- Page 1 . k a r m a i t a l i a n a . i t SET 6080 SET 6080LAV VHF Wireless Microphone SET 6082 SET 6082PL SET 6082LAV Double VHF Wireless Microphone Instruction manual...
- Page 2 Congratulation for your choice! Congratulations for your choice! The Karma product you have purchased is the result of careful planning by specialized engineers. High quality materials have been used for its construction, to ensure its functioning over time. The product is manufactured in compliance with strict regulations imposed by the European Union, a guarantee of reliability and safety.
-
Page 3: Safety Notes
Safety notes • Keep this User Manual for future reference. If you sell the product to another user, be sure to give this manual to the next owner. • Make sure the voltage of the power source used for the product is correct. - Page 4 Community standards EMC ( Electromagnetic Compatibility) and LVD ( Low Voltage Directive ). Compliance documentation in complete form is available at the company Karma Italian Srl. The symbol of the crossed-out dustbin indicates that the product at the end of its life must be collected separately from other waste .
- Page 5 Single Channel Base Double Channels Base N° Function/Description Power Led indicator RF MIC1 Led Signal RF MIC2 Led Signal Left Antenna Right Antenna ON/OFF Button Jack unbalanced MIC - OUT with Jack Connector 6.3mm mono Power Socket Ulteriori informazioni su: www.karmaitaliana.it...
- Page 6 Microphone: MW 6080 Lavalier: MW 6081 N° Function /Description Microphone grid - capsule housing Battery status led indicator Three position switch: off/ mute/ on Plastic body Battery housing Socket for headset or lavalier microphone...
-
Page 7: Setup Example
SETUP EXAMPLE The output from the receiver is a microphone signal. In this example the receiver is connected to a microphone mixer, linked to an amplifier that will send the signal to the speakers. The microphone signal is unbalanced and is supplied through 6,3mm mono sockets. - Page 8 Please be sure that the batteries in the transmitter are charged necessary replace them following instructions. If you have a handy microphone unscrew the lower part to open the battery compartment, where you can put 2 AA batteries (not included). The same batteries can be inserted in the headset version, by opening the front cover.
- Page 9 It is not possible to use more than one microphone on the same channel. In case of contemporary use of more than one microphone, each of them must operate on a different channel. This model is available in different frequencies. For further information contact Karma’s offices. Ulteriori informazioni su: www.karmaitaliana.it...
-
Page 10: Registration Form
Warranty certificate HOW TO SEND THE PRODUCT REGISTRATION FORM: The product is covered by warranty, according to the current If you didn’t register the product on regulations. We suggest to keep our website www.karmaitaliana.it the receipt or the invoice in order we invite you to cut the form on the to use it, in case of necessity, as page beside and to send it to our... - Page 11 Ulteriori informazioni su: www.karmaitaliana.it...
-
Page 13: Compliance Declaration
The product described in this manual is compliant with the essential requirements of 1999/5/CE directive. Karma Italiana Srl This device operates on frequencies that are legal on the Italian territory and might not be authorized in other geographic areas. We suggest to address to the local authorities to ask for information about the frequencies authorized in your country. - Page 14 NOTE...
- Page 15 RECEIVER Power Supply 13-15V / 300-500mA Operative range Max 25 mt Noise Signal > 85dB Spurious > 70 dB Output Audio Level 0 +/-300mV Sinsibility -105dB Operative Temperature da -10° a + 50° C T.H.D. <0,5% Audio dinamyc range >100dB Frequency Responce 40 Hz - 20 KHz Dimensions:...
- Page 16 Via Gozzano 38 bis 21052, Busto Arsizio (VA) - Italy Telefono +39 0331.628.244 1622 Fax +39 0331.622.470 www.karmaitaliana.it made in China...
