- Page 1 Battery installing guide for EV4 Bike Remove all of the side screws from the battery cover Remove all of the top screws from the battery cover...
- Page 2 Loosen the front main bolt on the battery cover Lift the battery cover or remove it completely for easier access.
- Page 3 Notice the layout of protection foam Insert the battery into the casing. The cables must face towards the back. All relevant cables have been marked with numbers. Connect them carefully. Cables without a number don’t need to be connected to anything. We recommend using small amount of isolation tape to wrap all of the connectors.
- Page 4 Place the protection foam between the battery and loose cables. Now, place the controller and cables on the protection foam...
- Page 5 Place the sponge on top of everything and close the battery cover Secure the cover with front main bolt.
- Page 6 If the EV4 does not start please check if all cables were properly connected. Wires that haven’t a number attached to them don’t need to be connected to anything. If the vehicle still does not start please refer to...
