Features:
- SRS: Serial Receiver System provides the facility to use receivers
with serial interface: Spektrum DSM2 and DSMX, Multiplex M-Link,
Futaba S-Bus, Graupner HoTT, Jeti R-SAT, JR DMSS.
- Unrestricted channel assignment of the PowerBox outputs
- Integral high-resolution graphic OLED screen with 128 x 64 pixels
- Particularly user-friendly menu-based programming using the
SensorSwitch
- Door sequencer: six freely programmable outputs with set-up
assistant
- Channel lock when undercarriage is retracted
- 12 channels inclusive one channel for the doorsequencer in the
Cockpit Version
- 14 channels in the Competition version
- Signal amplification and interference suppression for 12 channels
and 21 servos in the Cockpit version
- Signal amplification and interference suppression for 14 channels
and 18 servos in the Competition version
- Synchronised servo output for totally synchronous servo response
- Flight recorder: records Lost Frames and fail-safe periods for all
receivers connected to the backer
- Variable frame rate, range 9 ms - 21 ms
- 16-bit processor for fast, high-resolution signal processing
- Four match-channels, each for two servos. Accurate adjustment of
all eight servos
- Double regulated output voltage for receivers and servos
- Can be connected to Spektrum, HoTT and Multiplex MSB downlink
channel bus systems
- Direct transmission of battery voltages and capacities to the
transmitter
- Separate voltage and capacity displays for each battery
- Software-selectable servo voltage: 5.9 V or 7.4 V
- Minimum value memory displays any voltage collapses
- Large-area heat-sinks for high regulator power
- Regulator monitor, regulator malfunction indicator
- Support for three battery types: LiPo, NiMH / NiCd, LiFePo
- Suppresses any servo feedback currents which might develop
- Can be updated using the PowerBox USB Interface
