On-Screen Icons / Settings and Navigation
6.1
Locating Screen Display
ON SCREEN ICONS
Figure 6 – Screen display in detection mode
A. Signal strength (numbers and emitter waves)
B. Indicator arrows
C. Probe frequency
No information available:
User may encounter this reading if emitter/SONDE is below or beyond range of locator (0,6 –
1,8m).
6.2
Tools / Menu
To change settings you need to tap the touch screen – a tools icon
left corner of the screen. Tap the tools icon and the following screen will open up.
Figure 7 – Tools menu
Measurement of depth
ENGLISH
will appear in the lower
19
