Shooting 8.2.1 Main Board (1). No Power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U404 PIN2=3.3V... - Page 46 17"& 19” LCD Color Monitor LANIX LX700B&LX900B (2). No Picture No picture The button if X401 oscillate Replace X401 under control waveform is normal Check reset circuit of Check Correspondent component U401 is normal Measure U404 PIN2=3.3V Q409 V =1.8V...
- Page 47 17"& 19” LCD Color Monitor LANIX LX700B&LX900B (3). White screen White screen Measure Q404 base X401 oscillate waveform is normal is low level? Replace X401 Check Q404, Q405 is broken or CN403 solder? Check reset circuit of U401 is normal...
- Page 48 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 8.2.2 Power/Inverter Board LX700B 1.) No power Check CN902 pin4, 5 = 5V Check AC line volt 110V or 220V Check AC input Check the voltage of C907 (+) Check bridge rectified circuit and F901 circuit...
- Page 49 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 2.) W / LED, No Backlight Check CN902 pin4, 5 = 5V Check adapter or MB Check ON/OFF signal Check Interface board Check IC801 PIN12=12V pin9=12vvoltage of C905(+) Change Q808 Check IC801 PIN10, 9 have the output of square wave at short...
- Page 50 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B 1.) No power Check CN902 pin3, 4 = 5V Check AC line volt 110V or 220V Check AC input Check the voltage of C905 (+) Check bridge rectified circuit and F901 circuit...
- Page 51 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 2.) W / LED, No Backlight Check CN902 pin3, 4 = 5V Check adapter or MB Check ON/OFF signal Check Interface board Check IC801 PIN12=16V pin9=12vvoltage of C905(+) Change Q801 Check IC801 PIN10, 9 have the output of square wave at short...
- Page 52 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 8.2.3 Key Board OSD is unstable or not working Connect Key Pad Board Is Key Pad Board connecting normally? Replace Button Switch Is Button Switch normally? Replace Key Pad Board Is Key Pad Board normally?
-
Page 53: White-Balance, Luminance Adjustment
= 313 ±30, y = 329 ±30, Y>150cd/m 3. Into Factory mode of LANIX LX700B&LX900B Press the MENU button, pull out the power cord, and then plug the power cord. Then the factory OSD will be at the left top of the panel. - Page 54 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 3. The LCD-indicator on chroma 7120 will show x = 302 ±30, y = 318 ±30, Y>150cd/m 4. Adjust the RED on factory window until chroma 7120 indicator reached the value R=100 5. Adjust the GREEN on factory window until chroma 7120 indicator reachedthe value G=100 6.
-
Page 55: Monitor Exploded View
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 10. Monitor Exploded View LX700B LX700B... - Page 56 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B LX900B...
-
Page 57: Bom List
17"& 19” LCD Color Monitor LANIX LX700B&LX900B 11. BOM List LX700B T7RHM5NPWW2LNN Location Part No. Description Remark 050G 600 2 HANDLE1 050G 600 3 HANDLE2 052G 1150 C INSULATING TAPE 052G 1185 1 BIG TAPE 052G 1186 SMALL TAPE 052G 1211 A CONDUCTIVE TAPE 55MM *45MM *0.08MM... - Page 58 17"& 19” LCD Color Monitor LANIX LX700B&LX900B U401 056G 562557 IC TSUM1PFR-LF U404 056G 563 52 IC AP1117D33L-13 TO252-3L DIODES U102 056G 662 13 IC AZC099-04S SOT23-6L U103 056G 662 13 IC AZC099-04S SOT23-6L U402 056G1133 74 SST25VF010A-33-4C-SAE Q404 057G 417 6...
- Page 59 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R406 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R404 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R121 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R120 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R436...
- Page 60 17"& 19” LCD Color Monitor LANIX LX700B&LX900B C412 065G0402220 31 CHIP 22PF 50V NPO C408 065G0402224 17 CAP CER 0.22UF -20%-80% C101 065G0402473 12 CHIP 0.047UF 16V X7R C105 065G0402473 12 CHIP 0.047UF 16V X7R C106 065G0402473 12 CHIP 0.047UF 16V X7R...
- Page 61 17"& 19” LCD Color Monitor LANIX LX700B&LX900B D001 081G 12 1F GP LED 3ΦGP32032M/G307-ZY-50-C R003 061G0603000 1F RST CHIPR 0 OHM +-1% 1/10W R005 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R004 061G1206200 1F RST CHIPR 2.0 KOHM +-1% 1/4W...
- Page 62 17"& 19” LCD Color Monitor LANIX LX700B&LX900B BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON BD901 093G 50460502 KBP206G D905 093G3006 1 1 31DQ06FC3 NIHON INTER CN902 095G 82510D 3 HARNESS 10P(SCN)-9P 120MM CN902 095G 82510Q 3 HARNESS 10P(SCN)-9P 120MM...
- Page 63 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R818 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R824 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R827 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R926 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W...
- Page 64 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R837 061G0805473 RST CHIPR 47K OHM +-5% 1/8W R810 061G0805510 2F RST CHIPR 51K OHM +-1% 1/8W JR801 061G1206000 RST CHIPR 0 OHM +-5% 1/4W JR901 061G1206000 RST CHIPR 0 OHM +-5% 1/4W...
- Page 65 17"& 19” LCD Color Monitor LANIX LX700B&LX900B C820 065G080522131G CAP CHIP 0805 220PF G 50V NPO C845 065G0805225 12 CAP CHIP 0805 2.2UF K 16V X7R C909 065G0805471 21 CAP CHIP 0805 470PF J 25V NPO C929 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R...
