Operator's Manual
TM
2-in-1 Cordless Grass Trimmer/Edger
Model No. HT19-401-003-03
3026035
WARNING: Read, understand and follow all safety Rules and Operating
Instructions in this Manual before using this product.
Wal-Mart Stores, Inc., Bentonville, AR 72716
For questions / comments, technical assistance or repair parts.
Please Call Toll Free at: 1-888-997-8875 (M-F 8am-6pm)
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hyper Tough HT19-401-003-03
Summary of Contents for Hyper Tough HT19-401-003-03
- Page 1 Operator’s Manual 2-in-1 Cordless Grass Trimmer/Edger Model No. HT19-401-003-03 3026035 WARNING: Read, understand and follow all safety Rules and Operating Instructions in this Manual before using this product. Wal-Mart Stores, Inc., Bentonville, AR 72716 For questions / comments, technical assistance or repair parts.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Safety..................................Pages 3-5 Symbols......................................Page 6 Component List...................................Page 7 Technical Data....................................Page 8 Accessories....................................Page 8 Operation Instructions..............................Pages 9-12 For charger HT19-401-003-14 ............................Pages 9-12 For charger ACG318W1U..............................Pages 9-12 For charger HT19-401-003-13 ............................Pages 9-12 Charging Indicator..................................Page 10 For Battery Tools..................................Page18 Cleaning The Tool..................................Page 18 SAVE THESE INSTRUCTIONS! READ ALL INSTRUCTIONS! WARNING: This product can expose you to chemicals including lead, phthalate or bisphenol A which... -
Page 3: Product Safety
PRODUCT SAFETY Important Safety Instructions WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING: Read all instructions FOR ALL APPLIANCES: 1) Avoid Dangerous Environment - Don’t use appliances in damp or wet locations. 2) Don’t Use In Rain. - Page 4 Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to fire or temperature above 130°C may cause explosion. Follow all charging instructions and do not charge the battery pack or appliance outside of the temperature range specified in the instructions. Charging improperly or at temperatures outside of the specified range may damage the battery and increase the risk of fire.
- Page 5 e) Do not subject battery pack to mechanical shock. f) In the event of battery leaking, do not allow the liquid to come in contact with the skin or eyes. If contact has been made, wash the affected area with copious amounts of water and seek medical advice.
-
Page 6: Symbols
SYMBOLS To reduce the risk of injury, user must read instruction manual WARNING Wear ear protection Li-Ion battery, battery must be recycled Do not burn Do not expose to rain or water POSITEC Inc. has established a partnership with the RBRC Corporation to recycle any Positec batteries with the RBRC- call2recycle seal. -
Page 7: Component List
COMPONENT LIST 1. Handle adjustment knob 9. Lower shaft 2. Auxiliary handle 10. Safety guard 3. Command feed button 11. Line cutter 4. Battery pack 12. Edger wheel 5. On/Off Switch 13. Flower guard 6. Lock off switch 14. Line feed button 7. -
Page 8: Technical Data
150mins for 2 batteries Charging time 5.1 lbs Machine weight The accessories of battery charger (HT19-401-003-13 /ACG318W1U) and battery pack (ABP118T7/ HT19-401-003-17 ) illustrated or described are not included in HT19-401-003-03 delivery. ACCESSORIES Battery pack (ABP118T) Charger ( HT19-401-003-14 ) Auxiliary handle... -
Page 9: Operation Instructions
OPERATION INSTRUCTIONS ASSEMBLY AND OPERATION ACTION FIGURE Assembly Assembling the Main Handle See Fig. A Assembling the Auxiliary Handle See Fig. B1, B2 Assembling the Safety Guard See Fig. C Assembling the Flower Guard See Fig. D Removing the Blade Protect Label See Fig. -
Page 10: For Charger Acg318W1U
CHARGING PROCEDURE (SEE FIG. F3) 1) Plug the charger into an appropriate outlet. The light will be green. 2) Slide the battery pack into the charger, the light will turn to red to indicate the charging process has started. 3) When charging is completed, the light will turn to green. The pack is now fully charged, unplug the charger and remove the battery pack. - Page 11 NOTE: The accessories of battery charger (HT19-401-003-13 /ACG318W1U) and battery pack (ABP118T7/ HT19-401-003-17 ) illustrated or described are not included in HT19-401-003-03 delivery. OPERATION INSTRUCTIONS Warning! The charger and battery pack are specially designed to work together so do not attempt to use any other devices.
