- Page 1 WD011911850 1850W...
- Page 2 WD011911850 Thank you for purchasing a WIDO product. We are confident that you will appreciate the quality of the product and you will be entirely satisfied with your purchase. Please read carefully the user safety and operating instruction on how to operate this product correctly within safety...
- Page 3 WD011911850...
- Page 4 WD011911850 6mm(1/4˝)
-
Page 5: Component List
1850W ROUTER COMPONENT LIST Routing base Wing screw Transparent protection Collet nut Right handle Brush holder caps Nylon nut Depth scale Depth stop 10) Left handle 11) Fast feed button 12) Triple depth stop 13) Spindle lock button 14) Plunge lock lever 15) On/off switch 16) Spanner 17) Guide holder and straight guide... -
Page 6: General Power Tool Safety Warnings
1850W ROUTER GENERAL POWER TOOL SAFETY WARNINGS Warning: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 7 1850W ROUTER f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
-
Page 8: Double Insulation
1850W ROUTER 9. Hold the tool firmly with both hands. 10. Keep hands away from rotating parts. 11. Hold power tool by insulated gripping surfaces, when performing an operation where the cutting tool may contact hidden wiring or its own cord. Cutting tool contacting a ‘live’ wire will make exposed metal parts of the tool ‘live’... -
Page 9: Technical Data
Wear dust mask Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice TECHNICAL DATA Model WD011911850 Voltage 110 -120V AC 220 - 240V AC Frequency... - Page 10 1850W ROUTER OPERATING INSTRUCTIONS Note: Before using the power tool, read the instruction manual carefully. 1. INTENDED USE The machine is intended for routing grooves, edges, profiles and elongated holes as well as for copy routing in wood, plastic and light building materials, while resting firmly on the workpiece. 2.
-
Page 11: On/Off Switch
1850W ROUTER hex bolts, first loosen the hex nuts on the hex bolts with the spanner and then turn the hex bolts. After obtaining the desired position, tighten the hex nuts. The triple depth stop is also convenient for making three passes with progressively deeper bit settings when cutting deep grooves. -
Page 12: Maintenance
1850W ROUTER guide by turning the fine adjusting screw. At the desired distance, tighten the wing bolt to secure the trimmer guide in place. When adjusting the guide roller up on down, loosen the wing bolt. After adjusting it, tighten the wing bolt securely. 3) When cutting, move the power tool with the guide roller riding the side of the workpiece (See Fig 9. -
Page 13: Environment Protection
1850W ROUTER inappropriate for the collet, 3. If the surface of the workpiece is not smooth after cutting, check the bit for sharpness, replace bit if the bit is dull. 4. If a fault can’t be rectified, return the power tool to an authorized dealer for repair. ENVIRONMENT PROTECTION Waste electrical products should not be disposed of with household waste. -
Page 14: Explosive View
1850W ROUTER EXPLOSIVE VIEW... - Page 15 1850W ROUTER DESCRIPTION DESCRIPTION Q’TY Q’TY Motor housing Screw Stator Screw Fan baffle Cable clamp Bearing Brush holder cap Rotor Carbon brush Screw Brush holder Press plate Adjusting nut Bearing Bolt for adjusting nut Right handle Cable protector Support Cable and plug Screw Supporting rod Spring...
- Page 16 MADE IN CHINA Copyright @ WIDO Machinery Co., Ltd. All rights reserved. www.widopt.com...
