- Page 1 BT-0260 Printer Combo Adapter USER’S GUIDE (For Widcomm Driver) VERSION Bluetooth Tested To Comply With FCC Standards FOR HOME OR OFFICE USE...
- Page 2 © All rights reserved. All trade names are registered trademarks of respective manufacturers listed. The Bluetoothname and the Bluetoothtrademarks are owned by BluetoothSIG,Inc. This manual may not be copied in any media or form without the written consent of original maker.
-
Page 3: Table Of Contents
Before You Start ............2 Connecting your Bluetooth USB Adapter with PC ....2 BT-0260 Printer Combo Adapter ........2 Getting to Know Your BT-0260 Printer Combo Adapter ..3 Function of LEDs During Printing ........3 WIDCOMM BLUETOOTH SOFTWARE DRIVER ......4 UPDATE BLUETOOTH DRIVER .......... -
Page 4: Welcome
WELCOME Thank you for your purchase of the BT-0260 Printer Combo Adapter. Featuring Bluetooth wireless technology, BT-0260 Printer Combo Adapter creates cable-free printing connections between your desktop PCs and your printers. BT-0260 Printer Combo Adapter is compatible with all Bluetooth v1.1-certified devices and you can... -
Page 5: Before You Start
BEFORE YOU START 1. Confirm Box Contents 5V Power BT-0260 Printer Combo Adapter Utility CD Manual Adapter IMPORTANT LEASE READ ALL INSTRUCTIONS AND THE SAFETY GUIDE BEFORE YOU PLUG THE UNIT INTO THE PRINTER CONNECTING YOUR BLUETOOTH USB ADAPTER WITH PC Connect your Bluetooth USB dongle with your PC. -
Page 6: Getting To Know Your Bt-0260 Printer Combo Adapter
BT-0260 printer combo adapter to both of them, 1284 interface will be the functioning one. 3). Apply power to BT-0260 adapter by using the 7.5V DC power adapter accompanied, it is also the only way to RESET BT-0260. 4). Mode button is used by the advanced user to configure the printer adapter for some special purposes, it is normally left unused. -
Page 7: Widcomm Bluetooth Software Driver
NOTE : Skip this section if you already installed Widcomm driver in your This software is included in our BT-0260 Printer Combo Adapter package. We assume you already purchased a Bluetooth USB dongle and it already bundled this software. We also assume you already installed this driver in your PC. - Page 8 Step 3 : Select destination folder, you can choose the default or change to your favorite. Step 4 : Click Install to start the installation. If you have not plugged in Bluetooth Dongle onto your PC before, one reminding window will show up to ask you to plug in it before installa- tion can be finished.
-
Page 9: Update Bluetooth Driver
This section is a reference topics to tell you how to prevent conflict when installing your USB Bluetooth Dongle in your PC. It has NOTHING to do with BT-0260 Printer Combo Adapter which you purchased. Here, we assume you already purchased a Bluetooth USB dongle and it is using CSR technology (i.e. - Page 10 Step 4 : Default is : Install the software automatically (Recommended). Please do not select it. Select Install from a list or specific location (Advanced). Then click Next. Step 5 : Dafault is Search for the best driver in these locations.
- Page 11 Step 7 : Click Finish. Step 8 : After these update driver steps, you will see only one bluetooth device in the Device Manager. This is what Widcomm driver really supports.
-
Page 12: Select Bluetooth Services
SELECT BLUETOOTH SERVICES When the first time Widcomm driver is installed, and USB Bluetooth Dongle is plugged to your system, you will be asked to configure your Bluetooth services for your system. Step 1 : Double-click on the bluetooth icon on the lower-right corner of the screen, you will see configuration wizard, Click Next button. - Page 13 Step 4 : The default setting is that all services are available, you can check or uncheck one or more services, then click Next button. Step 5 : click skip and then click Next button. Step 6 : configuration is completed.
-
Page 14: My Bluetooth Places
MY BLUETOOTH PLACES Step 1 : Method 1 : Double click on your desktop. Click Folder on the toolbar. Folder window will appear on left side of your screen. Method 2: Right click on the lower right hand corner of your screen. Select Explore My Bluetooth Places. - Page 15 You also may start a search for devices by clicking Bluetooth from the toolbar. Step 3 : In this example, One Bluetooth printer device is found in your Bluetooth neighborhood. This is the service we want to know. We will look at it later. The “My Bluetooth Places”...
