MEMORY STORAGE UNIT
SR-R1000
INSTALLATION MANUAL
1st Edition
Serial No. 10001 and Higher: SR-R1000 (SY)
Serial No. 50001 and Higher: SR-R1000 (CN)

Advertisement

Table of Contents
loading

Related Manuals for Sony SR-R1000

Summary of Contents for Sony SR-R1000

  • Page 1 MEMORY STORAGE UNIT SR-R1000 INSTALLATION MANUAL 1st Edition Serial No. 10001 and Higher: SR-R1000 (SY) Serial No. 50001 and Higher: SR-R1000 (CN)
  • Page 2 : MAINTENANCE connector : NETWORK 1 connector : NETWORK 2 connector Follow the instructions for the above port(s). For kundene i Norge Dette utstyret kan kobles til et IT-strømfordelingssystem. SR-R1000...
  • Page 3 6. When performing the installation, keep the following space away from walls in order to obtain proper exhaust and radiation of heat. Right, Left: 4 cm (1.6 inches) or more Rear: 15 cm (6 inches) or more 1 (P) SR-R1000...

  • Page 5: Table Of Contents

    Combination of Option Boards ......1-21 (E) 1-14-2. Option Board Installing/Removing Procedures ............1-23 (E) 1-14-3. Checking Recognition of SRK-R201/ SRK-R202 by the Unit ........1-24 (E) 1-14-4. Settings after Installing SRK-R201/ SRK-R202 ............1-25 (E) 1-15. Ejecting SRMemory (Memory Card) Manually ..1-27 (E) 1 (E) SR-R1000...

  • Page 7: Purpose Of This Manual

    Manual Structure Purpose of this manual This manual is the installation manual of Memory Storage Unit SR-R1000. This manual is intended for use by trained system and service engineers, and provides the information that is required to install (operating environment, installation space, connection information, initial setting, etc.) and the setting check...

  • Page 9: Installation

    Settings when Connecting the Unit to an Editing Device * Operation check If an error message appears on the time data display area, refer to the operation manual. (For more details, refer to the maintenance manual volume 1.) 1-1 (E) SR-R1000...

  • Page 10: Operating Environment

    1-3. Operating Environment 1-4-2. Recommended Power Cord This unit does not come with a power cord. To get a power cord, please contact your local Sony Sales Do not block any air vents in the cabinet and exhaust vents Offi ce/Service Center.
  • Page 11 1 Power cord 250 V 10 A (2.0 m): ! 1-551-631-15 2 Plug holder: 3-613-640-01 AC inlet For customers in China 1 Power cord 250 V 10 A (1.8 m): ! 1-830-860-11 2 Plug holder: 3-613-640-01 AC inlet 1-3 (E) SR-R1000...

  • Page 12: Installation Space

    540.7 Mass of this unit (not including option) : approx. 19 kg 45.5 577 (Maximum traveling distance) 15.9 12.7 31.5 123.8 263.5 457.5 n Remove the feet when rack mounting. Unit : mm Dimensions when Rack-Mounting 1-4 (E) SR-R1000...

  • Page 13: Rack Mounting

    (Refer to Fig. 2.) . Adjust the temperature inside the rack within the range of the unit’s operating temperature. (Refer to Section 1-3.) 1-5 (E) SR-R1000...
  • Page 14 1 pc Keep the removed screws and legs in a safe place. When using this unit outside the rack, be sure to reattach the legs. Tightening torque: 98 x 10 N . m {10 kgf . cm} 1-6 (E) SR-R1000...
  • Page 15 Rack angle Inner rail Inner rail When replacing a Sony’s 5U-size VTR with this unit in the rack, attach the inner rails at the lower part. The bottom plate of this unit is at the same height of the bottom plate of the 5U-size VTR.
  • Page 16 Ball retainer Ball retainer Outer rail Outer rail Rail fixing bracket Rail fixing bracket B4 x 8 B4 x 8 50 to 55 mm 50 to 55 mm B4 x 8 B4 x 8 Rack angle Rack angle 1-8 (E) SR-R1000...
  • Page 17 When the unit is fully pushed into the rack, the lock mech- anism is activated and the unit can no longer be pulled out. To pull out the unit in this state, pull it out while pressing the unlock buttons on the rack angles. 1-9 (E) SR-R1000...

