I N S T A L L A T I O N I N S T R U C T I O N S
LF55UxP-B2B
LF49UxP
Back-to-Back Floor Kiosk
Floor Kiosk
49"/50"/55" Portrait Floor Kiosks,
49"/50"/55" Portrait Back-to-Back Floor Kiosks
Portuguese Product Description
Italian Product Description
Dutch Product Description
LF49/50/55UxP,
LF49/50/55UxP-B2B
Advertisement
Related Manuals for LEGRAND CHIEF LF49UxP
Summary of Contents for LEGRAND CHIEF LF49UxP
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S LF55UxP-B2B LF49UxP Back-to-Back Floor Kiosk Floor Kiosk 49"/50"/55" Portrait Floor Kiosks, 49"/50"/55" Portrait Back-to-Back Floor Kiosks Portuguese Product Description Italian Product Description Dutch Product Description...
-
Page 2: Important Safety Instructions
The information contained in this document is subject WARNING: Exceeding the weight capacity can result in to change without notice or obligation of any kind. Legrand serious personal injury or damage to equipment! It is the makes no representation of warranty, expressed or implied, installer’s responsibility to make sure the weight of... - Page 3 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B DIMENSIONS LF49UxP FLOOR MOUNTING HOLES TOP KNOCKOUTS SCALE 1:8 DIMENSIONS: INCH [MILLIMETERS]...
- Page 4 LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions DIMENSIONS...cont’d LF50UxP FLOOR MOUNTING HOLES TOP KNOCKOUTS SCALE 1:8 DIMENSIONS: INCH [MILLIMETERS]...
- Page 5 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B DIMENSIONS...cont’d LF55UxP 0.328 8.33 0.63 15.88 SLOT DIA FLOOR MOUNTING 0.50 12.7 HOLES SLOT LENGTH 30.67 779.0 DIMENSIONS: INCH [MILLIMETERS]...
- Page 6 LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions DIMENSIONS...cont’d LF49UxP-B2B 0.328 8.33 0.63 15.88 SLOT DIA FLOOR MOUNTING 0.50 12.7 HOLES SLOT LENGTH 30.67 779.0 TOP KNOCKOUTS 0.203 5.16 SCALE 1:8 3.00 76.20 0.20 5.16 SECTION B-B SCALE 1 : 8 DIMENSIONS: INCH REMOVABLE STORAGE PANEL [MILLIMETERS] LOWER FRONT PANEL REMOVED...
- Page 7 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B DIMENSIONS...cont’d LF50UxP-B2B 0.328 8.33 0.63 15.88 SLOT DIA FLOOR MOUNTING 0.50 HOLES 12.7 SLOT LENGTH 30.67 779.0 TOP KNOCKOUTS 0.203 5.16 SCALE 1:8 3.00 76.20 0.20 5.16 SECTION B-B SCALE 1 : 8 DIMENSIONS: INCH REMOVABLE STORAGE PANEL [MILLIMETERS] LOWER FRONT PANEL REMOVED...
- Page 8 LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions DIMENSIONS...cont’d LF55UxP-B2B 0.328 8.33 0.63 15.88 SLOT DIA FLOOR MOUNTING 0.50 12.7 HOLES SLOT LENGTH 30.67 779.0 TOP KNOCKOUTS 0.203 5.16 SCALE 1:8 3.00 76.20 0.20 5.16 SECTION B-B SCALE 1 : 8 REMOVABLE DIMENSIONS: INCH STORAGE PANEL [MILLIMETERS] LOWER FRONT PANEL REMOVED...
- Page 9 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación Perforar...
-
Page 10: Tools Required For Installation
LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/2" 5/16" 3/8" PARTS *Quantities are listed as (LFxxUxP / LFxxUxP-B2B) Monitor Interface Hardware Bag NOTE: Letters match markings on hardware bags BA (4/8) BB (4/8) BC (4/8) M4 x 12mm M4 x 25mm M4 x 50mm BD (4/8) BE (4/8) -
Page 11: Assembly And Installation
Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B ASSEMBLY AND INSTALLATION (One-sided display only) Grasp and "squeeze" the sides of the rear panel from behind the kiosk. Remove Kiosk from Packaging (One-sided display only) Lift to remove the rear panel from NOTE: These instructions apply to both the LF49/50/55UxP the kiosk. - Page 12 LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions WARNING: TIPPING HAZARD! Close and lock door(s) before removing the hex head bolts from the pallet. (See Figure 3) Keep door(s) closed and locked until the kiosk is E x 4 fully secured to the floor. Kiosk may tip if door(s) are open when kiosk is not securely fastened to pallet or to floor.
- Page 13 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B Attaching Flat Panel NOTE: Use the key to unlock and open the swing door. Swing door (D) Gasket strip Use a 5/16" open end wrench to remove display frame from kiosk swing door by removing and SAVING four hex head screws.
- Page 14 LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions IMPORTANT ! : The M8 screws do NOT require a washer. Use the universal washer (BO) ONLY with the Slots for depth adjustment M4, M5 or M6 screws. • Proper screw length requires base of screw head to protrude above flat washer a distance equal to or greater than the screw diameter.
- Page 15 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B Cabling Storage Panel Cables may be placed through the corners of the display frame. (See Figure 10) WARNING: Exceeding the weight capacity can result in Attach cable tie mounts (G) as necessary to keep cables serious personal injury or damage to equipment! It is the from being damaged in pinch points of the kiosk.
- Page 16 LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions Figure 12 Return lower panel to kiosk by sliding it in from the left side of the kiosk. (See Figure 12) Pull up lower panel latch inside kiosk and push in right side of lower panel to complete installation of panel. (See Figure 12) (One-sided display only) Rest rear panel on top of lower panel and lift upward approximately 2 inches.
- Page 17 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B...
- Page 18 LF49/50/55UxP, LF49/50/55UxP-B2B Installation Instructions...
- Page 19 Installation Instructions LF49/50/55UxP, LF49/50/55UxP-B2B...
- Page 20 P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 918 on 9/F, Shatin Galleria 8800-003146 Rev01 18-24 Shan Mei Street 2019 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 10/19 F 852 2145 4477...