- Page 12 Problems Possible Causes Corrective Action Battery discharged. Recharge battery; also see the content in charger manual. Trimmer fails to operate. Battery too hot/cold. Allow to cool/warm. Motor is broken. Contact Service Agent. Internal wiring of machine damaged. Contact Service Agent. Motor is broken.
-
Page 18: For Battery Tools
FOR BATTERY TOOLS The ambient temperature range for the use and storage of tool and battery is 0°C-45°C. The recommended ambient temperature range for the charging system during charging is 0°C-40°C. CLEANING THE TOOL Clean the tool regu‘larly. WARNING! Keep your product dry. Under no circumstances spray with water. - To clean the tool, use only mild soap and a damp cloth. - Page 19 Manual del operador Rebordeador/ribeteador de césped 2 en 1 inalámbrico Modelo No. HT19-401-003-03 3026035 ADVERTENCIA: Lea, entienda y siga todas las Reglas de seguridad y las Instrucciones de operación en este Manual antes de usar el producto. Wal-Mart Stores, Inc., Bentonville, AR 72716 Para preguntas / comentarios, asistencia técnica o partes de reparación.
- Page 20 TABLA DE CONTENIDOS Seguridad Del Producto..............................Pages 21-23 Símbolos......................................Page 24 Lista De Partes....................................Page 25 Datos Técnicos....................................Page 26 Accesorios....................................Page 26 Instrucciones De Uso...............................Pages 27-30 Para cargador HT19-401-003-14 ..........................Pages 27-30 Para cargador ACG318W1U............................Pages 27-30 Para cargador HT19-401-003-13 ..........................Pages 27-30 Indicador De Carga...................................Page 28 Para herramientas de batería...............................Page 36 Limpiar La Herramienta................................Page 36 CONSERVE ESTAS INSTRUCCIONES!
-
Page 21: Seguridad Del Producto
SEGURIDAD DEL PRODUCTO INSTRUCCIONES DE SEGURIDAD ADVERTENCIA: Lea y comprenda todas las instrucciones. El no seguir todas las instrucciones a continuación puede ocasionar descargas eléctricas, incendios y/o heridas graves. ADVERTENCIA: Lea todas las instrucciones. PARA TODAS LAS HERRAMIENTAS 1) Evite ambientes peligrosos. No utilice las herramientas en lugares húmedos o mojados. No trabaje bajo la lluvia. - Page 22 conexión de una terminal a otra. Poner en corto las terminales de la batería puede causar quemaduras o un incendio. Bajo condiciones de abuso, puede expulsarse líquido de la batería; evite el contacto. Si ocurre contacto accidentalmente, lave con agua. Si el líquido entra en contacto con los ojos, busque ayuda médica adicional.
- Page 23 Advertencias de seguridad general para el paquete de batería a) No desensamble, abra o triture el paquete de batería. b) No exponga el paquete de batería a calor o fuego. Evite guardar a la luz directa del sol. c) No ponga en corto circuito el paquete de batería. No guarde el paquete de batería de forma aleatoria en una caja o cajón donde puedan ponerse en corto circuito entre sí...
-
Page 24: Símbolos
SÍMBOLOS Para reducir el riesgo de lesiones, el usuario deberá leer el manual de instrucciones Advertencia Emplee protección auditiva Batería de iones de litio. La batería deberá reciclarse. No arrojar al fuego No exponer a la lluvia ni al agua POSITEC Inc. -
Page 25: Lista De Partes
LISTA DE PARTES 1. Perilla de ajuste del mango 9. Eje inferior 2. Mango auxiliar 10. Guarda protectora de seguridad 3. Botón de alimentación automática 11. Cuchilla del hilo 4. Paquete de Batería 12. Rueda bordeadora 5. Interruptor de encendido/apagado 13. -
Page 26: Datos Técnicos
Tiempo de Carga 5.1 lbs Peso de la máquina El cargador de batería (HT19-401-003-13 /ACG318W1U) y el paquete de batería (ABP118T7/ HT19-401-003-17 ) ilustrados o descritos no están incluidos en la entrega de HT19-401-003-03. ACCESORIOS Batería (ABP118T) Cargador ( HT19-401-003-14 ) -
Page 27: Instrucciones De Uso
INSTRUCCIONES DE USO ENSAMBLE & FUNCIONAMIENTO ACCIÓN FIGURA ENSAMBLE Ensamble del mango principal Vea la Fig. A Ensamble del mango auxiliar Vea la Fig. B1, B2 Ensamble del guarda de seguridad Vea la Fig. C Ensamble del guarda para flores Vea la Fig. -
Page 28: Para Cargador Acg318W1U
no menos de la mitad antes de almacenar. Si la herramienta no se va a usar por periodos prolongados de tiempo, cargue la batería cada 3-6 meses. PROCEDIMIENTO DE CARGA (VEA LA FIG. F3) 1) Conecte el cargador en el tomacorriente correcto. La luz será color verde. 2) Deslice el paquete de batería en el cargador, la luz se encenderá... - Page 29 NOTA: El cargador de batería (HT19-401-003-13 /ACG318W1U) y el paquete de batería (ABP118T7/HT19-401- 003-17 ) ilustrados o descritos no están incluidos en la entrega de HT19-401-003-03. INSTRUCCIONES DE FUNCIONAMIENTO Advertencia! Tanto el cargador como el pack de batería están diseñados para operar conjuntamente, de modo que no debe utilizarse ningún otro dispositivo.