  • Page 18: Connectors And Cables

    1-7. Connectors and Cables Use the following connectors (or cables) or equivalent for cable connection. Panel Indication Applicable Connector (Cable) Sony Part No. Remarks BNC 75 Z, MALE TIME CODE INPUT 1-569-370-12 TIME CODE OUTPUT AUDIO MONITOR OUTPUT L, R...

  • Page 19: Connector Input/Output Signals

    4 REF. INPUT External reference video signal . HD (Tri-level SYNC): 0.6 V p-p, 75 Z . SD (Black burst or composite SYNC): NTSC: 0.286 V p-p, 75 Z (terminated) 0.3 V p-p, 75 Z (terminated) PAL: 1-11 (E) SR-R1000...
  • Page 20 D-SUB 9-pin x 1 != VIDEO CONTROL For connection to HD digital video controller (HKDV-900) RJ-45 8-pin x 2 ![ NETWORK 1/2 1000BASE-T D-SUB 25-pin x 1 !] GPIO (25P) USB type x 1 !\ MAINTENANCE RJ-45 8-pin x 1 1-12 (E) SR-R1000...
  • Page 21 (External View) Pin No. Signal Name TXD (+) TXD (_) RXD (+) RXD (_) *1: Input ; 47 kZ pull up to +5 V (close/open) Output ; 10 kZ pull up to +5 V (0 V or open) 1-13 (E) SR-R1000...

  • Page 22: Setting Switch On The Connector Panel

    1. Close the control panel while lifting the right and left stays gently with index fi ngers as shown in the fi gure. Stay Stay When closing the control panel completely, be careful not to catch the control panel cable. 1-14 (E) SR-R1000...

  • Page 23: System Setting Method

    Exec Exec Exec Disable Disable Exec Exec Exec Exec Exec Exec 29.97 29.97 Exec Exec DELETE DELETE ENTRY ENTRY F10 (EXEC) F10 (EXEC) (EXECUTE) (EXECUTE) F9 (SYSTEM FRQUENCY) F9 (SYSTEM FRQUENCY) 6. System reboot is automatically activated. 1-15 (E) SR-R1000...

  • Page 24: Setting Port

    (EXECUTE) 6. Press the [F9] (SET) key. If the signal format combination selected in step 5 is not included in the formats supported by the unit, the [F9] (SET) key is grayed out disabling operation for determination. 1-16 (E) SR-R1000...

  • Page 25: Setting Metadata

    LINE3 LINE3 EXIT EXIT Exec Exec DELETE DELETE ENTRY ENTRY MULTI CONTROL MULTI CONTROL F9 (META DATA SET) F9 (META DATA SET) Recorded uncompressed lines are played and output with- out any processing in the playback mode. 1-17 (E) SR-R1000...

  • Page 26: Storing And Reading System Settings In

    BANK4 BANK5 BANK5 BANK6 BANK6 BANK7 BANK7 BANK8 BANK8 EXIT EXIT Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec F1 (USER BANK) F1 (USER BANK) (EXECUTE) (EXECUTE) 1-18 (E) SR-R1000...
  • Page 27 Bank6 Bank7 Bank7 Bank8 Bank8 EXIT EXIT Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec Exec DELETE DELETE ENTRY ENTRY (EXECUTE) (EXECUTE) (BANK1 - BANK8) (BANK1 - BANK8) 1-19 (E) SR-R1000...

  • Page 28: Reference System

    Table 1-13-2. Settings of VTR Constant Values of Editing Device (Typical Hexadecimal Values) Frame Rate VTR CONSTANT 1 VTR CONSTANT 2 Data Number Data Number 29.97PsF, 59.94i / 1080 59.94P / 720 25PsF / 50i / 1080 23.98PsF, 24PsF / 1080 1-20 (E) SR-R1000...

