SebArt
PittS 12 Python 50E
The new PittS 12 Python 50E ARF was designed by Italy
aerobatic pilot, Sebastiano Silvestri.
This professional ARF kit is the result of Sebastiano's long
research in 3D performance and precision. This combined with an
extremely lightweight structure, the all wood airframe and the big
control surfaces give the PittS 12 Python 50E an impressive
thrust-to-weight ratio and crisp control authority at any airspeed
and flight condition.
The PittS 12 Python 50E can do it all... precision aerobatics
manouvres... easy harriers, torque rolls, blenders, waterfalls and
all this for a biplane of this class is unbelievable!
Specifications:
Wing Span:...........................................135 cm
Length:............................................ 145 cm
Wing Area:............................................ 61 dm2
Weight:........................2.300 g. RTF less battery
Radio: 6-Channel with 4 mini + 2 standard servo
Modellbau Lindinger GmbH
Modellbau Lindinger GmbH
ASSEMBLY MANUAL
.....the only aerobatic limit is your fantasy!
Alte-Post-Str. 14
A-4591 Molln
professional line
ARF
Recommended power set up:
Motor:....................... Hacker A50-16S
ESC:............Master basic 70 S-BEC
Battery: ..........Flight Power 4270-6S
Propeller: .................... APC 17x8E
e-Mail: office@lindinger.at
www.lindinger.at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SebArt Serues and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Modellbau Lindinger SebArt Serues

Summary of Contents for Modellbau Lindinger SebArt Serues

  • Page 1 Modellbau Lindinger GmbH SebArt professional line PittS 12 Python 50E ASSEMBLY MANUAL The new PittS 12 Python 50E ARF was designed by Italy aerobatic pilot, Sebastiano Silvestri. This professional ARF kit is the result of Sebastiano’s long research in 3D performance and precision. This combined with an...

  • Page 2: Table Of Contents

    Modellbau Lindinger GmbH Table of contents Table of contents.......................……….. 2 Required radio, motor and battery.....................…. 3 Additional required items, tools and adhesives................3 Warning............................3 Before starting assembly ......................… 4 Using the manual........................... 4 Warranty information…......................... 4 Section 1 – top & bottom wing’s ailerons installation..............5 Section 2 –...

  • Page 3: Required Radio, Motor And Battery

    Modellbau Lindinger GmbH Required radio, motor and battery Radio equipment: • 6-channel radio system • 4 digital mini servo for ailerons, recommended JR PROPO DS385 or DS381 • 2 digital standard servos, recommended JR PROPO DS 9401 • 2 servo extension 300mm, for rudder and elevator servos •...

  • Page 4: Before Starting Assembly

    Modellbau Lindinger GmbH Before starting assembly Before starting the assembly of your PittS 12 Python 50E, remove each part from its bag and protection for a prior inspection. Closely inspect the fuselage, wing panels, rudder, and stabilizer for damage. If you find any damage or missing parts, contact the place of purchase.

  • Page 5: Section1 - Top & Bottom Wing's Ailerons Installation

    Modellbau Lindinger GmbH Section1 – top & bottom wing’s ailerons installation step 1 Trial fit the four aileron hinges, included in the hardware pack, in their place and verify the correct position and alignment of the aileron with the wing panel.

  • Page 6: Section 2 - Aileron Servo & Control Horn Installation

    Modellbau Lindinger GmbH step 4 Work the aileron up and down some times to work the hinges and check for proper movement. step 5 Repeat steps 1 through 4 for the remaining ailerons. Section 2 – aileron servo & control horn installation step 1 Locate the following items included in the hardware pack and the servo.
  • Page 7 Modellbau Lindinger GmbH step 3 With the hobby knife open the servo lead exits in the bottom & top wing. step 4 Carefully take out from the wing panels the nylon cable, factory located. step 5 Install the servo hardware (gommets and eyelets), put the servo into the wing panel and bring out the servo lead, as per pictures.
  • Page 8 Modellbau Lindinger GmbH step 6 Drill the location for the self-tapping screw using a 1.5mm drill bit and install the servo into the wing panel as per the picture. step 7 Glue the fibreglass horn with medium CA into the aileron.

