- Page 1 BT-0260 Printer Combo Adapter PDA USER’S GUIDE VERSION Bluetooth Tested To Comply With FCC Standards FOR HOME OR OFFICE USE...
- Page 2 © All rights reserved. All trade names are registered trademarks of respective manufacturers listed. The Bluetoothname and the Bluetoothtrademarks are owned by BluetoothSIG,Inc. This manual may not be copied in any media or form without the written consent of original maker.
-
Page 3: Table Of Contents
Before You Start ............2 Connecting your Bluetooth USB Adapter with PC ....2 BT-0260 Printer Combo Adapter ........2 Getting to Know Your BT-0260 Printer Combo Adapter ..3 Function of LEDs During Printing ........3 INSTALLING MICROSOFT ACTIVESYNC ........4 INSTALLING WIDCOMM BTW-CE ......... -
Page 4: Welcome
WELCOME Thank you for your purchase of the BT-0260 Printer Combo Adapter. Featuring Bluetooth wireless technology, BT-0260 Printer Combo Adapter creates cable-free printing connections between your desktop PCs and your printers. BT-0260 Printer Combo Adapter is compatible with all Bluetooth v1.1-certified devices and you can... -
Page 5: Before You Start
LEASE READ ALL INSTRUCTIONS AND THE SAFETY GUIDE BEFORE YOU PLUG THE UNIT INTO THE PRINTER CONNECTING YOUR BLUETOOTH USB ADAPTER WITH PC Connect your Bluetooth USB dongle with your PC. Install Widcomm Bluetooth software driver. BT-0260 PRINTER COMBO ADAPTER DC Power Jack USB Connector Mode Button IEEE-1284 connector... -
Page 6: Getting To Know Your Bt-0260 Printer Combo Adapter
BT-0260 printer combo adapter to both of them, 1284 interface will be the functioning one. 3). Apply power to BT-0260 adapter by using the 7.5V DC power adapter accompanied, it is also the only way to RESET BT-0260. 4). Mode button is used by the advanced user to configure the printer adapter for some special purposes, it is normally left unused. -
Page 7: Installing Microsoft Activesync
INSTALLING MICROSOFT ACTIVESYNC Before you can exchange information between your mobile device and your PC computer, you must set up ActiveSync. After installing ActiveSync in your PC, then you can download Bluetooth related driver or program from this PC to your mobile device. Step 1: Normally, there is a self-extracted file named MSAsync.exe, please... - Page 8 A message prompts you that your mobile device has not set up a connection with your PC. Click OK. Step 4: Power on pocket PC and connect it to your PC using accompanied USB cable. On your PC, click Start -> All Programs ->...
- Page 9 Click Next. Click Finish. ActiveSync starts establishing syn- chronized information.
-
Page 10: Installing Widcomm Btw-Ce
Synchronization is complete. A mark is shown on the screen. INSTALLING WIDCOMM BTW-CE Now, we are going to install Widcomm BTW-CE 1.3.1 software on your mobile device. Make sure your Pocket PC is connected to your computer. Put Widcomm BTW-CE Install CD into CD drive of your PC, run setup.exe. - Page 11 Select Typical, Click Next. Installing setup is in progress in your Click Yes to install Widcomm BTW-CE from your PC onto your Pocket PC. Installing Widcomm BTW-CE is in progress.
- Page 12 Widcomm BTW-CE is downloaded to your Pocket PC. Click OK. Click Finish, the installation is complete. Reset your Pocket PC before using Bluetooth.
-
Page 13: Installing Printing Tool
INSTALLING PRINTING TOOL A Pocket PC printing tool must be installed first before you can print any document out. In this example, we select PrintPocketCE v3.33 as our printing tool. Click Next to continue. Click Yes for License Agreement. Click Yes to choose default install directory. - Page 14 You also can use ActiveSync to Add/ Remove programs to your mobile device. Select Tools -> Add/Remove Programs..Check the boxes to select programs. Check box - Install program into the default installation folder. Click OK. Installing PrintPocketCE is in progress. Installation is complete on your mobile device.
-
Page 15: Start Bluetooth Printing
START BLUETOOTH PRINTING Step 1 : Read Serial Port. Click Start. Select and click Settings. Click System. Double click on Bluetooth icon. -
Page 16: Add Paired Printer To Device List
Click on Serial Port. Remember the Outbound COM port. In this case, it is COM port 2. Step 2 : Add Paired Printer to Device List. Click Start. Select and click Programs. Double click on Bluetooth Manager icon. - Page 17 Bluetooth Manager screen pops out. Tap Tools. Select Paired devices. PDA will ask you to add a paired bluetooth device to its device list. In this example, we will add a printer to the list.
- Page 18 Tap the lookup icon. PDA starts looking for Bluetooth devices nearby, a Bluetooth printer BT0260-0A228 is found. Select it, and tap OK. Device name is automatically added to the list. You can select a Passkey (PIN code) for future authenticating connection or ignore it by inputting nothing.
- Page 19 Pairing between PDA and Bluetooth printer is in progress. Bluetooth printer is added to the paired devices list of PDA. Each PDA can have many paired devices in its devices list. For example, if there are three different Bluetooth printers in the list, you can select one among them for the printing.
-
Page 20: Print It Out
Step 3 : Print it Out. Click Start. Select and click Programs. Double click on Print Pocket icon. In this example, we are going to print file : SysInfo.txt. Tap on it. - Page 21 Choose font style and font size. Choose COM port, it is COM2 as we found on Step PDA starts looking for available printer in its device list.
- Page 22 One BT0260-0A228 printer was found. Select it, and tap OK. Printing is in progress and SysInfo.txt file will be printed.