  • Page 29: Removing/Installing Plug-In Boards

    1-14-1. Combination of Option Boards Ports for mounting option boards are defi ned depending on the system confi guration. Mount option boards according to the port confi guration table of each system confi guration and the fi gure below (SR-R1000 Rear View).
  • Page 30 (Option: SRK-R202) (Option: SRK-R202) Port C ENC-134 board (Option: SRK-R201) Port D DEC-176 board DEC-176 board DEC-176 board (SR-R1000 regulationequipment) (SR-R1000 regulationequipment) (SR-R1000 regulationequipment) Port Confi guration Table (3 Output Ports) 0 Input/3 Output 1 Input/3 Output configuration configuration Port A...

  • Page 31: Option Board Installing/Removing

    1. Turn off the power switch on the rear of the SR-R1000 1-14-2. Option Board Installing/Removing Procedures and disconnect the power cable from the power outlet. 2. Remove the two screws to detach the blank panel. SRK-R201 (ENC-134 board) and SRK-R202 (DEC-176 Keep the removed blank panel in a safe place.

  • Page 32: Checking Recognition Of Srk-R201

    1. Turn on the power and press the [DIAG] button while DEC-176 board that was installed in Port D when the pressing the [SFT] (Shift) key. SR-R1000 was shipped. This procedure also applies when removing a board from another port. The MAINTENANCE INFORMATION menu is displayed.

  • Page 33: Settings After Installing Srk-R201

    Section 1-14-2 is displayed in the lines of PORT A to SRK-R202 PORT D. Port Setting 1. Turn on the power and press a PORT SELECT button SR-R1000 Version Information SR-R1000 Version Information S/N: 001009 S/N: 001009 R: 000% E: 000% E: 000% E: 000% R: 000% E: 000% E: 000% E: 000% from [A] to [D] to select a port.
  • Page 34 YPbPr 10b 2D SQ YPbPr 10b 2D SQ Out : Out : 1920X1080 1920X1080 YPbPr 10b 2D YPbPr 10b 2D SR-R1000, the [F9] (SET) key is grayed out disabling CLOSE CLOSE operation for determination. PORT CONFIG SET PORT CONFIG SET 00:00:00:00 00:00:00:00...

  • Page 35: Ejecting Srmemory (Memory Card) Manually

    Salvage processing or formatting is in progress due to an error. Disabled Fast Blink red An error is detected during SRMemory processing. Take appropriate Enabled actions (such as ejection or salvage) according to the guidance displayed on the control panel. 1-27 (E) SR-R1000...
  • Page 36 (width: 4 mm) at the front of the top surface of the memory card and pull the memory card in the arrow direction. Be careful not to damage the memory card. Flat-blade screwdriver Flat-blade screwdriver or the like or the like Slot Slot Memory card Memory card 1-28 (E) SR-R1000...
  • Page 37 H01: OPERATION HOURS H02: M1 SLOT COUNTER H03: M2 SLOT COUNTER H04: M3 SLOT COUNTER H05: M4 SLOT COUNTER H12: M1 SLOT COUNTER (resettable) H13: M2 SLOT COUNTER (resettable) H14: M3 SLOT COUNTER (resettable) H15: M4 SLOT COUNTER (resettable) A-1 (E) SR-R1000...
  • Page 38 Installation Information of Input/Output Ports Write down input/output boards mounted in the ports on the rear of the SR-R1000. Port Board Serial Number PORT A ENC-134 board □ DEC-176 board □ PORT B ENC-134 board □ DEC-176 board □ PORT C ENC-134 board □...
  • Page 39 Board Switch No. Factory Setting (■ : Knob position) HP-160 KY-662 S200 S201 MIX-123 S200 SY-350 S101 S1002 S601 S1501 S1601 S1802 S1703 A-3 (E) SR-R1000...

  • Page 42: Sony Corporation

    SR-R1000 (SY) Printed in Japan Sony Corporation SR-R1000 (CN) J, E 2011. 7 08 4-284-752-01 ©2011...
