Summary of Contents for Pro-X XW-HDU04pro
- Page 1 XW-HDU04pro...
-
Page 2: Table Of Contents
Table of Contents 1.IMPORTANT INFORMATION ......2.SAFETY PRECAUTIONS ........1 3.INTRODUCTION ..........2 4.FEATURES............3 5. INTERFACES.............3-5 6.SPECIFICATION ..........6 7.OPERATION ............7-11 8.TROUBLE SHOOTING ........12 9.PACKING CONTENT ......... 13... -
Page 3: Important Information
■ When damages caused by accidents include but not limited to lightning, water or fire. ■ The serial number on the product has been altered, deleted, removed or made illegible. ■ PRO-X Co.,Ltd reserves the right to make changes to the information or specifications without prior notification. Safety Precautions... -
Page 4: Introduction
Therefore a license for radio station use is not required to operate this product. ■ Optimal distance of working between XW-HDU04pro TX (transmitter) and XW-HDU04pro RX (receiver) is between 3 meters and 300 meters LOS (line of sight). Introduction... -
Page 5: Features
The transmission distance of approximately 300m is not guaranteed. In locations with many other devices operating in 5GHz frequencies, operation of the set can be affected, and video may be interrupted. XW-HDU04pro TX USB Port for Firmware Update 3.5mm Headset Jacket... - Page 6 XW-HDU04pro RX Link Status LED Indicator Frequency Point LED Display Video LED Indicator for LINKMUTE Video Input Signal VIDEO Frequency Point Change &Select Button Video Signal Intensity CH/OK LED Indicators Register Button ■Video Signal Intensity LED Indicators The wireless video signal intensity RX receives will be calculated and indicated by 5 green LEDs.
- Page 7 XW-TI XW-TI is for wireless intercom and switch of TALLY signals, and makes it able to connect PRO-X wireless systems and commonly used switchers for the integration of wireless devices. Front Panel 2-Wire Audio and TALLY IN DC IN 1.RED (TALLY Signal Red Indicator) 2.MIC/SPK (2-Wire Audio Connector)
-
Page 8: Interfaces
Time Code LTC; VITC Transmission Distance 300m LOS (line of sight) Latency Less than 1 millisecond Frequency 5.1GHz~5.9GHz Interfaces XW-HDU04pro TX XW-HDU04pro RX Audio/Video SDI Input SDI Output HDMI Intput HDMI Output Tally/Intercom 3.5mm mini jack Power Switch on Operation Panel... -
Page 9: Operation
Wireless Video Transmission 1.Install Antennas RX: Screw seven antennas (blade style rubber duck antenna) to antenna connectors, and tilt them as in below picture. 2.Cable Connect and Power the Set For TX: Connect HD device’s SDI output connector to the SDI IN of TX with SDI cable. Connect camera’s HDMI output connector to the HDMI IN of TX with HDMI cable. - Page 10 Connect switcher’s SDI input to SDI OUT of RX with SDI cable. Connect DC IN on RX and AC power source with the adaptor, or you can mount a PRO-X battery on RX and turn the power switch on. Digital HD Monitor...
- Page 11 3.Power On When TX and RX all connected with power source, turn the power switch on and frequency point LED display lights up. Power Switch LINKMUTE VIDEO Frequency Point LED Display When the input signal is identified, VIDEO LED on TX stays on. LINKMUTE CH/OK VIDEO...
- Page 12 Wireless Intercom With headset and microphone, wireless intercom can be available between TX and RX via headset or microphone. ■ When the connection is established, you can talk wirelessly. ■ If the connection is not established successfully, you can press and hold REG button for 3 seconds and the unit is in register mode, and LINK LED flashes quickly.
- Page 13 4.When an external power supply is used, power failure can be avoided by mounting a PRO-X V Type or 3-Stud mount lithium ion battery to the set at the same time. If the external power supply fails, operation continues via battery power.
-
Page 14: Trouble Shooting
Trouble shooting Fault Solutions ● Check the battery mounted is available. Power LED ● Check the power plugs of TX and RX are properly connected doesn’t light up to a functioning power outlet. ● Make sure the power sources connected to TX and RX are functional. -
Page 15: Packing Content
Standard Packing Please check whether the following items are present in the package. If not, please contact your dealer. Description Quantity XW-HDU04pro TX XW-HDU04pro RX Headset XW-TI SP-1BPJ Power Supply DC IN Cable (2-pin) DC IN Cable (4-pin) PT-2BP Cable...