  • Page 9: Section 3 - Rudder & Tail Wheel Installation

    Modellbau Lindinger GmbH step 9 Repeat steps 1 through 2 and 4 through 8 for the remaining ailerons. Section 3 – rudder installation & tail wheel installation step 1 Locate the following items. step 2 Locate the rudder in his place and check the alignment with the fuselage.
  • Page 10 Modellbau Lindinger GmbH step 3 Glue the rudder with some drops of medium CA, as per pictures. step 4 With the hobby knife cut a groove of 20mm length into the rudder. Drill in the rudder, 20mm from the bottom, the location for the tail wheel using a 2mm drill bit.
  • Page 11 Modellbau Lindinger GmbH step 6 Insert the three hinges in their appropriate slots of the rudder, and glue them with some drops of thin CA. step 7 Carefully locate the rudder and glue the hinges with some drops of thin CA.

  • Page 12: Section 4 - Elevator Installation

    Modellbau Lindinger GmbH Section 4 – elevator installation step 1 Insert in the elevator the four hinges into their appropriate slots and verify the correct position and alignment of the elevator with the stabilizer. step 2 Carefully glue the hinges, with some drops of thin CA, in the elevator only. Than insert carefully the elevator through the fuselage.
  • Page 13 Modellbau Lindinger GmbH step 4 Glue carefully the hinges in the stabiliser with some drops of thin CA. step 5 Check carefully the alignment of stabilizer with the bottom wing. step 6 Once satisfied with the alignment, glue carefully with thin CA the stabilizer at the fuselage.

  • Page 14: Section 5 - Elevator Servo & Control Horn Installation

    Modellbau Lindinger GmbH Section 5 – elevator servo & control horn installation step 1 Locate the following items included in the hardware pack, the servo extension 400mm long and the servo for elevator and rudder. step 2 Install the servo hardware (gommets and eyelets) and locate the elevator servo into the fuselage.
  • Page 15 Modellbau Lindinger GmbH step 3 Drill the location for the four self-tapping screw using a 1.5mm drill bit and install the servo into the wing panel as per the picture. step 4 Glue the fibreglass horn with medium CA into the elevator.

  • Page 16: Section 6 - Rudder Servo & Control Horn Installation

    Modellbau Lindinger GmbH Section 6 – rudder servo & control horn installation step 1 Install the servo hardware (gommets and eyelets) and locate the rudder servo into the fuselage. step 2 Drill the location for the four self-tapping screw using a 1.5mm drill bit and install the servo into the wing panel as per the picture.

  • Page 17: Section 7 - Wing's Pylon & Top Wing Installation

    Modellbau Lindinger GmbH step 4 Install the hardware and make the final adjustment as per picture Section 7 – wing’s pylons & top wing installation step 1 Locate all the necessary items. Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at...
  • Page 18 Modellbau Lindinger GmbH step 2 Locate and glue the plywood reinforcement on bottom wing as per picture. step 3 Locate and fix the bottom wing, with the washer and 3mm screw, as per picture. Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at...
  • Page 19 Modellbau Lindinger GmbH step 4 Locate and fix the aluminium top wing holder, with the washers and 3mm screws, as per picture. Note: use locktite to secure the screws on fuselage. step 5 Locate and fix the two aluminium pieces (that after need to be glued into top wing), with 3mm screws, as per picture.
  • Page 20 Modellbau Lindinger GmbH step 6 Sand the two aluminium pieces, in order to be ready to glued into top wing. step 7 With the hobby knife cut holes the pylons location into top and bottom wing, and install the pylons in the bottom wing with the pins, as per picture.
  • Page 21 Modellbau Lindinger GmbH step 9 Check incidence of wings with the provided plywood support, included in the hardware. step 10 Once satisfied with the alignment and incidences, disassemble the top wing and put the 5 minutes epoxy glue in the two aluminium locations and reassemble it rapidly, repeating step 8 and step 9.

