Operator's manual for Attachment
Operator's
Operator's
Operator's
Product number:
Please read this manual carefully before using the equipment, and follow all
instructions.
Keep this manual for later reference.
manual for Attachment
manual for Attachment
manual for Attachment
Edge trimmer
400-700-series loaders:
Edge trimmer 2011 1
A21068
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AVANT A21068
Summary of Contents for AVANT A21068
- Page 1 Operator’s manual for Attachment manual for Attachment Operator’s Operator’s manual for Attachment manual for Attachment Edge trimmer Product number: 400-700-series loaders: A21068 Please read this manual carefully before using the equipment, and follow all instructions. Keep this manual for later reference.
-
Page 2: Table Of Contents
Edge trimmer 2011 1 CONTENTS 1. Foreword..........................3 2. Designed purpose of use ......................3 3. Safety instructions for the edge trimmer ...................3 4. Edge trimmer specifications .....................4 5. Assembly of the edge trimmer ....................5 .................5 5.1. Mounting the edge trimmer to the loader ..............7 5.2. -
Page 3: Foreword
3(12) 1. Foreword Avant Tecno Oy would like to thank you for your purchase of this AVANT attachment. It has been designed and manufactured on the basis of years of product development and experience. By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure the reliable operation and long service life of the equipment. -
Page 4: Edge Trimmer Specifications
4. Edge trimmer specifications Table 1 –Edge trimmer technical data Product number A21068 Cutting depth: max 150 mm Cutting width: Total width: Weight: 65 kg Maximum input of 70 l/min hydraulic energy: 22,5 MPa (225 bar) Suitable AVANT loader* 420-700... -
Page 5: Assembly Of The Edge Trimmer
These instructions are applicable to mounting the edge trimmer to the boom quick attach plate of AVANT loaders that have standard quick attach locking. If your machine is equipped with a hydraulic locking and/or serial quick attach system, refer to the relevant manuals for additional mounting instructions. - Page 6 6(12) Never move or raise an attachment that has not been locked. Step 1: • Lift the quick attach plate locking pins up and turn them backwards into the slot so that they are locked in the upper position. • Ensure that the hydraulic hoses are not in the way during installation. Step 2: •...
-
Page 7: Connecting And Disconnecting The Hydraulic Fittings
7(12) 5.2. Connecting and disconnecting the hydraulic fittings To connect and disconnect the fittings, move the collar at the end of the female fitting. Before connecting or disconnecting hydraulic fittings, shut down the loader engine and move the working hydraulics lever or pedal on the loader to its extreme positions a few times. -
Page 8: Use
8(12) 6.1. The edge trimmer is started by turning the working hydraulics valve to its locked position. Depending on the loader model, the working hydraulics control device is a lever that is locked in the front or right position, or a pedal that is locked to lower position. -
Page 9: Cleaning The Trimmer
Only add the grease amount of a couple of grease press pushes at a time. 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) for the edge trimmer from the date of purchase. The warranty covers repair costs as follows: •... - Page 10 SFS-EN ISO 12100-1, SFS-EN ISO 12100-2, SFS-EN 982 Kuvaus: Avant-kuormainten kanssa käytettävä nurmikon reunaleikkuri, työsyvyys 150 mm Beskrivning: Kantslipare till gräsmatta, arbetsdjup 150 mm; arbetsredskap för Avant lastare Description: Lawn edge trimmer working depth 150mm; attachment for Avant loaders Beschreibung: Rasenkanten-Trimmer Arbeits-Tiefe 150 mm;...
