Quer CRUISER ZAB0010 Owner's Manual page 16

Indicators
Indicators, located in the central part of the device, signalize operation status
and battery level:
Battery indication:
• green light – battery fully charged
• yellow light – battery level at 50% capacity
• red light – battery level at 20% capacity (charging required).
Operation indication:
• when the pedal is triggered, the operation indicator will light up
• in case of error, the indicator will turn red
Range (cruise distance on one battery charge)
A distance the vehicle can cover depends on many factors, and thus may
decrease in relation to:
• topography: uneven surface will shorten the range;
• weight;
• temperature: extreme temperatures shorten the range;
• maintenance: proper handling, charging, etc. will optimize the range distance;
• speed: moderate, economic driving will optimize distance; while frequent
starts, stops changes of speed reduce the distance.
Max speed
Maximum speed for the vehicle is around 10 km/h.
The device prompts about speeding with an alarm signal.
PROTeCTION INFORMATION
During operation, if the system faces error or some faulty operation, the vehicle
will prompt the user about this in different ways (e.g. prohibit riding, alarm
indicator lights, buzzer alarm, the system cannot enter self-balancing mode):
• When step on the scooter, the platform go forwards or backwards more than
10 degrees.
EN
• The voltage of the battery is too low.
• During charging.
• The platform upturned.
• Overspeeding.
• The electric scooter shaking back and forth more than 30 seconds.
• System enter protection mode, alarm indicator lights, buzzer alarms of high
frequency.
• The platform going forwards or backwards more than 35 degrees, the electric
scooter will directly into the stop mode.
• Tire stall, two seconds later the electric scooter enters power off mode.
• The battery voltage is lower than the protection value, 15 seconds later the
16
Owner's manual