  • Page 22: Section 8 - Landing Gear & Wheel Installation

    Modellbau Lindinger GmbH Section 8 – landing gear & wheels installation step 1 Locate all the necessary items. step 2 Install the landing gear as follow. Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at www.lindinger.at...
  • Page 23 Modellbau Lindinger GmbH step 3 Install the axle, wheel as follow. step 4 Install wheel and wheel pant as follow. step 5 Hold the wheel pant parallel to the fuselage and drill the location for the wheel pant screw using a 1,5mm drill bit.
  • Page 24 Modellbau Lindinger GmbH step 6 Test fit the landing gear fillet and his alignment. Once satisfied with the fit, glue the fillet on the landing gear using medium CA. Use the glue carefully avoid over runs on other areas. step 7 Repeat steps 3 through 7 for the opposite landing gear side.

  • Page 25: Section 9 - Electric Motor Installation

    Modellbau Lindinger GmbH Section 9 – electric motor installation We recommend to fly HACKER motor, you need the following item (not included): • Hacker A50-16S + MasterBasic70 SBEC + APC 17x8E + 4270-6S Flight Power pack step 1 Locate the motor and fix it with the four screws included in the motor hardware pack.
  • Page 26 Modellbau Lindinger GmbH step 2 Locate and fix the ESC and his switch as per picture. step 3 Fix carefully the prop and spinner. Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at www.lindinger.at...

  • Page 27: Section 10 -.Transparent Canopy Installation

    Modellbau Lindinger GmbH Section 10 – transparent canopy installation step 1 Cut very carefully the canopy following the border. step 2 Locate the canopy on the fuselage and sign the border, as follow. Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at...

  • Page 28: Section 11 - Final Radio Installation

    Modellbau Lindinger GmbH step 3 Send the canopy on the inside and the oracover surface on fuselage. step 4 Using 5 minutes epoxy glue carefully the canopy on the fuselage. Section 11 – final radio installation step 1 Locate two “Y” hardness, the receiver and the velcro to fix the battery in the fuselage.
  • Page 29 Modellbau Lindinger GmbH step 2 With the hobby knife, open the locations were to glue the servo extensions for top wing’s servos. step 3 Secure on top of the fuselage the servo leads with medium CA. Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at...
  • Page 30 Modellbau Lindinger GmbH step 4 Install receiver as per picture. Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at www.lindinger.at...

  • Page 31: Section 12 - Decal Set Application

    Modellbau Lindinger GmbH step 5 Install the battery pack as follow. Section 12 – decal set application Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at www.lindinger.at...

  • Page 32: Control Throws

    Modellbau Lindinger GmbH Control throws We recommend the use of a computer radio, that will allow you to do quite a bit of fine-tuning of the feel of the plane, which will make aerobatics even easier. Please, follow carefully the recommended linkage setups: For the AILERON we recommend the following throws: Low rate: 20°...

  • Page 33: Mixing

    Modellbau Lindinger GmbH Mixing For best performance, we recommend a linear-mix*: Rudder Elevator UP When you give full rudder to the right or left side, the elevator have to go up (positive) approx. 8% Rudder Ailerons When you give full rudder to the right, all four ailerons need to go left, approx. 2% when you give full rudder to the left, all four ailerons need to go right, approx.
  • Page 34 Modellbau Lindinger GmbH Finally... have a nice flight! SebArt di Sebastiano Silvestri Via Trento 69/3 38017 Mezzolombardo (TN) – Italy Modellbau Lindinger GmbH Alte-Post-Str. 14 A-4591 Molln e-Mail: office@lindinger.at www.lindinger.at...