- Page 30 PROBLEMAS Posibles causas Acción correctiva Batería descargada. Vuelva a cargar la batería; consulte también “ CÓMO CARGAR EL PACK DE BATERÍA “. Batería demasiado caliente/fría. Espere a que la batería se enfríe/ La podadora no funciona. caliente. Motor dañado. Póngase en contacto con un agente de servicio técnico.
-
Page 36: Para Herramientas De Batería
PARA HERRAMIENTAS DE BATERÍA El rango de temperatura ambiente para uso y almacenamiento de la herramienta y la batería es de 0°C-45°C. El rango de temperatura ambiente recomendado para el sistema de carga durante la carga es de 0°C-40°C. LIMPIAR LA HERRAMIENTA Limpie la herramienta con regularidad.
Need help?
Do you have a question about the HT19-401-003-03 and is the answer not in the manual?
Questions and answers
How do I replenish line? I don’t see any Info about replacing the spool
To replenish the line on the Hyper Tough HT19-401-003-03:
1. Take approximately 6 meters of line.
2. Insert 2 mm of the line into the holes on the Spool.
3. Wind the line in the direction of the arrows on top of the Spool.
4. Leave about 100 mm of line unwound and place it into the cleat.
5. Make sure the line is neatly coiled to ensure proper automatic feed.
6. Fit the Spool as described in the “Replacing the trimmer line and Spool” section.
This answer is automatically generated
line is caught in spool; severely wrapped around inside; how do I disassemble to untie?
To disassemble the Hyper Tough HT19-401-003-03 to untangle the line caught in the spool:
1. Remove the battery pack to ensure safety.
2. Access the spool by removing the spool cover (referred to as "Tapa de bobina").
3. Pull out the spool (referred to as "Bobina").
4. Untangle the line, making sure it is not damaged.
5. Reinsert the spool, ensuring the line is wound in the direction of the arrows and about 100mm is left unwound and placed into the cleat.
6. Replace the spool cover securely.
Ensure the line is neatly coiled to maintain efficient automatic feed.
This answer is automatically generated
My Hyper-Tough weed eater has started feeding excessive line especially when it starts (also when running). How do I ger it to feed properly (when bumped to feed)?
To fix the line feeding issue on your Hyper Tough weed eater model HT19-401-003-03, follow these steps:
1. Use Command Feed System:
- While the trimmer is running, press the Command Feed button.
- Release the button when you hear a ‘clattering’ noise, indicating the line is cutting.
2. Manual Line Feeding:
- Turn off the trimmer and remove the battery.
- Press and release the manual Line Feed Button while gently pulling the line until it reaches the Line Cutter.
- If too much line is fed, remove the Spool Cap and turn the Spool counter-clockwise to adjust the length.
3. Manually Wind the Line:
- Take about 6 meters of line.
- Insert 2 mm of the line into the Spool holes.
- Wind the line in the direction of the arrows shown on the Spool.
Check and replace the line if it is damaged. Make sure the battery is fully charged and properly installed.
This answer is automatically generated
Trimmer wont start anymore batteries are fully charged put new batteries
The Hyper Tough HT19-401-003-03 trimmer may not start even with fully charged batteries due to the following possible causes:
1) The battery is too hot or too cold—allow it to cool or warm before use.
2) The motor is broken—contact a service agent.
3) Internal wiring of the machine is damaged—contact a service agent.
This answer is automatically generated
