4L Air Cooler
Please read and retain these instructions for future reference
Power Details:
Voltage:
220-240V a.c.
Frequency:
50/60Hz
Wattage:
65W
Max water injection rate: 4L
Room size capacity: up to 8m
Noise level: 53-57dB
Please read this instruction manual thoroughly before starting and ensure you are familiar with
the operation of your new Air Cooler.
FUNCTIONS
•
Principle of Cooling: Water is pumped from the water tank to the top, then the water drops into the
paper evaporator. When the water in the paper evaporator evaporates, the air is cooled. People will
feel cool air delivered by the fan.
•
Electronics control: Safe and durable, attractive appearance.
•
Adjustable speed and fan mode: There are three speeds and fan modes. Cool air is blown at a wide
oscillation angle.
•
Cool: With the technology of ice crystal cooling and air humidifying, the cool temperature from the
air vent raises relative humidity and prevents air drying. To increase the cooling effect, ice boxes can
be placed into the top and lower tank.
•
Deliver cool air at a wide angle: The blades oscillate automatically emitting cold air at a wide
horizontal range. The blades can be manually swung transversely.
•
Far-range remote control: The range of the remote control is 6 metres at a 60 degree wide angle.
•
Buzzer: Audible alert when operating the keypad.
ASSEMBLING AND FILLING WITH WATER
1. Assembling castors: Put the appliance on a flat surface. Using the spanner (supplied) assemble the
castors.
2. Filling with water: Pull out the bottom water tank by 1/3 and add clean water (Fig 1)
Attention:
a) Check the level of water in the bottom water tank before adding water.(Fig 2)
11441
2
Instructions for Use
v002:18/06/19
Advertisement
Table of Contents
Related Manuals for Coopers of Stortford HydroBreeze 11441
Summary of Contents for Coopers of Stortford HydroBreeze 11441
- Page 1 4L Air Cooler 11441 Instructions for Use Please read and retain these instructions for future reference v002:18/06/19 Power Details: Voltage: 220-240V a.c. Frequency: 50/60Hz Wattage: Max water injection rate: 4L Room size capacity: up to 8m Noise level: 53-57dB Please read this instruction manual thoroughly before starting and ensure you are familiar with the operation of your new Air Cooler.
- Page 2 4L Air Cooler 11441 Instructions for Use Please read and retain these instructions for future reference v002:18/06/19 b) The level of water should not exceed the “MAX” mark on the scale at any time. When humidifying, the total level of water should not be below the “MIN” scale. c) Put ice cubes or frozen ice box into the top or bottom water tank if you want to lower the temperature further.
- Page 3 4L Air Cooler 11441 Instructions for Use Please read and retain these instructions for future reference v002:18/06/19 REMOTE CONTROL Fit CR2025 3V batteries. The 6 function keys on the remote control are the same as on the control panel. Point the remote control at the receiver/sensor.
- Page 4 • CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS CONTINUOUSLY SUPERVISED. • THE USE OF ANY ACCESSORY ATTACHMENTS NOT RECOMMENDED BY COOPERS OF STORTFORD MAY CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE. • DO NOT LET THE POWER CABLE HANG OVER THE EDGE OF A TABLE OR COUNTER, OR TOUCH HOT SURFACES.
- Page 5 4L Air Cooler 11441 Instructions for Use Please read and retain these instructions for future reference v002:18/06/19 Clean the air filter screen (Fig 4) 1. Unplug from supply, pull the handle of the air filter screen and remove it from the appliance. Clean the air filter screen with a neutral detergent and banister brush, then clean it with clear water.
- Page 6 4L Air Cooler 11441 Instructions for Use Please read and retain these instructions for future reference v002:18/06/19 Troubleshooting Malfunction Causes Solution 1. Power off or poor 1. Plug in the power cord No function connection. and make sure it 2. “ON” key on the control connects well.
- Page 7 8L Air Cooler Instructions for Use 11442 Please read and retain these instructions for future reference v001: 05/06/19 Power Details: 220-240V 50/60Hz Max water injection rate: 8L Room size capacity: up to 12 m Noise level: 57-60 dB Please read this instruction manual thoroughly before starting and ensure you are familiar with the operation of your new Air Cooler.
- Page 8 8L Air Cooler Instructions for Use 11442 Please read and retain these instructions for future reference v001: 05/06/19 2. Filling with water: Pull out the bottom water tank by 1/3 and add clean water (Fig 1) Attention: a) Check the level of water in the bottom water tank before adding water.(Fig 2) b) The level of water should not exceed the “MAX”...
- Page 9 8L Air Cooler Instructions for Use 11442 Please read and retain these instructions for future reference v001: 05/06/19 REMOTE CONTROL Fit CR2025 3V batteries. The 6 function keys on the remote control are the same as on the control panel. Point the remote control at the receiver/sensor.
- Page 10 • CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS CONTINUOUSLY SUPERVISED. • THE USE OF ANY ACCESSORY ATTACHMENTS NOT RECOMMENDED BY COOPERS OF STORTFORD MAY CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE. • DO NOT LET THE POWER CABLE HANG OVER THE EDGE OF A TABLE OR COUNTER, OR TOUCH HOT SURFACES.
- Page 11 8L Air Cooler Instructions for Use 11442 Please read and retain these instructions for future reference v001: 05/06/19 The air filter screen and wetted pad are located at the rear grille of the unit. Undo the screws at the rear and push down the 2 clips to release the screen.
- Page 12 8L Air Cooler Instructions for Use 11442 Please read and retain these instructions for future reference v001: 05/06/19 Troubleshooting Malfunction Causes Solution No function 1. Power off or poor 1. Plug in the power cord connection. and make sure it 2.
