- Page 1 ENG/FR OPERATION AND INSTALLATION MANUAL Multi-fuel and SE models Guide d’utilisation et Mode d'Emploi Burcott - Fireplace inset stove...
- Page 2 This manual refers to the stoves listed above, which are tested in accordance with EN 13240. Thank you for purchasing your new stove from Mendip Stoves. Please read this manual carefully to ensure that you get maximum enjoyment and performance from your new stove and to prevent any potential operational problems. Please note that “all local regulations, including those referring to national and European Standards, need to be complied with when...
-
Page 3: Health And Safety Precautions
IMPORTANT: hese instructions cover the basic principles to ensure the satisfactory installation of Mendip Stoves product :- Burcott, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with current Building Regulations, Local Authority Byelaws and other specifications or regulations as they affect the installation of the stove. - Page 4 Older properties, especially, may have chimney faults or the cross section may be too large . Mendip Stoves recommend the use of a solid fuel flue lining system for all installation into existing chimneys. All chimney systems must be used in accordance with Building Regulations Approved Document J.
-
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Each installation is unique to the property so it is not possible to give details to suit every setting. The installation must comply with local and national Building Regulations and be made using best practice construction methods. Many fireplace openings have a supporting lintel. Do not remove without supporting the remaining structure of the building. - Page 6 INSTALLATION INSTRUCTIONS Connection to Flue Liner/Pipe Fit flue collar to flue liner /connecting pipe prior to putting stove into position 5a Slide the appliance back into the opening taking care not to damage the hearth. Check that the fit is suitable and the appliance is in the correct position. 5b Fill the void at the back of the box with 6:1 vermiculite/cement mix or any other good non-combustible insulation material.
- Page 7 STOVE DIMENSIONS AND CONNECTION MEASUREMENTS...
- Page 8 STOVE PERFORMANCE & TESTING Mendip Stoves, Burcott models are tested in accordance with BS EN 13229:2001 + A1:2003 + A2:2004 Efficiency CO@13% Recommended CO@13% o2 Output Output coal for smoke control Efficiency wood fuel fuel Oct 2014 Burcott 4.1kw 0.38 3.9kw...
-
Page 9: Combustion Air
Connection to chimney Mendip Stoves are built with a top flue outlet as standard, this can be altered to a rear connection by removing the top collar, rear cover plate then exchanging collar and plate. Care should be taken to ensure an airtight fit when refitting collar and plate. - Page 10 DO NOT BURN HOUSE COAL. DO NOT BURN HOUSEHOLD WASTE, THIS APPLIANCE IS NOT AN INCINERATOR. MENDIP STOVES RECOMMEND THE USE OF A FLUE THERMOSTAT TO CHECK YOUR STOVE IS NOT OVERHEATING. PLACE FLUE THERMOSTAT DIRECTLY ABOVE COLLAR OF STOVE AND REFER TO TEMPERATURE GAUGE ON PAGE 4.
- Page 11 OPERATING YOUR STOVE - BURCOTT - AIR CONTROLS AND DOOR Secondary air Open Right ( pull open) / Left closed Tertiary air Permanently open Primary air Right open / Left closed To Open door lift handle. To close push door closed and push handle down until located When opening the door of your Mendip stove always wear the glove that is provided...
- Page 12 HOW TO LIGHT YOUR WOODBURNING STOVE Note: If the chimney is externally fitted or the stove has been installed on a larger diameter clay chimney liner then on cold days it maybe necessary to warm the flue using firelighters prior to lighting with wood. .
- Page 13 RE-FUELLING WHEN BURNING WOOD To re-fuel your stove in the cleanest way only refuel your stove when flames have died down and you have glowing embers. Before refuelling, open secondary air control fully . Open door gently, add two pieces of wood (see weight table page 6) and close the door. Once the flames from the logs are fully established the secondary air supply can be adjusted to the desired setting .
- Page 14 LIGHTING THE STOVE - SOLID FUELS Note: on cold days it maybe necessary to warm the flue using two firelighters. 1. Place Firelighters and a few smaller pieces of dry wood (kindling) among a small quantity of fuel in the combustion chamber.
-
Page 15: Overnight Burning
OVERNIGHT BURNING Mendip stoves do not recommend burning registered smokeless coal in a slumbering position, Mendip stoves are designed to burn wood and quality registered smokeless fuels. Wood burns more efficiently and cleanly if it is burnt hotter. Mendip stoves do not recommend that their stoves are burnt overnight for this reason. -
Page 16: Warning Note
WARNING NOTE Properly installed, operated and maintained this stove will not emit fumes into the dwelling. Occasional fumes from de-ashing and re-fuelling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, then the following immediate action should be taken:- (a) Open doors and windows to ventilate the room and then leave the premises. - Page 17 STOVE PARTS, COMBUSTION CHAMBER, ASSEMBLY PIÈCES DÉTACHÉES, VUE ÉCLATÉES "This section shows the parts contained in your stove, each stove has over 80 spare-parts and, each part is detailed. When new parts are required the section will allow spares to be recognised and ordered. As a further source of reference please visit www.eurostove.co.uk for latest spare-part information.
- Page 18 Burcott brick set removal and assembly Fig 1 Fig 2 Fig 1: Burcott complete chamber Fig 2: to start removed begin by lifting baffle up Fig 3 : To remove the Brickset from the Burcott stove start at the left side. Remove left rear brick Fig 3 Fig4...
- Page 19 Burcott brick set removal and assembly Fig 6: Remove right rear brick Fig 6 Fig 7: Remove right front brick Lift out steel grate Fig 7 Fig 8: The chamber is now empty Fig 8 Fig 9: Fig 9 When refitting bricks first ensure the grate is in position and then start with the front right brick, the front brick has a routed out section for the handle mount to fit see fig 9...
- Page 20 BS26 2UG Distribué en France par la société / Distributed in France and Benelux by:- Eurostove SAS Centre d’Affaires Rue de L’horlogerie BP 60011 62401 Bethune Cedex Contact@eurostove.fr www.eurostove.fr Part of Eurostove group Mendip Stoves Ltd, 2013, Burcott v5 09.08.2016...