- Page 66 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R946 061G152M15152T RST MOFR 150 OHM +-5% 2WS R914 061G152M47852T RST MOFR 0.47 OHM +-5% 2WS C906 065G 2K152 1T6213 CAP CER 1500PF K 2KV C903 067G 2152207NT KY50VB22M-TP5 5*11 CAP 105 ℃ 22UF M 50V KINGNICHI...
- Page 67 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 071FPE19301 02 FP2 EEL19 01 Q12G6300 64 WASHER Q15G0249201 MAIN FRAME Q33G0170BCS 1L0100 KEY PAD Q33G0171 1 1C0100 LENS Q34G0275BCSA2B0130 BEZEL L17WA-8Q2 Q34G0276ABJ 4B0100 REAR COVER 17 Q40G000260811A BASIC LABEL Q41G7800880 1A LX900B QSG...
- Page 68 17"& 19” LCD Color Monitor LANIX LX700B&LX900B LX900B T98SM5NPX22LAN Location Part No. Description Remark 050G 600 2 HANDLE1 050G 600 3 HANDLE2 052G 1150 C INSULATING TAPE 052G 1185 1 BIG TAPE 052G 1186 SMALL TAPE 052G 1207 A CONDUCTIVE TAPE 45MM *25MM *0.08MM...
- Page 69 17"& 19” LCD Color Monitor LANIX LX700B&LX900B CN101 088G 35315F HD D-SUB CONN F ATTACHED SCREW X401 093G 22 53 J 14.31818MHZ/32PF/49US U401 056G 562557 IC TSUM1PFR-LF U404 056G 563 52 IC AP1117D33L-13 TO252-3L DIODES U102 056G 662 13 IC AZC099-04S SOT23-6L...
- Page 70 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R433 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R421 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R417 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R408 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R407...
- Page 71 17"& 19” LCD Color Monitor LANIX LX700B&LX900B C422 065G0402104 15 MLCC 0402 0.1UF K 16V X5R C428 065G0402104 15 MLCC 0402 0.1UF K 16V X5R C432 065G0402104 15 MLCC 0402 0.1UF K 16V X5R C102 065G0402220 31 CHIP 22PF 50V NPO...
- Page 72 17"& 19” LCD Color Monitor LANIX LX700B&LX900B SW001 077G 600 1A HJ TACT SWITCH 5PIN SW005 077G 600 1A HJ TACT SWITCH 5PIN SW003 077G 600 1A HJ TACT SWITCH 5PIN SW004 077G 600 1A HJ TACT SWITCH 5PIN SW002...
- Page 73 17"& 19” LCD Color Monitor LANIX LX700B&LX900B CAP 105 ℃ 470UF M 25V C805 067G215P4714AV C811 067G215P4714AV CAP 105 ℃ 470UF M 25V C917 067G215P6814AV CAP 105C 680UF M 25V C918 067G215P6814AV CAP 105C 680UF M 25V C916 067G215S102 3K...
- Page 74 17"& 19” LCD Color Monitor LANIX LX700B&LX900B 0M1G1730 8120 SCREW Q90G6263 6 HEAT SINK U801 056G 379 22 IC TL494IDR SOIC-16 U901 056G 379 98 IC LD7552DPS SOP-8 Q903 057G 417 4 PMBS3904/PHILIPS-SMT(04) Q811 057G 417 4 PMBS3904/PHILIPS-SMT(04) Q810 057G 417 4...
- Page 75 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R605 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W R609 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W R809 061G0603105 RST CHIPR 1M OHM +-5% 1/10W R817 061G0603105 RST CHIPR 1M OHM +-5% 1/10W R821...
- Page 76 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R802 061G0805101 1ST CHIPR 100 OHM +-5% 1/8W R939 061G0805102 RST CHIPR 1K OHM +-5% 1/8W R925 061G0805102 RST CHIPR 1K OHM +-5% 1/8W R938 061G0805103 RST CHIPR 10K OHM +-5% 1/8W R843...
- Page 77 17"& 19” LCD Color Monitor LANIX LX700B&LX900B R909 061G1206519 RST CHIPR 5.1 OHM +-5% 1/4W C610 065G0603101 31 CER1 0603 NP0 50V 100P PM5 R C611 065G0603101 31 CER1 0603 NP0 50V 100P PM5 R C932 065G0603102 32 1000PF +-10% 50V X7R...
- Page 78 17"& 19” LCD Color Monitor LANIX LX700B&LX900B C828 065G0805472 32 CAP CHIP 0805 4700PF K 50V X7R C910 065G0805473 32 CHIP 0.047UF 50V X7R C912 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R C929 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R...
- Page 79 17"& 19” LCD Color Monitor LANIX LX700B&LX900B J819 095G 90 23 JUMPER J820 095G 90 23 JUMPER J821 095G 90 23 JUMPER J818 095G 90 23 JUMPER J817 095G 90 23 JUMPER J816 095G 90 23 JUMPER J815 095G 90 23...
- Page 80 17"& 19” LCD Color Monitor LANIX LX700B&LX900B Q90G6295 3 HEAT SINK L905 S73G25391V CHOKE COIL ASS'Y L904 S73G25391V CHOKE COIL ASS'Y L903 S73G25391V CHOKE COIL ASS'Y T801 S80GL20T510V TRANSFORMER ASS'Y Q34FPE19P06 CASE EEL19 T802 S80GL20T510V TRANSFORMER ASS'Y Q34FPE19P06 CASE EEL19...
