Battery And Charging - Quer CRUISER ZAB0010 Owner's Manual

electric scooter enters into power off mode.
• Continuing large current discharge (such as a long-time climbing a very steep
slope), 15 seconds later the electric scooter enters into power off mode.

BATTeRY ANd CHARGING

battery
Flashing red indicator signalizes low battery. When the device indicates low
battery, stop using the vehicle and charge it. Do not continue using the vehicle,
as the system will automatically tilt the base of the platform to prohibit using the
device – risk of falling is increased!
• Do not use the device if the battery gives out any odor or excessive heat or
when there's leakage.
• Do not use the device when it is charging!
• Ensure the charging port is dry prior to charging!
Charging
1. Plug the charger into mains socket (100 – 240 V; 50/60 Hz). Verify the green
light lights properly.
2. Plug the other end of the charger into the vehicle. The indicator should turn
red (otherwise, check connection).
3. When the indicator turns from red to green, the charging is complete.
Disconnect charger from the device and power mains outlet. Do not
overcharge the device, as it may affect battery life.
Specifications of battery
Rechargeable lithuim-ion battery
Voltage: 36 V
Capacity: 4,4 Ah
Working temperature: -15ºC~50ºC
Charging temperature: 0ºC~40ºC
Relative storage humidity: 5~95%
Cleaning
• Do not clean this device when in the process of charging!
• Clean this device with soft, slightly damp cloth. Do not use any abrasives or
chemical agents to clean this product.
Storage
Fully charge the battery before storage to prevent battery over discharge due
to a long time non-use.
Owner's manual
EN
17
