Owner's Manual
WA57CIUP
High Capacity
Transfer Utility Pump
®
TABLE OF CONTENTS
General Safety . . . . . . . . . . . . . . . . . . . . 2
Specifications. . . . . . . . . . . . . . . . . . . . . 3
Installation. . . . . . . . . . . . . . . . . . . . . 4 -5
Operation. . . . . . . . . . . . . . . . . . . . . . . . .6
Troubleshooting . . . . . . . . . . . . . . . . . . . 7
Warranty . . . . . . . . . . . . . . . . . . . . . . . . .8
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Water Ace WA57CIUP
Summary of Contents for Water Ace WA57CIUP
- Page 1 Owner’s Manual WA57CIUP High Capacity Transfer Utility Pump ® TABLE OF CONTENTS General Safety ....2 Specifications..... 3 Installation.
-
Page 2: General Safety
STOP Before you start A transfer pump is an electrical device designed to operate in inherently wet environments. ALWAYS USE EXTREME CAUTION when installing or maintaining this product! Need Help: Call 1-844-394-2604 for assistance; Do Not Return to Store GENERAL SAFETY Important Safety Instructions General Safety Carefully read and follow all safety... - Page 3 APPLICATIONS For water transfer jobs when pumping water from pools, spas, lakes or ponds. The WA57CIUP pump can also be used to boost water pressure in washdown applications. The motor is fan cooled, non-submersible AC brush motor. A plas- tic suction stainer is supplied with the pump. The WA57CIUP pump is designed to pump only water. NEVER PUMP GASOLINE, CHEMICALS OR ANY CORROSIVE OR FLAMMABLE LIQUIDS with the WA57CIUP.
-
Page 4: Installation
INSTALLATION Do not work on pump until power is unplugged. (h) All piping must be clean and free of all foreign matter to prevent clogging. Do not cut off ground pin or use an adapter fitting. Pump will be inadequate if suspension liquids contain solid particles larger than 1/4”... - Page 5 INSTALLATION The figure of the front of the pump shows a typical installation with threaded brass adapters for con- necting a garden hose are included. Rigid pipe is recommended for suction line. However be sure to only use reinforced garden hose when needing a flexible suction line. Reinforced garden hose will help avoid collapse during operation. In no case should the pump be more than 15 feet above or away from the inlet source. Install a foot valve when the suction lift or suction line is over 10 feet.
-
Page 6: Operation
OPERATION AUTOMATIC THERMAL PROTECTION CAUTION: Do not cycle or continue to run the pump following an overload condition. Thermal overloads are designed to protect the product and user during extreme conditions where nor- mal operating parameters are exceeded. Determine the cause of an overload condition imme- diately after detection and resolve prior to operating the pump again. -
Page 7: Troubleshooting
TROUBLESHOOTING CHECKLIST (Caution: shut off power to pump) POSSIBLE CAUSES/SOLUTIONS PROBLEMS • Line circuit breaker is off, or fuse is blown or loose PUMP DOES NOT RUN AND MAKES HUMMING • Pump cord is not making contact in receptacle. SOUND •... -
Page 8: Warranty
WARRANTY Retain Original Purchase Receipt for Warranty Eligibility Limited Warranty Manufacturer warrants to the original consumer purchaser (“Purchaser” or “You”) that its products are free from defects in material and workmanship for a period of twenty-four (24) months from the date of the original consumer purchase. If, within twenty-four (24) months from the original consumer purchase, any such product shall prove to be defective, it shall be repaired or replaced at manufacturer’s option, subject to the terms and conditions set forth herein. Note that this limited warranty applies to manufacturing defects only and not to ordinary wear and tear.
