- Page 1 User’s Manual Network Control Input Unit IP-1000CI Thanks for your purchase of TOA products IP-1000 series. Please read the manual carefully to ensure the machine operating in long time and fault-free. TOA Corporation...
- Page 2 Chapter 1 Safety precaution...
-
Page 3: Chapter 1: Safety Precaution
Chapter 1: safety precaution Please abide by the warning and the relevant safety tips. Please take this manual in convenient place after you reading the guide for future reference. Warning The sign means there is potential safety hazard, when operate wrong may result in death or serious injury. - Page 4 Chapter 2 Products description...
-
Page 5: Chapter 2: Products Description
Chapter 2: products description 2.1Summary 2.1Summary IP-100CI is an IP control input unit, which is used for receiving alarm signal from fire center and trigger to broadcasting warning announcement. High speed industrial grade dicaryon ARM+DSP chip, starting time ≤3s. ... -
Page 6: Interface Description
Chapter 2: products description 2.2 Interface description 2.2 Interface description 2.2.1 Front view ① POWER: power switch and power indicator light. - Page 7 Chapter 2: products description 2.2 Interface description 2.2.2 Rear view ①DATA PORT: data upgrade interface, it’s used for firmware upgrade. ②LAN：RJ45 network interface, and it connect with Ethernet switch. ③Alarm output terminal: provide 8-way switching value (Stem node) signal, the interface is normally open contact, the contact capacity is DC24V/1A.
- Page 8 Chapter 3 Wiring...
-
Page 9: Chapter 3: Wiring
Chapter 3: wiring 3.1 Wiring 3.1 IP-1000CI Wiring diagram... - Page 10 Chapter 3: wiring 3.2 Reference size 3.2 Reference size (unit: mm)
- Page 11 Chapter 4 Operating description...
-
Page 12: Chapter 4: Operating Description
Chapter 4: operating description 4.1 Fire alarm 4.1 Fire alarm After adding the fire alarm task in the server, and after the task was triggered, it will automatically broadcast the specified audio program by server. Please add the fire alarm task to the server according to the following steps. - Page 13 Chapter 5 Appendix...
-
Page 14: Chapter 5: Appendix
Chapter 5: appendix 5.1Specification 5.1.1 Network Control Input Unit IP-1000CI Model number IP-1000CI Suitable voltage AC185V～260V Suitable mains frequency 50～60Hz Alarm output terminal Alarm input terminal Functional unit terminal Power input terminal Data upgrade terminal Network input terminal Network protocol TCP/IP、UDP、ARP、ICMP、IGMP protocol... - Page 15 TOA Corporation 201611...
