IMPULSE BassStation™
PC10, PC12 Powered Car & PT8, PT10
Powered Truck Subwoofer Systems
The KICKER Impulse BassStation is a great way to easily and economically
add real KICKER bass to you system. Installation is simple, and the sound is
ALL KICKER!

Features of the Impulse BassStations

• Built-In Amplifier
• Active Electronic Crossover – 90Hz at 12dB with equalization circuit.
• Universal Inputs
• Audio-Activated Auto Turn-On
• Gain Control
• Lower Power Requirements – Full power requires less than 10 Amps of current.
The position of your KICKER Impulse BassStation will affect the quality and the amount
of the bass it reproduces. The best results will come from boundary loading the output of
the BassStations into the corners of the vehicle. Both PC & PT speaker systems contain
woofer(s) on the front side of the enclosure and then ports on either end, depending on
model and amplifier location. Directing the ports toward specific locations in the vehicle will
control which portion of the bass gets reinforced. Firing the ports into the corners of the
vehicle will boost the lower frequencies while positioning the ports away from the corners
will increase the output of the upper bass.
Model
Subwoofer
PC10
10 Inch
PC12
12 Inch
PT8
8 Inch
PT10
10 Inch
Common to all Models:
Input Sensitivity – 100mV to 10V
Crossover – 90Hz at 12dB/octave
All manuals and user guides at all-guides.com

Installation Information

Specifications

Frequency
Length
Response (Hz)
35-90
18"
32-90
20-1/2"
38-90
19"
35-90
21-1/2"
Top Width
Base Width
10-3/16"
12-3/4"
11-1/16"
14"
4"
6-7/8"
4-3/16"
7-1/4"
Height
12-1/4"
14"
13-1/16"
14-1/2"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kicker IMPULSE BassStation PC10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stillwater Designs Kicker IMPULSE BassStation PC10

  • Page 1 All manuals and user guides at all-guides.com IMPULSE BassStation™ PC10, PC12 Powered Car & PT8, PT10 Powered Truck Subwoofer Systems The KICKER Impulse BassStation is a great way to easily and economically add real KICKER bass to you system. Installation is simple, and the sound is ALL KICKER! Features of the Impulse BassStations •...
  • Page 2 All manuals and user guides at all-guides.com Mounting After determining the mounting position, turn the enclosure upside-down and attach the four mounting brackets to the bottom of the enclosure using the enclosed small screws. Each bracket must be positioned so the rounded end protrudes approximately 3/4 inch from under the cabinet to allow a screw to easily pass through it for attachment to the vehicle.
  • Page 3 All manuals and user guides at all-guides.com Wiring The power wire for your BassStation should be connected directly to the vehicle’s battery using an appropriate connector, or you can use a high-current tap in the fuse box, if one is available. A 10 Amp fuse should be inserted in the power lead within 18 inches or less from the power source.
  • Page 4 Defective merchandise must be returned to your local Authorized Stillwater Designs (Kicker/Impulse) Dealer for warranty. Assistance in locating an Authorized Dealer can be obtained by writing or calling Stillwater Designs direct. You can confirm that a dealer is authorized by asking to see a current author- ized dealer window decal.