-
Page 16: Add Local Printer
ADD LOCAL PRINTER In the following example, we assume a BT-0260 printer combo adapter (with series# : BT-PRT-B0A351) is connected to an EPSON Stylus C61 printer. Step 1 : From My Bluetooth Places, right click on BT-0260 printer combo adapter... -
Page 17: Disable Bidirectional Support
DISABLE BIDIRECTIONAL SUPPORT From Ports page, there is a check box - Enable bidirectional support. This feature allows computer to talk with printer bidirectionally. Because some functions are not supported by Bluetooth, if enabling this feature, some printers may stay at wait state for one minute after printing is done. -
Page 18: Start Printing
Faxes, then you can find a Bluetooth Printer is there : EPSON Stylus C61 Series. Print a file by using BT-0260 combo printer adapter is quite straigth forward, it is just like the normal way you are printing a file. -
Page 19: Change Printer
CHANGE PRINTER In your home or office, there may be two or three different printers coming from different brands. In previous example, we selected EPSON Stylus C61 color printer as our bluetooth printer. If you want to change it to another printer, such as EPSON Stylus Photo 830U, then you shall know how to change printer driver to a different one. - Page 20 Step 5 : When installation of new printer driver is complete, the Printers and Faxes screen will look like this. EPSON Stylus Photo 830U Series coming out as the new printer which must be connected to the BT-0260 printer adapter now.
-
Page 21: Multiple Bt-0260 Printer Combo Adapters
MULTIPLE BT-0260 PRINTER COMBO ADAPTERS Previous sections talk about how to do a printing job with a BT-0260 printer combo adapter. This section is talking about when multiple adapt- ers are installed in your office, how to configure each adapter before... -
Page 22: Configuring The First Bt-0260 Printer Adapter
1. Configuring the first BT-0260 Printer Adapter Connect the first BT-0260 printer combo adapter to an EPSON Stylus C61 printer. Step 1 : From My Bluetooth Places, right click on the first BT-0260 printer combo adapter folder (with series# : BT-PRT-B0A351), then select OK to install a printer driver for it. -
Page 23: Configuring The Second Bt-0260 Printer Adapter
2. Configuring the second BT-0260 Printer Adapter Connect the second BT-0260 printer combo adapter to another EPSON Stylus C61 printer. Step 1 : From My Bluetooth Places, right click on the second BT-0260 printer combo adapter folder (with series# : BT- PRT-B0A352), then select OK to install a printer driver for it. -
Page 24: Configuring The Third Bt-0260 Printer Adapter
3. Configuring the third BT-0260 Printer Adapter Connect the third BT-0260 printer combo adapter to an EPSON Stylus Photo 830U printer. Step 1 : From My Bluetooth Places, right click on the third BT-0260 printer combo adapter folder (with series# : BT-PRT-B0A353), then select OK to install a printer driver for it. - Page 25 Step 4 : From Ports page, you can see three printer ports are used : 1. BT-PRT-B0A351. 2. BT-PRT-B0A352. 3. BT-PRT-B0A353. They are functioning the same as the original LPT1: printer port of your PC. The difference is LPT1: is for cable conenction, while these three Bluetooth printer ports are used for wireless connections.
-
Page 26: Start Printing
Start Printing : Print a file by using BT-0260 combo printer adapter is quite straigth forward, it is just like the normal way you are printing a file. For EPSON Stylus C61 (Sales_Dept) : When page range and number of... -
Page 27: Change Printer
Change Printer : Step 1 : Select Control Panel Select Printers and Faxes. Right click on printer EPSON Stylus C61 Series (Sales_Dept) icon. Click on Properties. Step 2 : You can change printer name to such as : EPSON Stylus COLOR 680 (Sales_Dept). - Page 28 Step 3 : Click on Advanced tab to see if the driver of EPSON Stylus COLOR 680 has been installed before. If yes, click to complete the change. If not, click New Driver and follow the instructions to install it. If New Driver is selected, this screen will prompt to instruct you to install new driver step by step.
-
Page 29: Printer Error Message
5. Paper empty. If it is out of paper, this screen will pop out. BT-0260 Printer Combo Adapter will continue the printing if the error condition is cleaned. It will not stop unless you cancel it. Example : Cancel an out of paper job. -
Page 30: Cancel Printing Job
CANCEL PRINTING JOB 1. Start 2. Printing job in process. 3. Printing job has error. Double click on printer icon to read the message. 4. Error message. 5. Right click on the file being printed, and select Cancel to stop it. RESET HANGED BLUETOOTH If there is any Bluetooth operation hanged, you can use the following steps to clean it. -
Page 31: Appendix A
APPENDIX A Specifications : Product Name BT-0260 Printer Combo Adapter Model Name BT-0260 Certification FCC, CE, BQB Standard Bluetooth v1.1 Frequency Band 2.4~2.4835GHz unlicensed ISM band Spread Spectrum FHSS (Frequency Hopping Spread Spectrum) Services Supported SPP and HCRP print services... -
Page 32: Appendix B
APPENDIX B Safety Guide : Read and follow all instructions and warnings provided. Save these instructions for future use. When service or replacement of parts is required, ensure work is done by a qualified technician. Do not use this unit near water or in a rainy/moist environment. Use supplied cables only. -
Page 33: Fcc
FCC COMPLIANCE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 34: Warranty
One Year Limited Warranty This device is guaranteed against manufacturing defects for one full year from the original date of purchase. This warranty is valid at the time of purchase and is non-transfer able. This warranty must be presented to the service facility before any repair can be made.
