LIGHT ANGLE ADJUSTMENTS
1. Use a 13mm socket to loosen the 2 Hex head bolts Part
(B2) on each side of the light.
2. Adjust the light to your desired angle and tighten Bolts (B2).
LIGHT ANGLE ADJUSTMENT DIAGRAM:
ADJUSTMENT KEY
Part (B2) Bolt
a. 13mm Hex Head Bolt
(B2)
8.7" CG2 LED LIGHT CANNON
Installation Instructions & User's Manual
Advertisement
Table of Contents
Related Manuals for Vision X 8.7" CG2 LED Light Cannon
Summary of Contents for Vision X 8.7" CG2 LED Light Cannon
- Page 1 LIGHT ANGLE ADJUSTMENTS 1. Use a 13mm socket to loosen the 2 Hex head bolts Part (B2) on each side of the light. 2. Adjust the light to your desired angle and tighten Bolts (B2). LIGHT ANGLE ADJUSTMENT DIAGRAM: 8.7” CG2 LED LIGHT CANNON ADJUSTMENT KEY Part (B2) Bolt Installation Instructions &...
- Page 2 VISION X 8.7” CG2 LED LIGHT CANNON About The 8.7” CG2 LED Light Cannon: Pigtail Hex Head Bolt WARNING: Bolts, Nuts, and Washers are Stainless Steel. Cannon [M12] DO NOT USE Pneumatic or Electric Tools to Tighten and Loosen. The Hardware Will Permanently Lock Together.
