- Page 1 Ejector SCPi Maintenance Instructions WWW.SCHMALZ.COM EN · 30.30.01.02074 · 00 · 06/19...
- Page 2 Failure to follow the instructions in these maintenance instructions can lead to life-threatening injuries! Schmalz is not liable for damage or malfunctions that result from failure to heed these instruc- tions. If you still have questions after reading the technical documentation, contact Schmalz service at: www.schmalz.com/services...
- Page 3 Warranty IMPORTANT! A warranty claim can only be accepted by Schmalz if the ejector has been installed and used in ac- cordance with the corresponding operating instructions. In the case of inappropriate handling or use of force, any warranty and liability claims shall be void.
- Page 4 Safety Safety Maintenance work may only be carried out by qualified personnel. WARNING Risk of injury due to incorrect maintenance or troubleshooting Check the proper functioning of the product, especially the safety features, after every maintenance or troubleshooting operation. NOTE Improper maintenance Damage to the ejector! Switch off the supply voltage before any maintenance.
-
Page 5: Replacing The Silencer
Compressed air connection 1 (suction) Bypass for exhaust air Type plate 2 Vacuum connection Replacing the silencer This manual provides you with all the necessary information to replace a silencer on an SCPi. Accessories, wearing parts set Article/part Designation Description number 10.02.02.03381... - Page 6 Removing the silencer 4.2 Replacing the silencer The ejector is disconnected from the compressed air supply and the power supply. The vacuum and compressed air system is subjected to atmospheric pressure. 1. Loosen the fastening screws 2. Pull the cover and silencer downward to remove them 3 mm 6 / 9...
- Page 7 Mounting the silencer Mounting the silencer 1. Attach the new silencer el- ement to the basic body of the ejector 2. Tighten the fastening screw (0.4 Nm tightening torque) = 0.4 Nm EN · 30.30.01.02074 · 00 · 06/19 7 / 9...
- Page 8 Connecting the SCPi to the compressed air and power supply Connecting the SCPi to the compressed air and power supply WARNING The silencer is not secured with the fastening screw. When compressed air is supplied, individual components are accelerated and fly around.
