- Page 1 Install Manual Tilt Wall Mounting Bracket Please read this manual carefully before operating your set and retain it for future reference. LSW840B P/NO: MFL63640591 (1503-REV01) www.lg.com...
-
Page 2: Important Safety Instructions
COMPONENT Wall mount anchor Wall mount screw Install manual 8 units 8 units Guide spacer 4 units Guide spacer screw 4 units Set protection cushion (M8X44 mm) 4 units IMPORTANT SAFETY INSTRUCTIONS - If you are a professional installer, please read this manual carefully before installing the product. - If you are a professional installer, please give this manual to the user after installing the product and ensure that the user also reads the manual carefully and retains it for future reference. -
Page 3: Before Installation
* Mount the product only on a concrete wall. LG Electronics Inc. is not liable for any accidents caused by mounting the product on walls made of any other materials, including wood, plywood, and bricks. -
Page 4: Installation
INSTALLATION - The picture may differ from the actual product. - Consult a professional installer prior to mounting the TV using a wall bracket. How to Attach the Brackets for the Product to the TV - If the screw will not fully tighten when using a guide spacer, recheck the assembly depth of the screw and refer to the technical service manual. -
Page 5: How To Install The Wall Mount
How to install the wall mount - Mount the product only on a concrete wall. LG Electronics Inc. is not liable for any accidents caused by mounting the product on walls made of any other materials, including wood, plywood, and bricks. - Page 6 Setting the Lock Springs Lock Spring After securing the set to the bracket, pull down the lock springs at the bottom of the wall mounting bracket. * Caution - If the wall mounting bracket is not attached securely, the set may fall off, resulting in damage or injury.
-
Page 7: Tilt Angle Adjustment
Tilt Angle Adjustment - To watch the TV after adjusting the angle, please refer the following images and explanations. (The tilt angle can be adjusted by non-specialized installers. In this case, two or more people are needed) - When you adjust the angle, hold the product carefully with both hands to avoid any damage to the product or wall. ❶... -
Page 8: How To Organize Cables And Attach Protective Cushions
How to Organize Cables and Attach Protective Cushions - Organize the cables as shown in the illustration. Please purchase a band for cable organization, or use the band that comes with the - Attach the protective cushions to minimize the impact between the wall and the TV in case they bump against each other when adjusting the angle. -
Page 9: Specifications
SPECIFICATIONS [Unit: mm] Maximum Minimum 600.5 Model name LSW840B Width (mm) Height (mm) Depth (mm) Product weight (kg) Wall mounting bracket VESA specifications 800X400 Max. tensile load (kg) - Page 10 The model and serial number of the product is located on Supported Displays the back or one side of the product. Record it below (Please contract the retailers or refer to the TV owner’s should you ever need service. manual for applicable models.) MODEL SERIAL...
